Danfoss TLX Installation Manual page 31

Technical Data
Parameter
Cable specification
Sensor Input Specification
4 4
Direct contact protection
Short-circuit protection
Table 4.9 Auxiliary Interface Specifications
1)
A maximum of 100 inverters can be connected in 1 network. If
GSM modem is used for portal upload, the number of inverters in a
network is limited to 50.
2) For underground use, outdoor burial type cable is recommended
for both Ethernet and RS-485.
3)
Third input is used for compensation of the irradiation sensor.
4)
The number of inverters to be connected in the RS-485 network
depends on which peripheral device is connected.
CAUTION
To ensure fulfilment of IP enclosure rating, correctly
mounted cable glands are essential for all peripheral
cables.
CAUTION
To ensure EMC compliance, shielded cables must be
applied for sensor inputs and RS-485 communication.
Unshielded cables may be applied for alarm outputs.
Other auxiliary cables must pass through the designated
EMC cable clamps to establish mechanical fixing and in
case of shielded cable termination to the shielding device.
28
Parameter Details
Cable jacket diameter (⌀)
Cable type
Cable shield termination
Maximum wire gauge
Maximum cable length
Sensor input class
Nominal output current
Maximum short-circuit output current
Open-circuit output voltage
Maximum pulse frequency
Double/Reinforced insulation
Parameter
Potential free
contact
Rating AC
Rating DC
Maximum wire
gauge
Overvoltage
category
Modem
Table 4.10 Auxiliary Input Specifications
L00410309-09_02
Specification
4-8 mm
Shielded Single Pair - 2-wire
Via EMC cable clamp
2
2.5 mm
30 m
Class A
12 mA for an 800 Ω load
24.5 mA
+12 VDC
16.7 Hz
Yes
Yes
Condition Specification
Relay output x 1
250 V AC, 6.4 A, 1600 W
24 V DC, 6.4 A, 153 W
2.5 mm
Class III
GSM
2
