FPC-7200 Series
Fanless Intel® Atom™ D2700 Box PC
User's Manual
Version 1.0
P/N: 4012720000100P
2012.03

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FPC-7200 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Arbor Technology FPC-7200 Series

Summary of Contents for Arbor Technology FPC-7200 Series

  • Page 1 FPC-7200 Series Fanless Intel® Atom™ D2700 Box PC User’s Manual Version 1.0 P/N: 4012720000100P 2012.03...
  • Page 2 This page is intentionally left blank.

  • Page 3: Table Of Contents

    Index Contents Chapter 1 - General Information ..............1 1.1 Introduction .................. 2 1.2 Packing List .................. 3 1.3 Ordering Information ..............3 1.4 The Installation Paths of CD Driver ..........4 1.5 Specifications ................5 1.6 Dimensions ................... 7 1.7 Locating Controls and Connectors ..........
  • Page 4 Index 3.3 Hard Disk Drive & Riser Card Installation ........ 29 3.3.1 Removing Bottom Cover ..........29 3.3.2 Installing Hard Disk Drive ..........29 3.3.2 Installing Riser Card ............31 3.4 Wall Mounting (Optional) ............32 3.5 Grounding the Box PC ............... 32 3.6 Wiring the DC-Input Power Source ..........

  • Page 5: Copyright Notice

    This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This kind of cable is available from ARBOR. Please contact your local supplier for ordering information.
  • Page 6 SVHC / REACH To minimize the environmental impact and take more responsibility to the earth we live, Arbor hereby confirms all products comply with the restriction of SVHC (Substances of Very High Concern) in (EC) 1907/2006 (REACH --Reg- istration, Evaluation, Authorization, and Restriction of Chemicals) regulated by the European Union.

  • Page 7: Important Safety Instructions

    Important Safety Instructions Read these safety instructions carefully 1. Read all cautions and warnings on the equipment. 2. Place this equipment on a reliable surface when installing. Dropping it or letting it fall may cause damage 3. Make sure the correct voltage is connected to the equipment. 4.

  • Page 8: Replacing The Lithium Battery

    Technical Support If you have any technical difficulties, please consult the user’s manual first ftp://ftp.arbor.com.tw/pub/manual Please do not hesitate to call or e-mail our customer service when you still can- not find out the answer.
  • Page 9 Warranty This product is warranted to be in good working order for a period of one year from the date of purchase. Should this product fail to be in good working order at any time during this period, we will, at our option, replace or repair it at no additional charge except as set forth in the following terms.
  • Page 10 This page is intentionally left blank. - vi -...

  • Page 11: Chapter 1 - General Information

    General Information Chapter 1 General Information - 1 -...

  • Page 12: Introduction

    General Information 1.1 Introduction The Box PC, FPC-7200 is targeted at many different application fields. By adopting it, you can pinpoint specific markets, such as Thin Client, KIOSK, information booth, GSM Server, environment-critical and space-critical applications. • All-In-One Platform The CPU, DRAM and even software are integrated to provide a plug- and-play machine.

  • Page 13: Packing List

    General Information 1.2 Packing List After opening the package, carefully inspect the contents. If any of the items is missing or appears damaged, please contact with your local dealer or distributor. The package should contain the following items: FPC-7200 Box PC Accessory Box (Driver CD/User’s Manual/Screws/Cable/Terminal Block)

  • Page 14: The Installation Paths Of Cd Driver

    General Information Optional Configuration (Configure to Order Service) SSD-25080 Intel® 2.5” 80GB SATAII SSD kit HSUPA-3500 HSPA+ 3.75G module kit w/ 2dBi HSPA+ antenna & 25cm internal wiring WiFi-3500 802.11 b/g/n WiFi module kit w/ 2dBi WiFi antenna & 15cm internal wiring ML-3C-2G Single Side DDR3-2GB Long DIMM Kit Note: There is only one mini-card socket, which sports either HSUPA-3500 or...

  • Page 15: Specifications

    General Information 1.5 Specifications System Kernel Soldered Onboard Intel® Atom D2700 2.13GHz Processor processor BIOS AMI Flash BIOS Chipset Intel® NM10 PCH Graphics Integrated Intel® GMA3150 2 x 240-pin Dual-channels DDR3 Long-DIMM System Memory Sockets up to 4GB at 800/1066MHz Serial ATA 1 x Serial ATA port with 300MB/s HDD transfer rate Ethernet...
  • Page 16 General Information Qualification Class A certified Certified Environmental Operating Temp. -20 ~ 55ºC (-4 ~ 131ºF), ambience w/ air flow Storage Temp. -40 ~ 85ºC (-40 ~ 185ºF) Relative Humidity 10 ~ 95% @ 40 C (non-condensing) Vibration 3 Grms/5 ~ 500 Hz/random operation •...

  • Page 17: Dimensions

    General Information 1.6 Dimensions UNC #6-32 6.00 207.00 219.00 195.00 - 7 -...

  • Page 18: Locating Controls And Connectors

    General Information 1.7 Locating Controls and Connectors Please take a moment to identify those controls and connectors shown in the following figures. Front Panel Antenna Connector KB/MS Connectors Power On/Off USB Ports CFast & SIM Card Slots' Cover-door Rear Panel Line-out DVI-I COM2...

  • Page 19: Dvi-I/Dvi-D Video Outputs

    General Information 1.8.1 DVI-I/DVI-D Video Outputs FPC-7200 is equipped with two video outputs—one DVI-I and one DVI-D. DVI is a popular form of video interface technology made to maximize the quality of flat panel LCD monitors and modern video graphics cards. DVI-D cables are used for direct digital connections between source video (namely, video cards) and LCD monitors.

  • Page 20: Lan Ports

    General Information 1.8.3 LAN Ports FPC-7200 provides two Realtek RL8111 10/100/1000 Base-T Ethernet (RJ- 45) interface. For network connection, follow the instructions below: 1. Turn off the BOX PC system and the Ethernet hub. 2. Plug one cable end from a 10/100/1000Base-T hub in the system's RJ-45 jack.

  • Page 21: Keyboard And Mouse

    General Information Note that for many of these devices, you will first have to install proper device drivers before they can be recognized by the system. 1.8.5 Keyboard and Mouse FPC-7200 has two PS/2 keyboard/mouse connectors located at the front panel.

  • Page 22: Dc Power Input And Power On/Off Button

    General Information 1.8.8 DC Power Input and Power ON/OFF Button For DC power input, the computer is equipped with a 4-pin terminal block receptacle on the rear panel. The “S/W” button located on the front panel is used to power ON/OFF the computer. See the figures below. Front Panel Rear Panel - 12 -...

  • Page 23: Chapter 2 - The Engine Of Fpc-7200

    The Engine of FPC-7200 Chapter 2 The Engine of FPC-7200 - 13 -...

  • Page 24: Board Layout

    The Engine of FPC-7200 2.1 Board Layout The engine of FPC-7200 is FMB-i2500. RSTB1 FAN2 DIO1 JBAT1 FAN1 - 14 -...

  • Page 25: Jumpers And Connectors

    The Engine of FPC-7200 2.2 Jumpers and Connectors 2.2.1 Jumpers & Connectors List Jumpers Label Function JBAT1 Clear CMOS Setting RS485 AUTOFLOW Selector COM3, COM4 PORT RS232/485 MODE Selector COM3 PORT RS232/485 MODE Selector COM4 PORT RS232/485 MODE Selector Connectors Label Function DIO1...

  • Page 26: Jumper Setting

    The Engine of FPC-7200 2.2.2 Jumper Setting JBAT1: Clear CMOS Setting (1) Connector type: 2.54mm pitch 1x3-pin header. Description Keep CMOS (Default) Clear CMOS JP1: RS485 AUTOFLOW Selector (2) Connector type: Onboard 1x3-pin 2.00mm pin header. Description RS485 AUTOFLOW Disable (Default) RS485 AUTOFLOW Enable JP2: COM3, COM4 PORT RS232/485 MODE Selector (3) Connector type: Onboard 2x8-pin 1.27mm pin header.

  • Page 27: Jp3: Com3 Port Rs232/485 Mode Selector

    9 11 13 15 8 10 12 14 16 8 10 12 14 16 The Engine of FPC-7200 9 11 13 15 9 11 13 15 8 10 12 14 16 8 10 12 14 16 8 10 12 14 16 9 11 13 15 9 11 13 15 9 11 13 15...

  • Page 28: Pin Assignments For Connectors

    The Engine of FPC-7200 2.2.3 Pin Assignments for Connectors DIO1: Digital I/O Box Header (6) Connector type: Onboard 2.54mm pitch 16-pin BOX header. Description Description DIO3 DIO4 DIO1 DIO5 DIO0 DIO6 DIO2 DIO7 VCC5 VCC5 15 16 VCC5 GND_DIO GND_DIO BZ1: Buzzer Pin Header (7) Connector type: Onboard 2.54mm pitch 2-pin header.

  • Page 29: Rstb1: Reset Button Pin Header

    The Engine of FPC-7200 RSTB1: Reset Button Pin Header (9) Connector type: Onboard 2.54mm pitch 2-pin header. (for debug use only) Description SYS_RESET# FAN1-2: FAN Connectors (10-11) Connector type: Onboard 3-pin wafer connector. Description +12V Fan CTL - 19 -...
  • Page 30 This page is intentionally left blank. - 20 -...

  • Page 31: Chapter 3 - Installation And Maintenance

    Installation and Maintenance Chapter 3 Installation and Maintenance - 21 -...

  • Page 32: Memory & Mini-Card Installation

    Installation and Maintenance 3.1 Memory & Mini-card Installation FPC-7200 is designed to be modular, slim and lightweight for easier maintenance. The following sections describe simple hardware installations. 3.1.1 Removing Top Cover 1. Locate the six screws which secure the top cover. 2.

  • Page 33: Installing Memory Module

    Installation and Maintenance 3.1.2 Installing Memory Module To install the Memory module, locate the Memory DIMM slot on the board and perform as below: 1. Hold the Memory module so that the key of the Memory module align with those on the Memory DIMM slot. 2.

  • Page 34: Installing Hsupa/Wifi Module

    Installation and Maintenance 3.1.3 Installing HSUPA/WiFi Module 1. Locate Mini-card socket, insert the HSUPA module into it at a slanted angle as shown in the picture. Be sure to align the notch on module with the break on socket. And then, secure two screws to fasten the module. 2.
  • Page 35 Installation and Maintenance 3. Push the plastic plug outwards to remove it, so that another end of RF cable, which is a SMA connector jack, can penetrate through antenna hole located on front panel of the chassis. Retain the plastic plug for later use. When you try to penetrate the SMA connector jack through antenna hole, be sure to align the flat sides, or it'll get stuck.
  • Page 36 Installation and Maintenance 4. Mount a round washer into the SMA connector jack from outside before securing another nut into it. 5. At the end, screw antenna into the SMA connector jack and adjust antenna angle for better signal. - 26 -...

  • Page 37: How To Access Cfast/Sim Card

    Installation and Maintenance 3.2 How to Access CFast/SIM Card 1. Make sure you have turned off the power before inserting or ejecting the CFast card (if OS is installed on CFast card). 2. Locate the CFast/SIM card door on the front panel. 3.
  • Page 38 Installation and Maintenance 5. To remove the CFast/SIM card, push that inwards to pop it out. - 28 -...

  • Page 39: Hard Disk Drive & Riser Card Installation

    Installation and Maintenance 3.3 Hard Disk Drive & Riser Card Installation 3.3.1 Removing Bottom Cover 1. Carefully place the Box PC upside down. Unscrew the six screws securing the bottom cover. 2. Use screwdriver to remove the bottom cover screws and retain them safely for later use.
  • Page 40 Installation and Maintenance 3. Carefully put the 2.5" HDD into the HDD Holder Bracket and screw its four corners. Be sure to align its connector with HDD socket. 4. Secure bracket on main unit. 2.5” HDD - 30 -...

  • Page 41: Installing Riser Card

    Installation and Maintenance 3.3.2 Installing Riser Card 1. Unscrew riser card bracket with screwdriver. Take the bracket off and keep it for later use. 2. Plug your desired PCIe x1 card into appropriate place and secure it. - 31 -...

  • Page 42: Wall Mounting (Optional)

    Installation and Maintenance 3.4 Wall Mounting (Optional) 1. Place the main unit upside down on a flat surface and locate the 8 screw holes on the bottom cover. 2. Place the wall-mount brackets horizontally along bottom cover edges, so that the screw holes are aligned with the ones of the bottom cover. 3.

  • Page 43: Wiring The Dc-Input Power Source

    Installation and Maintenance 3.6 Wiring the DC-Input Power Source Only trained and qualified personnel are allowed to install Warning or replace this equipment. Follow the instructions below for connecting the computer to a DC-input power source. 1. Before wiring, make sure the power source is disconnected. 2.
  • Page 44 This page is intentionally left blank. - 34 -...

  • Page 45: Chapter 4 - Driver & Ap

    Driver & AP Chapter 4 Driver & AP - 35 -...

  • Page 46: Preliminary Work

    Driver & AP 4.1 Preliminary work After everything mentioned before is settled down, and now, you need to install the necessary drivers and the application so that the box PC’s functions can operate normally. The following instructions take Windows 7 as the exemplary OS. Different OS may vary slightly, but generally speaking, they are almost the same.

  • Page 47: Drivers

    Driver & AP 4.2 Drivers 4.2.1 CHIPSET 1. Execute “infinst_autol.exe” in the suggested path (\CHIPSET\INF 9.2.0.1030). Always click Yes whenever Windows 7 inquires you “Do you want to allow the following programs to make changes to this computer?” 2. Click “Next >”. - 37 -...
  • Page 48 Driver & AP 3. Wait for extracting. 4. Click “Yes >”. - 38 -...
  • Page 49 Driver & AP 5. Click “Next >”. 6. Click “Finish >”. - 39 -...

  • Page 50: Vga

    Driver & AP 4.2.2 VGA 1. Execute “Setup.exe” in the suggested path (\GRAPHICS\INTEL_ WIN7_32\2230). 2. Click “Next >”. - 40 -...
  • Page 51 Driver & AP 3. Click “Yes >”. 4. Click “Next >”. - 41 -...
  • Page 52 Driver & AP 5. Wait for the process. 6. Click “Next >”. - 42 -...

  • Page 53: Audio

    Driver & AP 7. Click “Yes >” to restart computer. 4.2.3 Audio 1. Execute “Vista_Win7_R261-32_64.exe” in the suggested path (\AUDIO\ REALTEK_HD\Vista_Win7_R261-32_64 bit). - 43 -...
  • Page 54 Driver & AP 2. Wait for extracting. 3. Keep waiting. - 44 -...
  • Page 55 Driver & AP 4. Click “Next >”. 5. Wait for the process. - 45 -...

  • Page 56: Lan

    Driver & AP 6. Click “Yes >” to restart computer. 4.2.4 LAN 1. Execute “setup.exe” in the suggested path (\ETHERNET\ REALTEK\8111B_Win7_7046). - 46 -...
  • Page 57 Driver & AP 2. Click “Next >”. 3. Click “Install >”. - 47 -...
  • Page 58 Driver & AP 4. Wait for the process. 5. Click “Finish >”. - 48 -...

  • Page 59: Chapter 5 - Bios

    BIOS Chapter 5 BIOS - 49 -...

  • Page 60: Bios Main Setup

    BIOS 5.1 BIOS Main Setup The AMI BIOS provides a setup utility program for specifying the system configurations and settings which are stored in the BIOS ROM of the system. When you turn on the computer, the AMI BIOS is immediately activated. After you have entered the setup utility, use the left/right arrow keys to highlight a particular configuration screen from the top menu bar or use the down arrow key to access and configure the information below.

  • Page 61: Advanced Settings

    BIOS System Time Set the system time. The time format is: Hour : 00 to 23 Minute : 00 to 59 Second : 00 to 59 5.2 Advanced Settings ACPI Settings Set system ACPI parameters. CPU Configuration This section is used to configure the CPU. It will also display detected CPU information.

  • Page 62: Acpi Settings

    BIOS 5.2.1 ACPI Settings Enable ACPI Auto Configuration This item allows you to enable/disable ACPI (Advanced Configuration and Power Interface) Auto Configuration. Setting: Disabled (Default), Enabled. Enable Hibernation Enable or disable the Hibernation function. This allows the operating system to control power to the computer’s disk, monitor and peripheral devices. Setting: Enabled (Default), Disabled ACPI Sleep State This item allows you to select ACPI Sleep State.

  • Page 63: Cpu Configuration

    BIOS 5.2.2 CPU Configuration The CPU Configuration setup screen varies depending on the installed processor. Hyper-threading This item is used to enable or disable the processor’s Hyper-threading feature. Enabled for Windows XP and Linux (OS optimized for Hyper-threading Technology) and disabled for other OS (OS not optimized for Hyper-threading Technology).

  • Page 64: Ide Configuration

    BIOS 5.2.3 IDE Configuration It allows you to select the operation mode for SATA controller. SATA Controller(s) SATA Ports (0-3) Device Names if Present and Enabled. Configure SATA as Select a configuration for SATA controller. Port0 Speed Limit Select Port0 AHCI Speed Limit. SATA Port 0/1 Enable or Disable SATA Port.

  • Page 65: Usb Configuration

    BIOS 5.2.4 USB Configuration Legacy USB Support Enables support for legacy USB. AUTO option disables legacy support if no USB devices are connected. DISABLE option will keep USB devices avail- able only for EFI applications. EHCI Hand-Off Allows you to enable support for operating systems without an EHCI hand-off feature.

  • Page 66: F81866 Super Io Configuration

    BIOS 5.2.5 F81866 Super IO Configuration Serial Port 0/1/2/3 Configuration Set Parameters of Serial Port 0/1/2/3 (COMA). Power On After Power Fail Specify what state to go to when power is re-applied after a power failure. Serial Port Enable or Disable Serial Port (COM). Change Settings Select an optimal setting for Super IO device.

  • Page 67: F81866 H/W Monitor

    BIOS 5.2.6 F81866 H/W Monitor PC Health Status The hardware monitor menu shows the operating temperature, fan speeds and system voltages. - 57 -...

  • Page 68: Chipset Settings

    BIOS 5.3 Chipset Settings This submenu allows you to configure the specific features of the chipset installed on your system. The chipset manage bus speeds and access to system memory resources, such as DRAM. It also coordinates communications with the PCI bus. Notice Beware of that setting inappropriate values in items of this menu may cause system to malfunction.

  • Page 69: Host Bridge

    BIOS 5.3.1 Host Bridge Auto Disable IGD Auto disable IGD upon external GFX detected. IGFX - Boot Type Select the Video Device which will be activated during POST. This has no ef- fect if external graphics present. - 59 -...

  • Page 70: South Bridge

    BIOS 5.3.2 South Bridge High Precision Timer Enable or Disable the High Precision Event Timer. SLP_S4 Assertion Width Select a minimum assertion width of the SLP_S4# signal. - 60 -...

  • Page 71: Boot Settings

    BIOS 5.4 Boot Settings The Boot menu items allow you to change the system boot options. Bootup Numlock State This item determines if the Numlock key is active or inactive at system start-up time. Quiet Boot This allows you to select the screen display when the system boots. Fast Boot During the POST (Power On Self Test), the BIOS checks the hardware devices and counts the system memory.

  • Page 72: Security

    BIOS 5.5 Security Administrator Password Use the Administrator Password to set or change a administrator password. ENTER PASSWORD Type the password, up to eight characters in length, and press <Enter>. The password typed now will clear any previously entered password from CMOS memory.

  • Page 73: Save & Exit

    BIOS You can determine when the password is required within the BIOS Features Setup Menu and its Security option. If the Security option is set to “System”, the password will be required both at boot and at entry to Setup. If it’s set to “Setup”, prompting only occurs when trying to enter Setup.
  • Page 74 BIOS Restore Defaults Restore system to settings previously stored by Save as User Defaults. Pressing <Enter> on this item and it asks for confirmation prior to executing this command. Boot Override This group of functions includes a list of tokens, each of them corresponding to one device within the boot order.

  • Page 75: Appendix

    Appendix Appendix - 65 -...

  • Page 76: Appendix A: I/O Port Address Map

    Appendix Appendix A: I/O Port Address Map Each peripheral device in the system is assigned a set of I/O port addresses which also becomes the identity of the device. The following table lists the I/O port addresses used. Address Device Description 00000000-0000001F Direct memory access controller 00000000-00000CF7...
  • Page 77 Appendix 00000070-00000077 System CMOS/real time clock 00000072-0000007F Motherboard resources 00000080-00000080 Motherboard resources 00000080-00000080 Motherboard resources 00000081-00000091 Direct memory access controller 00000084-00000086 Motherboard resources 00000088-00000088 Motherboard resources 0000008C-0000008E Motherboard resources 00000090-0000009F Motherboard resources 00000092-00000092 Motherboard resources 00000093-0000009F Direct memory access controller 000000A0-000000A1 Programmable interrupt controller 000000A2-000000BF...
  • Page 78 Appendix 00000400-0000047F Motherboard resources 00000400-0000047F Motherboard resources 000004D0-000004D1 Motherboard resources 000004D0-000004D1 Programmable interrupt controller 00000500-0000053F Motherboard resources 00000500-0000057F Motherboard resources 00000600-0000061F Motherboard resources 00000680-0000069F Motherboard resources 000006A0-000006AF Motherboard resources 000006B0-000006EF Motherboard resources 00000A00-00000A0F Motherboard resources 00000A10-00000A1F Motherboard resources 00000D00-0000FFFF PCI bus 00001000-0000100F Motherboard resources 0000D000-0000D0FF...
  • Page 79 Appendix 0000F0D0-0000F0D7 Standard AHCI 1.0 Serial ATA Controller 0000F0E0-0000F0E3 Standard AHCI 1.0 Serial ATA Controller 0000F0F0-0000F0F7 Standard AHCI 1.0 Serial ATA Controller 0000F100-0000F107 Intel(R) Graphics Media Accelerator 3600 Series 0000FFFF-0000FFFF Motherboard resources 0000FFFF-0000FFFF Motherboard resources - 69 -...

  • Page 80: Appendix B: Interrupt Request Lines (Irq)

    Appendix Appendix B: Interrupt Request Lines (IRQ) Peripheral devices use interrupt request lines to notify CPU for the service required. The following table shows the IRQ used by the devices on board. Level Function IRQ 00 System timer IRQ 01 Standard PS / 2 Keyboard IRQ 03 Communications Port (COM2)
  • Page 81 Appendix IRQ 119 Microsoft ACPI-Compliant System IRQ 12 Microsoft PS/2 Mouse IRQ 120 Microsoft ACPI-Compliant System IRQ 121 Microsoft ACPI-Compliant System IRQ 122 Microsoft ACPI-Compliant System IRQ 123 Microsoft ACPI-Compliant System IRQ 124 Microsoft ACPI-Compliant System IRQ 125 Microsoft ACPI-Compliant System IRQ 126 Microsoft ACPI-Compliant System IRQ 127...
  • Page 82 Appendix IRQ 148 Microsoft ACPI-Compliant System IRQ 149 Microsoft ACPI-Compliant System IRQ 150 Microsoft ACPI-Compliant System IRQ 151 Microsoft ACPI-Compliant System IRQ 152 Microsoft ACPI-Compliant System IRQ 153 Microsoft ACPI-Compliant System IRQ 154 Microsoft ACPI-Compliant System IRQ 155 Microsoft ACPI-Compliant System IRQ 156 Microsoft ACPI-Compliant System IRQ 157...
  • Page 83 Appendix IRQ 175 Microsoft ACPI-Compliant System IRQ 176 Microsoft ACPI-Compliant System IRQ 177 Microsoft ACPI-Compliant System IRQ 178 Microsoft ACPI-Compliant System IRQ 179 Microsoft ACPI-Compliant System IRQ 18 Intel(R) N10/ICH7 Family USB Universal Host Controller - 27CA IRQ 180 Microsoft ACPI-Compliant System IRQ 181 Microsoft ACPI-Compliant System IRQ 182...
  • Page 84 Appendix IRQ 84 Microsoft ACPI-Compliant System IRQ 85 Microsoft ACPI-Compliant System IRQ 86 Microsoft ACPI-Compliant System IRQ 87 Microsoft ACPI-Compliant System IRQ 88 Microsoft ACPI-Compliant System IRQ 89 Microsoft ACPI-Compliant System IRQ 90 Microsoft ACPI-Compliant System IRQ 91 Microsoft ACPI-Compliant System IRQ 92 Microsoft ACPI-Compliant System IRQ 93...

  • Page 85: Appendix C: Memory Mapping

    Appendix Appendix C: Memory Mapping Address Device Description 00000000-00000FFF Motherboard resources 00000000-00000FFF Motherboard resources 00000000-00003FFF Motherboard resources 000A0000-000BFFFF PCI bus 000A0000-000BFFFF Intel(R) Graphics Media Accelerator 3600 Series 000C0000-000DFFFF PCI bus 000E0000-000EFFFF PCI bus 000F0000-000FFFFF PCI bus BF800000-BFFFFFFF PCI bus C0000000-FEBFFFFF PCI bus DFC00000-DFCFFFFF Intel(R) Graphics Media Accelerator 3600 Series...
  • Page 86 Appendix FED20000-FED8FFFF Motherboard resources FED45000-FED8FFFF Motherboard resources FEE00000-FEE00FFF Motherboard resources FF000000-FFFFFFFF Intel(R) 82802 Firmware Hub Device FF000000-FFFFFFFF Intel(R) 82802 Firmware Hub Device FFE00000-FFFFFFFF Motherboard resources - 76 -...

  • Page 87: Appendix D: Digital I/O Setting

    Appendix Appendix D: Digital I/O Setting Digital I/O can read from or write to a line or an entire digital port, which is a col- lection of lines. This mechanism can be used to meet user’s various applica- tions such as industrial automation, customized circuit, and laboratory testing. The source code below written in C is the applicable sample for programming.
  • Page 88 Appendix Index 41, GPIO3x Output Data value SMB_Byte_WRITE(SMB_PORT_AD,SMB_DEVICE_ADD,0x41,0x00); delay(10); //---------------------------------------------------------------------------- unsigned char SMB_Byte_READ (int SMPORT, int DeviceID, int REG_IN- DEX) unsigned char SMB_R; outportb(SMPORT+02, 0x00); /* clear */ outportb(SMPORT+00, 0xff); /* clear */ delay(10); outportb(SMPORT+04, DeviceID+1); /* clear */ outportb(SMPORT+03, REG_INDEX); /* clear */ outportb(SMPORT+02, 0x48);...

  • Page 89: Appendix E: Watchdog Timer (Wdt) Setting

    Appendix Appendix E: Watchdog Timer (WDT) Setting WDT is widely applied to industry computers to monitor activities of CPU. The programmed application triggers WDT with adequate timer setting depending on its requirement. Before WDT counts down to zero, the functional system will reset the counter.
