Installing the System

Installing the Wheel Kit

Installing the Wheel Kit
Compare the packing list (Table 2-1) with the contents of the wheel kit before beginning the installation. For
a more updated list of part numbers, go to the HP Part Surfer web site at: http://www.partsurfer.hp.com.
Table 2-1 Wheel Kit Packing List
Part Number
A9904-04002 Caster cover
A9904-04007 Right side cover
A9904-04008 Left side cover
A9904-04009 Top cover
A6093-04082 Right front caster assembly
A6093-04083 Right rear caster assembly
A6093-04084 Left front caster assembly
A6093-04085 Left rear caster assembly
0515-2478 M4 x 0.7 8mm T15 steel zinc
machine screw (used to attach
each caster to the chassis)
A6093-44013 Plywood unloading ramp
Not Applicable Phillips head wood screw (used to
attach the ramp to the pallet)
Tools Required for Installation
Use the following tools to perform the wheel kit installation:
• Diagonal side cutters
• Safety glasses
• Torx screwdriver with T-15 bit
• Phillips head screwdriver
WARNING Wear protective glasses while cutting the plastic bands around the shipping
container. These bands are under tension. When cut, they can spring back and cause
serious eye injury.
48
Description Quantity
2
1
1
1
1
1
1
1
8
1
2
Chapter 2
