The earth has to be connected. The device must only be connected with an electric installation carried
out in compliance with IEC standards.

OPERATION

After you connected the effect to the mains, The fixture starts running

Stand Alone operation

In the stand alone mode, the fixture can be use without controller
Master/slave-operation
The master/slave-operation enables that several devices can be synchronized and controlled by one
master-device

DMX controlled operation

You can control the projectors individually via your DMX-controller

Addressing

The control board allows you to assign the DMX starting address,
Note; it's necessary to insert the XLR termination plug (with 120ohm) in the last device in the link in
order to ensure proper transmission on the DMX data link.
CON TROL BOARD
The control board offer several features :you can simple set the starting address, run the
pre-programmed program or make a reset
The main menu is accessed by pressing the Mode/Esc-button, Browse through the submenu by
pressing Up or Down .Press the Enter-button in order to select the desired menu. You can change the
selection by pressing Up or Down, Confirm every selection by pressing the Enter-button. You can leave
every mode by pressing the Mode/Esc-button .The functions provided are described in the following
setting.
DMX Address
Setting
Display
Menu control
Test mode
1-512
Mode
Model number
PAN reverse
Tilt reverse
PAN/TILT exchange
Dimmer reverse
Iris reverse
Effect rotated distance
DMX reset
Language
Display brightness
Back bright setting
From CH1-CH16
Sound mode
Auto mode
Press Enter to edit the DMX address, First
press to select the third number of DMX
address, second press to select the second
number of DMX address, third press to select
the first number of DMX address
Standard mode/extend mode
Model number select
Yes/no
Yes/no
Yes/no
Yes/no
Yes/no
Yes/no
Yes/no
English
0-32
All on/delay darkness/ off with no function
001-255
4
