REMOTE CONTROL

OPERATING INSTRUCTION
Note: If operating by remote control, you must set the Control Knob on
ELECTRIC. (See Figure 18) Do not set the control knob between locked
position, otherwise there will be no power to the heater.
1. STOP! Read the safety information on page 14.
2. Disconnect or turn off all electric power to heater.
3. This appliance is equipped with an ignition device which automatically
lights the pilot. Do not try to light the pilot by hand.
4. Wait five (5) minutes to clear out any gas. Then smell for gas around
heater including near floor. If you smell gas, STOP! Follow "B" in the
safety information above. If you don't smell gas, go to the next step.
5. Plug into a properly grounded three-prong receptacle, and install three
AAA batteries in remote. A high pitch sound will occur and red power
light on front of heater will be lit.
6. Make sure Control Knob is in ELECTRIC position.
7. Initializing the system for the first time
Change the control identify code : When the identify code is the same
in both the remote control and the main machine , the main machine
can receive the control command . There are four DIP buttons in the
remote control . if you want to change the identify code ,the detail of
operation as following : Open the cap of the remote control , take the
battery , there are four DIP switch (see figure 21) and you can change
the state of the remote control by the object for hard and thin long ,
and change the four DIP switch, then install the battery , close the cap
. Insert the end of the paper clip, or other similar object into the hole
near the light on the front face of the mainframe. At the same time
press the button, the receiver will "beep" two(2) times to indicate
the transmitter's command is accepted and sets to the particular code
of that transmitter. The system is now initialized.
8. Point remote at bottom front of heater, press
spark will ignite the pilot, and the green light on front of heater will be
lit.
Note: When operating heater for the first time, the ignition period may
be 30 seconds or longer. This will allow air to exit fromthe gas system.
Note: The pilot is located on back of front burner. If pilot does not stay
lit, contact a qualified service person or gas supplier for repairs.
Note: If the appears on the remote control, press the
+ together until lock image disappear.
9. If the appliance will not operate, follow the instructions "To Turn Off
Gas To Appliance" and call your service technician or gas supplier.
button; an electric
5
Figure 20 - Front of Remote Control
Figure 2 - Back of Remote Control
(cover removed)
Figure 22 - Blue-light for LCD Display
