VP-772T Quick Start Guide
This guide helps you install and use your VP-772T for the first time.
Go to
upgrades are available.
Scan for full manual
Step 1: Check what's in the box
VP-772T Presentation Matrix Switcher Control Panel
1 Desktop mounting bracket kit

Step 2: Get to know your VP-772T

# Feature

Control Panel Functionality

1 MACHINE # Button
7-segment Display
2 Lamp XLR Connector (x2)
3 LAMP ON Button (x2)
4 ON Button
VP-772T Quick Start (P/N: 2900-300875QS REV 1)
www.kramerav.com/downloads/VP-772T
Function
Press to select the device to be controlled. The 7-segment display shows the selection (cycles
through 1 to 4 and A (all the devices).
All the operation buttons on the front panel refer to the selected controlled device.
Displays the number of the device that is currently controlled as well as other indications:
1 – The VP-772 unit that is connected to RS-485-1 port is currently controlled (same for 2, 3 and 4).
A –All the connected devices are currently controlled.
L – Indicating that VP-772T is currently powering up.
F – Indicates factory reset. Appears when powering the device while pressing the ON button.
Connect a gooseneck lamp.
Press to turn light on or off.
Power the T-bar console on or off.
to download the latest user manual and check if firmware
2 Lamps 1 Bracket set
4 Rubber feet 1 Power adapter
P/N:
2900- 300875QS
1 Quick start guide
Rev:
1
