XX077-50-00
S2000-MSH-HHB Heater/Blower Version
Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet
your requirements or that the operation will be entirely error free or perform precisely as
described in the documentation. This system has not been designed to be used in life-critical
situations and must not be used for this purpose.
Copyright © 2002 Vicon Industries Inc. All rights reserved.
Product specifications subject to change without notice.
Vicon and its logo are registered trademarks of Vicon Industries Inc.
VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788
TEL: 631-952-CCTV (2288) FAX: 631-951-CCTV (2288) TOLL FREE: 800-645-9116
24-Hour Technical Support: 800-34-VICON (800-348-4266)
UK: +44 (0) 1489-566300 WEB: www.vicon-cctv.com
Vicon Part No. 8009-8077-50-00 Section 1 Rev 1202
Advertisement
Table of Contents
Related Manuals for Vicon S2000-MSH-HHB Surveyor 2000
Summary of Contents for Vicon S2000-MSH-HHB Surveyor 2000
- Page 1 XX077-50-00 S2000-MSH-HHB Heater/Blower Version Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements or that the operation will be entirely error free or perform precisely as described in the documentation. This system has not been designed to be used in life-critical situations and must not be used for this purpose.
-
Page 5: Table Of Contents
Contents CONTENTS ..........................1 QUICK INSTALLATION .......................2 INTRODUCTION........................3 S2000-MSH-HHB Maximum Security Housing Components ..............3 Unpacking and Inspection..........................3 Accessory Kit..............................3 INSTALLATION ........................6 Mounting the Unit ............................6 OPERATION.........................8 MAINTENANCE........................8 Care and Cleaning of Clear Acrylic Domes ....................8 Fuse Replacement............................8 SHIPPING INSTRUCTIONS ....................9 CABLE RECOMMENDATIONS ..................10 Twisted-Pair Cable ............................11 TECHNICAL INFORMATION .....................12 Contents •... -
Page 6: Quick Installation
Quick Installation 2 • Quick Installation XX077-50-00 Rev 1202 S2000-MSH-HHB Heater/Blower Version... -
Page 7: Introduction
Open the cartons and inspect the equipment for damage. Save the cartons and packing material. If damage is present, contact the carrier and file a damage claim immediately. If the equipment must be returned to Vicon for repair, follow the instructions in the Shipping Information section of this manual. - Page 8 Model Product Description Code S2-RW23 7053-00 1/4-in. color camera, NTSC version, 23x zoom, high-resolution day/night camera S2-RW23C 7053-01 1/4-in. color camera , PAL version, 23x zoom, high-resolution day/night camera S2-CW22 8215-00 1/4-in. color camera, NTSC version, 22x zoom, high-resolution camera, Exview HAD CCD S2-CW22C 8215-01 1/4-in.
- Page 9 Figure 1 Exploded View Introduction • 5 XX077-50-00 Rev 1202 S2000-MSH-HHB Heater/Blower Version...
-
Page 10: Installation
POWER AT THIS TIME. Reference Table 4 and the Wiring Section of the Surveyor2000 Installation & Operation Manual XX031. Note: Vicon systems and components, like most electronic equipment, require a clean, stable power source. Voltage irregularities such as surges, drops, and interruptions can affect the operation of your equipment and, in severe cases, damage certain components. - Page 11 CONNECTOR/PIN CONNECTOR TYPE CONNECTOR/PIN LABEL SIGNAL NAME NUMBER BNC (female) VIDEO (J1) Video output VIDEO TERMINAL BLOCK POWER (TB1) TB1-1 TB1-2 Neutral TB1-3 No connection RJ-45 ALARM (J2) J2-1 ALARM1 Alarm input 1 J2-2 Ground VSSA J2-3 Alarm input 2 ALARM2 J2-4 Ground...
-
Page 12: Operation
Operation When power is applied to the Camera Drive, it will boot up through a diagnostic routine and view the currently selected scene. Refer to the Surveyor2000 Programming Manual XX034 for details on setup and operation. Maintenance The S2000-MSH-HHB Camera Dome requires no scheduled maintenance except for the occasional cleaning of the Lower Dome. -
Page 13: Shipping Instructions
Shipping Instructions Use the following procedure when returning a unit to the factory: 1. Call or write Vicon for a Return Authorization (R.A.) at one of the locations listed below. Record the name of the Vicon employee who issued the R.A. -
Page 14: Cable Recommendations
Cable Recommendations Caution: Careful selection of proper cable is essential to obtain the best performance from this equipment. Vicon assumes no responsibility for poor performance when cables other than those recommended, or equivalent, are installed. In all cases, coaxial cable impedance should be 75 ohms. -
Page 15: Twisted-Pair Cable
Twisted-Pair Cable Caution: Careful selection of proper cable is essential to obtain the best performance. Vicon assumes no responsibility for poor performance when cables other than the recommended types, or equivalent, are used. Materials Use a pure copper stranded conductor with or without a tin-plating to obtain a low DC resistance. Do not use cable with either steel or aluminum stranded conductor because they do not transfer signals effectively for long distances. -
Page 16: Technical Information
Technical Information ELECTRICAL (S2000-MSH Housing and Surveyor2000 Camera/Drive) Drive Type: Electrical motorized pan and tilt, electronic control. Camera Types: Units available in monochrome (EIA/CCIR) and color (NTSC/ PAL). Input Voltage: 22 - 34 VAC, 28 VAC nominal. Use the S28PS-HD power supply. - Page 17 Fuse: Communications/Power Supply Board: F1: 2AG, 1.6 A 250 VAC, slo-blo. F2: 2AG, 2.5 A 250 VAC, slo-blo. Housing: 5 x 20mm, 4 A, slo-blo Radio Frequency Emission Rating: FCC Class A. OPERATIONAL (Surveyor2000 Camera/Drive only) Pan Speed: Variable, 0.25 - 250°/ sec. Autopan Speed: Variable, 3 - 45°/ sec.
- Page 18 RS-422 or RS-485 protocol selectable via DIP switch 2. Communication is simplex or half duplex operation at 4800, 9600 or 19,200 baud or Vicon’s enhanced Vicoax II protocol (superimposed data on composite video signal) automatically detected upon power-up. RS-485 protocol utilizes full tri-state outputs for daisy chain capability.
- Page 19 Weight: S2000-MSH-HHB: 11.5 lb (5.2 kg). 15 lb (6.8 kg) with Surveyor2000 included. S2000-MSH-WM: 11.75 lb (5.3 kg). S2000-MSH-CM: 9.5 lb (4.3 kg). Construction: Housing: 13 gauge (0.089 in./23 mm thick) welded steel. Mounts: 0.19-in. (4.8-mm) thick steel. Finish: Paint. Color: Gray.
- Page 20 ENVIRONMENTAL (S2000-MSH Housing only) Operating Temperature Range: Outdoors with sun exposure (with Heater/Blower Assembly): -40 to 105°F (-40 to 40.5°C). Outdoors with sun exposure (with Heater/Blower Assembly and Sunshield): -40 to 122°F (-40 to 50°C). Note: The Sunshield cannot be used with the S2000-MSH-CM Ceiling Mount Bracket. Operating Humidity Range: 100% relative humidity.
- Page 21 NOTES Technical Information • 17 XX077-50-00 Rev 1202 S2000-MSH-HHB Heater/Blower Version...
- Page 22 Vicon Industries Inc. Corporate Headquarters 89 Arkay Drive Hauppauge, New York 11788 631-952-CCTV (2288) 800-645-9116 Fax: 631-951-CCTV (2288) Vicon Europe Headquarters Brunel Way Fareham, PO15 5TX United Kingdom +44 (0) 1489 566300 Fax: +44 (0) 1489 566322 Brussels Office Planet II - Unit E...
