Installing The Front Bezel; Removing And Installing The System Cover - Dell PowerEdge R530 Owner's Manual

1. bezel lock

Installing the front bezel

1. Hook the right end of the bezel onto the chassis.
2. Fit the free end of the bezel onto the system.
3. Lock the bezel.
Figure 9. Removing and installing the front bezel
1. release latch
3. front bezel

Removing and installing the system cover

WARNING: Whenever you need to lift the system, get others to assist you. To avoid injury, do not
attempt to lift the system by yourself.
WARNING: Installing or removing the system cover when the system is on may expose you to a
risk of electric shock.
CAUTION: Many repairs may only be done by a certified service technician. You should only
perform troubleshooting and simple repairs as authorized in your product documentation, or as
directed by the online or telephone service and support team. Damage due to servicing that is
not authorized by Dell is not covered by your warranty. Read and follow the safety instructions
that came with the product.
CAUTION: Do not operate the system without the cover for a duration exceeding five minutes.
2. front bezel
2. keylock
45
