Specifications - CipherLab 8500 Reference Manual

SPECIFICATIONS

Model Designation
Wireless
Communications
Readers
Electrical
Characteristics
Physical
Characteristics
IR/IrDA
Bluetooth Class 2
802.11b/g
GSM/GPRS
Barcode Reader
RFID Reader
Main Battery
Working Time
Backup Battery
CPU
Memory
Display
Keypad
Indicators
Vibrator
Enclosure Material
Dimensions
Weight
8500 8570
√ √
√ √
– √
– –
CCD (linear imager)
Standard Laser
Long Range Laser
Extra Long Range Laser
2D Imager
Frequency 13.56 MHz
Rechargeable Li-ion battery – 3.7 V, 4000 mAh
Laser, one scan per 5 seconds, with backlight on:
400 hours in batch mode
32 hours in Wi-Fi mode
Rechargeable Lithium button cell – 3.0 V, 7 mAh
Data retention – at least 7 days
32-bit Toshiba CMOS type, 40 MHz
Program memory – 2 MB flash
Data memory – 2 MB onboard SRAM, upgradeable
(4 MB/ 8 MB memory card)
Graphic LCD, 160 x 160 pixels, 3" FSTN with LED
backlight programmable
Font size 6x8: 26 characters by 19 lines
Font size 8x16: 20 characters by 9 lines
Also a touch screen allows for the use of stylus for
control and signature capture.
24 or 44 rubber keys, LED backlight programmable
LED – Dual-color (red/green), programmable
Buzzer – Low power transducer type, 1 KHz to 4
KHz, programmable
9000 ± 2000 RPM, Max. 50 dB, programmable
Rubber & ABS plastic
230 mm (L) 91 mm (W) 65 mm (H)
Approx. 600 g (Laser and battery included)
8580 8590
√ √
√ √
– √
√ √
