WARNING: IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED
EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY
DAMAGE, PERSONAL INJURY, OR LOSS OF LIFE.
-- Do not store or use gasoline or other flammable vapors and liquids in vicinity
of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch; do not use any phone in your building.
Immediately call your gas supplier from a neighbor's phone. Follow the
gas supplier's instructions.
If you cannot reach your gas supplier, call the fire department.
-- Installation and service must be performed by a qualified installer, service
agency or the gas supplier.
This is an unvented gas-fired heater. It uses air (oxygen) from the room in which it is
installed. Provisions for adequate combustion and ventilation air must be provided.
Refer to Air For Combustion and Ventilation section on page 6 of this manual.
INSTALLER: DO NO DISCARD THIS MANUAL – LEAVE FOR HOMEOWNER'S
FUTURE REFERENCE
This appliance may be installed in an aftermarket, permanently located manufactured
(mobile) home, where not prohibited by local codes. This appliance is for use with
the type of gas indicated on the rating plate only. This appliance is not convertible for
use with other gases.
Questions about installation, operation, or troubleshooting? Before returning to your retailer, call our customer
service department toll-free at (877)886-5989
CAUTION - FOR YOUR SAFETY
Vent-free Gas Stove
MODEL NO. SSU220RHN-GB & SSU220RHL-GB
PC-SSU220R653-0805
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Procom SSU220RHN-GB
Summary of Contents for Procom SSU220RHN-GB
- Page 1 Vent-free Gas Stove MODEL NO. SSU220RHN-GB & SSU220RHL-GB CAUTION - FOR YOUR SAFETY WARNING: IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY, OR LOSS OF LIFE. -- Do not store or use gasoline or other flammable vapors and liquids in vicinity of this or any other appliance.
-
Page 2: Table Of Contents
IMPORTANT: Read instructions and warnings carefully before starting installation. Failure to fol- low these instructions may result in a possible fire hazard and will void the warranty. PRODUCT SPECIFICATIONS MODEL NO SSU220RHL-GB SSU220RHN-GB Btu (Variable) 22,000 22,000 Gas Type LP Gas... -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION IMPORTANT SAFETY INFORMATION IMPORTANT: Read instructions and warnings carefully before starting installation. Failure to follow these instructions may result in possible electric shock or fire hazard and will void the warranty. Improper use of this heater can cause seri- ous injury or death from burns, fire, explosion, electrical shock, and carbon monoxide poisoning. -
Page 4: Operating Heater
WARNING: Do not allow fans to blow directly into the heater. Avoid any drafts that alter burner flame patterns including ceiling fans. Altered burner patterns can cause sooting. WARNING: Do not use a blower insert, heat exchanger insert, or other accessory not approved for use with this heater. - Page 5 10. Keep all air openings in front and bottom of heater clear and free of debris. This will ensure enough air for proper combustion. 11. If heater shuts off. Do not relight until you provide fresh, outside air. If heater keeps shutting off, have it serviced. 12.
-
Page 6: Air For Combustion & Ventilation
AIR FOR COMBUSTION AND VENTILATION WARNING: This heater shall not be installed in a confined space or unusually tight construction unless provisions are provided for adequate combustion and ventilation. Read the following instructions to insure proper fresh air for this and other fuel-burning appliances in your home. Providing Adequate Ventilation The following are excerpts from National Fuel Gas Code, NFPA 54/ANSI Z223.1, Section 5.3, Air for Combustion and Ventilation. - Page 7 Divide the space volume by 50 cubic feet to determine the maximum Btu/Hr the space can support. (volume of space)÷50 cu. ft.=(Maximum Btu/Hr the space can support). Add the Btu/Hr of all fuel-burning appliances in the space. Example: Btu/Hr Vent-free heater Btu/Hr Gas water heater 30,000...
-
Page 8: Product Features
PRODUCT FEATURES Safety Pilot This heater has a pilot with an Oxygen Depletion Sensing (ODS) safety shutoff system. The ODS/pilot shuts off the heater if there is not enough fresh air. Automatic Ignition System This heater is equipped with an automatic control system. This system requires no matches, or batteries to light heater. - Page 9 UNPACKING Remove top inner pack. Tilt carton so that stove is upright. Remove protective side packaging. Slide stove out of carton. Remove protective plastic wrap. Rotate door handle and open door. Logs # 1, 3, 4, 5, & 6 are under heater. Carefully unwrap logs.
-
Page 10: Installation
Clearances To Combustibles Carefully follow the instructions below. This stove is a freestanding unit designed to set directly on the floor. IMPORTANT: You must maintain minimum wall and ceiling clearances during installation. The minimum clearances are shown in Figure 4. Measure from outermost point of stove top. If heater is installed directly on carpeting, tile or other combustible material, other than wood flooring, the heater shall be installed on a metal or wood panel extending the full width and depth of the... -
Page 11: Checking Gas Connections
FOR PROPANE UNITS ONLY The installer must supply an external regulator (see Figure 5). The external regulator will reduce incoming gas pressure. If you do not reduce incoming gas pressure, heater regulator damage could occur. lnstall external regula- tor with the vent pointing down as shown in Figure 6. Pointing the vent down protects it from freezing rain or sleet. - Page 12 PRESSURE TESTING GAS SUPPLY PIPING SYSTEM Test Pressures In Excess Of 1/2 PSIG (3.5kPa) Disconnect heater with its appliance main gas valve (control valve) and equipment shutoff valve from gas supply piping system. Pressures in excess of 1/2 PSIG will damage heater regulator. Cap off open end of gas pipe where equipment shutoff valve was connected.
-
Page 13: Log Placement
INSTALLING DECORATIVE LOGS WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts spe- cifically approved with this heater may result in property damage or personal injury. CAUTION: After installation and periodically thereafter, check to ensure that no yellow flame comes in con- tact with any log. -
Page 14: Operating Heater
OPERATING HEATER FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. CAUTION: Do not try to adjust heating levels by using the equipment shutoff valve. NOTICE: During initial operation of new heater, logs will give off a paper-burning smell. -
Page 15: Remote Control
REMOTE CONTROL OPERATING INSTRUCTION Note: If operating by remote control, you must set the Control Knob on ELECTRIC. (See Figure 18) Do not set the control knob between locked position, otherwise there will be no power to the heater. STOP! Read the safety information on page 14. Disconnect or turn off all electric power to heater. -
Page 16: Lighting Instructions
TO TURN OFF GAS TO APPLIANCE Shut off heater Press the button. Set Switch on OFF position or unplug the electric power to the heater. (See Figure 20) SETTING TIMER Auto Off: With burner operating, press button. Then press to change to the scheduled time. Press the button again;... - Page 17 With Control Knob pressed in, push and release the ignitor button. This will light the pilot. If needed, keep pressing ignitor button until pilot lights. Keep Control Knob depressed for ten (10) seconds after lighting pilot. If pilot goes out, repeat steps 6, 7 and 8. Turn counterclockwise to “ON”...
-
Page 18: Care And Maintenance
CARE AND MAINTENANCE WARNING: Disconnect power before attempting any maintenance or cleaning to reduce the risk of fire, electric shock or personal injury. Turn off heater and let cool before cleaning. WARNING: Failure to keep primary/air openings of burners clean may result in sooting and property damage. CAUTION: Label all wires prior to disconnection when servicing controls. - Page 19 Clean the pilot assembly also. A yellow tip on the pilot flame indicates dust and dirt in the pilot assembly. There is a small air inlet hole about two inches from where the pilot flame comes out of the pilot assembly (see Figure 31). With the unit off, lightly blow air through the air inlet hole.
-
Page 20: Troubleshooting
TROUBLESHOOTING NOTE: BEFORE YOU SWITCH TO “ELECTRIC” CONTROL LEVEL FROM MANUAL CONTROL, YOU NEED TO TURN THE KNOB TO “OFF” LEVEL FIRST AND WAIT FOR ONE MINUTE; THEN TURN THE KNOB TO “ELECTRIC”. IN CASE “ELECTRIC” CONTROL LEVEL DOES NOT WORK, PLEASE TURN THE CONTROL KNOB COUN- TERCLOCKWISE TO “OFF”... - Page 21 PROBLEM POSSIBLE CAUSE REMEDY ODS/pilot has flame but continues to Thermocouple connection loose Check that connectors are secure spark on module Low gas pressure Contact local gas company Dirty or partially clogged ODS pilot Clean ODS/pilot (see Care and Maintenance, page 18) Thermocouple damaged Replace thermocouple Gas valve or regulator damaged...
- Page 22 PROBLEM POSSIBLE CAUSE REMEDY White powder residue forming within Heated vapors from furniture pol- Turn heater off when using furni- burner box or on adjacent walls or ish, wax, carpet cleaners, etc. turn ture polish, wax, carpet cleaner, or furniture into white powder residue similar products Heater is burning vapors from...
-
Page 23: Replacement Parts
REPLACEMENT PARTS Use only original replacement parts. This will protect your warranty coverage for parts replaced under warranty. PARTS UNDER WARRANTY Contact authorized dealers of this product. If they can’t supply original replacement part(s) call the number on the front of this manual. When contacting customer services, have ready: •... - Page 24 PARTS LIST SSU220RHN-GB & SSU220RHL-GB This list contains replaceable parts for your heater. When ordering replacement parts, follow the instructions listed under Replacement Parts on page 23 of this manual. Part Number Description Burner Assembly SSU220R230 ND4908X400-RH ND4703X400-RH Valve NV2020-22A...
-
Page 25: Parts List
PARTS LIST This list contains replaceable parts for your heater. When ordering replacement parts, follow the instructions listed under Replacement Parts on page 23 of this manual. SLU35A102C Top Panel Assembly SLU35A130 Door Assembly SLU35A106-01 Lower Front Panel SLU35A101C-01 Rear Panel SLU35A106C-01 Louver Assembly SLU35A200...
