Installation
1 Inverter
12A
12A
12A
12A
12A
12A
1
12A
12A
12A
12A
12A
12A
12A
12A
12A
12A
12A
12A
Illustration 2.21 Incorrect Parallel Connection
1 Parallel jumper
2 Parallel connection, 1 input. Current in first input is
exceeded, thus overloading cable and PV load switch.
3 Parallel connection missing. All PV power feeds into one
input, thus risking overload of PV connector, cable and PV
load switch.
4 Parallel jumper missing, thus risking overload of PV
connector, cable and PV load switch in the event of inverter
failure.
Table 2.3 Legend to Illustration 2.21
Cabling
2
20A
20A
20A
3
20A
20A
30A
20A
4
20A
20A
30A
20A
L00410309-09_02
PV module
7A
7A
7A
7A
2 2
13
