Kramer VP-773A User Manual page 114

Command
Usually the firmware will upload to the device via a command such as LDFW
A device reset may be needed to complete the process
Video core Firmware
update execute*
Reset configuration
to factory default
Reset Ethernet
configuration to
factory default
SET dedicated EAS
port settings
GET dedicated EAS
port settings
Parameters Description:
PORTTYPE
PORTNUM
EAS Activation Mode
notification
messages
Parameters Description:
ACTIVATION-MODE = EAS notification:
1" to notify full screen + siren alert mode (Severity = Extreme)
"2" to notify full screen alert mode (Severity = Severe)
"3" To notify full screen alert mode (Severity = Moderate)
"4" To notify message mode (Severity = Minor)
"5" To notify message crawler mode (Severity = Unknown)
"0" to notify that the alert went off either by timeout or by keystroke
SET dedicated port
tunneling settings
GET dedicated port
tunneling settings
Parameters Description:
PORTTYPE
PORTNUM
SET UART port tunneling
settings
GET UART port tunneling
settings
Parameters Description:
BAUD = 1200, 2400, 4800, 9600, 19200, 38400 57600,
115200
DATA_BITS = 5 to 8 inclusive
PARITY = "NONE", "ODD", "EVEN", "MARK", "SPACE"
or the first letter of these words
STOPBITS = 1 or 2
108
Operation commands
UPGRADES
FACTORY
ETH-FACTORY
EAS-CFG PORTTYPE,
PORTNUM
EAS-CFG?
either "TCP" or "UDP"
Ethernet port
N/A
PTNL-CFG PORTTYPE,
PORTNUM
PTNL-CFG?
either "TCP" or "UDP"
Ethernet port
UART BAUD,
DATA_BITS, PARITY,
STOPBITS
UART?
VP-773A - The VP-773A RS-232 Communication Protocol
Syntax
UPGRADES OK
FACTORY RESULT
ETH-FACTORY RESULT
EAS-CFG PORTTYPE,
PORTNUM RESULT
EAS-CFG PORTTYPE,
PORTNUM
EAS-EXE ACTIVATION-MODE OK
Response
PTNL-CFG CFG PORTTYPE,
PORTNUM RESULT
PTNL-CFG PORTTYPE,
PORTNUM
UART BAUD, DATA_BITS,
PARITY, STOPBITS RESULT
UART BAUD, DATA_BITS,
PARITY, STOPBITS
