4. SAFETY REQUIREMENTS AND CARE

Follow safety requirements! Don't face and stare at laser beam!
Laser level- Is an accurate Instrument, which should be stored and used with care.
Avoid shaking and vibrations! Store the Instrument and It's accessories only In the carrying case.
In case of high humidity and low temperature, dry out the Instrument and clean It after the usage.
Do not store the Instrument at a temperature below -0°C and above 50°C, otherwise the Instrument can be
out of action.
Don't put the Instrument Into the carrying case If the Instrument or case are wet. To avoid moisture condensa-
tion Inside the Instrument- dry out the case and laser Instrument!
Check regularly Instrument adjustment!
Keep the lens clean and dry. To clean the Instrument use a soft cotton napkin!

5. ORDER WORKING

1. Before use, remove battery compartment cover. Insert three batteries into battery compartment with proper
polarity, the put the cover back (Pic. ).
. Set the compensator locking grip into ON position, two laser beams and back-lighted bubble level will be
on.
If the switch is ON,that means the power and the compensation are opened.
If the switch is X, that means the power is opened,the compensation is still locked ,but we
can still issue the lines and dot if you push the keypad,also it will not warn if you issue the
slope. It's the hand-mode.
If the switch is OFF, that means shut off the power,the compensation is also locked.
3. Press V/H button - horizontal beam will turn on. Press the button V/H one more time
- vertical laser beam will turn on. Again press the button V/H - horizontal and vertical
beams will turn on.
6
2D 2D
BASIC LEVEL BASIC LEVEL
MEASUREMENT FOUNDATION
Pic.2
