Vicon Industries Inc. does not warrant that the functions contained in this equipment
will meet your requirements or that the operation will be entirely error free or perform
precisely as described in the documentation. This system has not been designed to be
used in life -critical situations and must not be used for this purpose.
WARNING: To reduce a risk of fire or electric shock, do not expose this product to rain
or moisture.
Copyright © 2002 Vicon Industries Inc. All rights reserved.
Product specifications subject to change without notice.
Vicon and its logo are registered tr ademarks of Vicon Industries Inc.
VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788
TEL: 631-952-CCTV (2288) FAX: 631-951-CCTV (2288) TOLL FREE: 800-645-9116
24-Hour Technical Support: 800-34-VICON (800-348-4266)
UK: +44 (0) 1489 566300 INFOFAX: 800-287-1207 WEB: www.vicon-cctv.com
Vicon part number 8009-8028-06-00
XX028-06-00 Rev 1002 Surveyor4 Fixed-Position Camera Dome
MINIATURE FIXED-POSITION
CAMERA DOMES
XX028-06-00
Rev 1002 Section 1
Contents • • i
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vicon Surveyor 4
Summary of Contents for Vicon Surveyor 4
- Page 1 MINIATURE FIXED-POSITION CAMERA DOMES Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements or that the operation will be entirely error free or perform precisely as described in the documentation. This system has not been designed to be used in life -critical situations and must not be used for this purpose.
- Page 2 Contents • • ii XX028-06-00 Rev 1002 Surveyor4 Fixed-Position Camera Dome...
-
Page 3: Table Of Contents
Contents Quick Installation..........................ii Introduction ............................1 Installation............................3 Unpacking and Inspection ........................3 Inspection for Visible Damage......................3 Inspection for Concealed Damage ......................3 Surveyor4 Dome Components ......................3 Mounting the Unit ..........................4 Camera/Lens Adjustments........................8 Final Installation..........................10 Operation............................11 Maintenance ............................11 Care and Cleaning of Lower Dome .................... -
Page 4: Quick Installation
Quick Installation ii • • Quick Installation XX028-06-00 Rev 1002 Surveyor4 Fixed-Position Camera Dome... -
Page 5: Introduction
Read this manual through completely before attempting installation. Vicon’s Surveyor4 Series of Miniature Fixed-Position Camera Domes offers a compact indoor domed housing incorporating a fixed camera and lens combination. They are configured for in-ceiling installation. The domes include a standard or high-resolution monochrome or color camera with a choice of manual varifocal or varifocal autoiris lenses. - Page 6 Table 1 Models, Product Codes and Descriptions Model Product Code Description S4-M36 7816-00 1/3-in. monochrome camera and 2.6 - 6 mm varifocal lens; 24 VAC; 4-inch smoked lower dome; EIA; coaxial cable video S4-M36C 7816-01 1/3-in. monochrome camera and 2.6 - 6 mm varifocal lens;24 VAC; 4-inch smoked lower dome;...
-
Page 7: Installation
Installation Unpacking and Inspection All Vicon equipment is tested and inspected before leaving the factory. It is the carrier’s responsibility to deliver the equipment in the same condition as it left the factory. Inspection for Visible Damage Immediately inspect the cartons upon delivery. Make a note of any visible damage on all copies of the carrier’s freight bill. -
Page 8: Mounting The Unit
Mounting the Unit The Surveyor4 is intended for in-ceiling installation. It can be installed in either a dropped ceiling or a hard ceiling. Installation is done with a 4 x 4 electrical box, which is included. All mounting hardware is provided. The ceiling material must provide suitable strength to support the weight of the Surveyor4 dome (3.0 lb, 1.4 kg). - Page 9 The power supply for the camera must be 24 VAC. Refer to Figure 5. Note: Vicon systems and components, like most electronic equipment, require a clean, stable power source. Voltage irregularities such as surges, drops, and interruptions can affect the operation of your equipment and, in severe cases, damage certain components.
-
Page 10: Power Supplies
11. Connect the safety cord (lanyard) on the lower dome to one of the holes provided in the enclosure with the screw that is provided. Power Supplies Vicon recommends several power supplies, depending on the needs of the installation. Refer to the table below. For other multichannel power supplies, contact Altronix Corporation at 888-258-7669. Model Number... - Page 11 Figure 3 Enclosure/Camera Assembly Components (Inside View) Figure 4 Camera Orientation (Color Camera) Installation • • 7 XX028-06-00 Rev 1002 Surveyor4 Fixed-Position Camera Dome...
-
Page 12: Camera Synchronization
Figure 5 Power Connections Camera Synchronization If there is more than one unit in a system, the cameras have to be synchronized to ensure there is no roll of video. If the camera will be used in a line lock video application (color camera only), the camera interface board is already set in line lock mode by default. -
Page 13: Camera/Lens Adjustments
Camera/Lens Adjustments After all cabling is complete, the camera and lens can be adjusted. DIP Switch Settings On color cameras, line lock and autoiris control are DIP switch selectable. For monochrome cameras, only autoiris control is available. AI setting is for external autoiris and EE setting is for internal autoiris. Refer to Figure 6 for the location and setting of the switches. -
Page 14: Final Installation
Camera/Lens Positioning The camera position can be adjusted in four axes, horizontally (pan), vertically (tilt), vertical height of the camera/lens assembly in the enclosure and rotation about the lens axis (roll). Rotate the camera/lens assembly on the camera mounting (L) bracket to adjust the pan position; swivel the assembly for tilt position. The vertical height of the camera/lens assembly can be adjusted by loosening the lock nut, changing the vertical position of the camera mounting bracket within the slot in the mounting bracket and retightening the nut. -
Page 15: Operation
Operation When power is applied to the camera, the Surveyor4 dome views the selected scene. Maintenance The Surveyor4 Miniature Fixed-Position Camera Dome requires no scheduled maintenance except for the occasional cleaning of the lower dome. Care and Cleaning of Lower Dome The inside surface of the smoked (gray-tinted) dome is easily scratched. -
Page 16: Shipping Instructions
Shipping Instructions Use the following procedure when returning a unit to the factory: 1. Call or write Vicon for a Return Authorization (R.A.) at one of the locations listed below. Record the name of the Vicon employee who issued the R.A. -
Page 17: Reference
Caution: Careful selection of the proper cable is essential to obtain the best performance from this equipment. Vicon assumes no responsibility for poor performance when cables other than those recommended are installed. In all cases, coaxial cable impedance should be 75 ohms. - Page 18 Twisted-Pair Cable Caution: Careful selection of the proper cable is essential to obtain the best performance from this equipment. Vicon assumes no responsibility for poor performance when cables other than those recommended are installed. Materials Use a pure copper stranded or solid conductor with or without a tin plating to obtain a low DC resistance. Do not use cable with either steel or aluminum stranded conductor because these do not transfer signals effecti vely for long distances.
-
Page 19: Technical Information
Technical Information ELECTRICAL Input Voltage: 13 – 28 VAC (24 VAC nominal), nonisolated. (Nonisolated camera input requires an isolated power supply; see Installation section.) Current Rating: 300 mA at 24 VAC. Power Consumption: 7.2 W. Heat Equivalent: 0.4 btu/min (0.1 kg-cal/min). Note: These figures represent the conversion of 100% of the electrical energy to heat. - Page 20 Dimensions: Height: 3.0 in. (76 mm), below ceiling; 4.1 in. (104 mm), above ceiling. Total Diameter: 6.2 in. (157 mm). Dome Diameter: 5.25 in. (133 mm). Total width of electrical box: 4.75 in. (121 mm). Weight: Approximately 3.0 lb (1.4 kg). Construction: Plastic and steel.
- Page 21 Table 3 Camera Specifications Model Image Color/ Resolutio Sensitivity Electronic Iris Signal-to-Noise Device Mono fc (lux) (sec) Ratio (TV lines) S4-M36/ 1/3” CCD, 2:1 Mono 0.028 (0.3) 1/60 (1/50)- >50 dB (AGC off) interlace, At 20 IRE, f/2 1/100,000, S4-M36C NTSC/PAL 1/3”...
- Page 22 Vicon Industries Inc. Corporate Headquarters 89 Arkay Drive Hauppauge, New York 11788 631-952-CCTV (2288) 800-645-9116 Fax: 631-951-CCTV (2288) &Infofax: 800-287-1207 Vicon Europe Headquarters Brunel Way Fareham, PO15 5TX United Kingdom +44 (0) 1489 566300 Fax: +44 (0) 1489 566322 Brussels Office...
