XX077-00-00
Surveyor2000-MSH Maximum Security Housing
Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet
your requirements or that the operation will be entirely error free or perform precisely as
described in the documentation. This system has not been designed to be used in life-critical
situations and must not be used for this purpose.
Copyright © 2001 Vicon Industries Inc. All rights reserved.
Product specifications subject to change without notice.
Vicon and its logo are registered trademarks of Vicon Industries Inc.
VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788
TEL: 631-952-CCTV (2288) FAX: 631-951-CCTV (2288) TOLL FREE: 800-645-9116
24-Hour Technical Support: 800-34-VICON (800-348-4266)
UK: 44/(0) 1489-566300 INFOFAX: 800-287-1207 WEB: www.vicon-cctv.com
Vicon Part No. 8009-8077-00-00 Section 1 Rev 1201
Advertisement
Table of Contents
Related Manuals for Vicon Surveyor 2000-MSH
Summary of Contents for Vicon Surveyor 2000-MSH
- Page 1 XX077-00-00 Surveyor2000-MSH Maximum Security Housing Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements or that the operation will be entirely error free or perform precisely as described in the documentation. This system has not been designed to be used in life-critical situations and must not be used for this purpose.
-
Page 3: Table Of Contents
Contents CONTENTS.......................... 1 QUICK INSTALLATION....................... 2 INTRODUCTION ........................3 Surveyor2000-MSH Maximum Security Housing Components ..............3 Unpacking and Inspection ..........................3 Accessory Kit ..............................3 INSTALLATION ........................6 Mounting the Unit ............................6 OPERATION ........................8 MAINTENANCE ........................8 Care and Cleaning of Clear Acrylic Domes....................8 Fuse Replacement ............................ -
Page 4: Quick Installation
Quick Installation Quick Installation • • • • 2 XX077-00-00 Rev 1201 Surveyor2000-MSH Maximum Security Housing... -
Page 5: Introduction
Open the cartons and inspect the equipment for damage. Save the cartons and packing material. If damage is present, contact the carrier and file a damage claim immediately. If the equipment must be returned to Vicon for repair, follow the instructions in the Shipping Information section of this manual. - Page 6 Model Product Description Code 1/4-in. color camera, NTSC version, 23x zoom, high-resolution day/night camera, S2000-RW23-MSH 7554-00 lower polycarbonate dome, mounting bracket not included 1/4-in. color camera , PAL version, 23x zoom, high-resolution day/night camera, S2000-RW23C-MSH 7554-01 lower polycarbonate dome, mounting bracket not included 1/4-in.
- Page 7 Figure 1 Exploded View Introduction • • • • 5 XX077-00-00 Rev 1201 Surveyor2000-MSH Maximum Security Housing...
-
Page 8: Installation
Communications Power Supply Board and place each under the Cable Retainer. They are TB1 (Power), J1 (Video), J2 (Alarm) and J3 (Communication/Relay). Use the Vicon Model S28PS or S28PS- 230 power supplies for Camera/Drive power. DO NOT APPLY POWER AT THIS TIME. Reference Table 4 and the Wiring Section of the Surveyor2000 Installation &... - Page 9 CONNECTOR/PIN CONNECTOR TYPE CONNECTOR/PIN LABEL SIGNAL NAME NUMBER BNC (female) VIDEO (J1) Video output VIDEO TERMINAL BLOCK POWER (TB1) TB1-1 TB1-2 Neutral TB1-3 No connection RJ-45 ALARM (J2) J2-1 ALARM1 Alarm input 1 J2-2 VSSA Ground J2-3 ALARM2 Alarm input 2 J2-4 VSSA Ground...
-
Page 10: Operation
Operation When power is applied to the camera, the Surveyor2000-MSH will boot up through a diagnostic routine and view the currently selected scene. Refer to the Surveyor2000 Programming Manual XX034 for details on setup and operation. Maintenance The Surveyor2000-MSH Camera Dome requires no scheduled maintenance except for the occasional cleaning of the Lower Dome. -
Page 11: Shipping Instructions
Shipping Instructions Use the following procedure when returning a unit to the factory: 1. Call or write Vicon for a Return Authorization (R.A.) at one of the locations listed below. Record the name of the Vicon employee who issued the R.A. -
Page 12: Cable Recommendations
400 (120) 530 (160) 820 (250) * Longer cable runs may produce a dim, faint picture. Use a Vicon Video Amplifier to obtain a usable picture for long cable runs. Usable Vicoax Signal vs. Cable Length Maximum Cable Length ft (m) -
Page 13: Twisted-Pair Cable
Twisted-Pair Cable CAUTION: Careful selection of the proper cable is essential to obtain the best performance from this equipment. Vicon assumes no responsibility for poor performance when cables other than those recommended are installed. Materials Use a pure copper stranded conductor with or without a tin plating to obtain a low DC resistance. Do not use cable with either a steel or an aluminum stranded conductor because these do not transfer signals effectively for long distances. -
Page 14: Technical Information
Technical Information ELECTRICAL (Surveyor2000 Camera/Drive only) Drive Type: Electrical motorized pan and tilt, electronic control. Camera Types: Units available in monochrome (EIA/CCIR) and color (NTSC/ PAL). Input Voltage: 22 - 34 VAC, 28 VAC nominal. Use the S28PS or S28PS- 230 power supplies for Camera/Drive power. - Page 15 V1466 series NOVA CPUs, V1400-DVC System Console and V1300X-DVC desktop keypad or V1300-RVC rack- mounted keypad. Control Software: Vicon’s ProTech or Direct Control software running on a standard PC-type computer with an RS-422/485 half duplex protocol interface. Technical Information • • • • 13...
- Page 16 Control Format: RS-422 or RS-485 protocol selectable via DIP switch 2. Communication is simplex or half duplex operation at 4800, 9600 or 19,200 baud or Vicon’s enhanced Vicoax protocol (superimposed data on composite video signal) automatically detected upon power-up. RS-485 protocol utilizes full tri-state outputs for daisy chain capability.
- Page 17 MECHANICAL (Surveyor2000-MSH Housing only) Application: Indoor or outdoor. Mounting: Ceiling or Wall mounting with separately purchased Mounting Brackets. See Table 3. Cable Access: 0.88 in (22 mm) hole size utilizing provided 0.5 in (12.7 mm) Liquid Tight Fitting. Mounting Pattern: Two four (4)-hole patterns on each mount sized to accommodate provided 3/8 in.
- Page 18 ENVIRONMENTAL Operating Temperature Range: Indoors (no Heater/Blower Assembly or Sunshield): 32 to 110°F (0 to 43°C). Outdoors with sun exposure (with Heater/Blower Assembly): -40 to 105°F (-40 to 40.5°C). Outdoors with sun exposure (with Heater/Blower Assembly and Sunshield): -40 to 122°F (-40 to 50°C). Note: The Sunshield cannot be used with the S2000-MSH-CM Ceiling Mount Bracket.
- Page 19 NOTES Technical Information • • • • 17 XX077-00-00 Rev 1201 Surveyor2000-MSH Maximum Security Housing...
- Page 20 Vicon Industries Inc. Corporate Headquarters 89 Arkay Drive Hauppauge, New York 11788 631-952-CCTV (2288) 800-645-9116 Fax: 631-951-CCTV (2288) Infofax: 800-287-1207 Vicon Europe Headquarters Brunel Way Fareham, PO15 5TX United Kingdom 44/(0) 1489/566300 Fax: 44/(0) 1489/566322 Brussels Office Planet II - Unit E...
