Lifting the Server Cabinet Manually

Lifting the Server Cabinet Manually
Use this procedure only if no HP approved lift is available.
CAUTION This procedure must only be performed by four qualified HP Service Personnel utilizing proper
lifting techniques and procedures.
Step 1. Follow the instructions on the outside of the service packaging to remove the banding and
cardboard top from the server pallet.
Step 2. Reduce the weight by removing all bulk power supplies and cell boards. Place each on an ESD
approved surface.
CAUTION
Step 3. Locate the four positioning handles on the sides of the system. They are colored blue and located
close to each base corner of the unit.
Step 4. Ensure that the vertical support brackets are in the position so that they rest on the slides when
the server is lowered to the rack slides. There are two brackets on each side of the server chassis.
Step 5. Unfold the handles so that they are extended out from the unit. The server is now ready for manual
lifting by the four qualified HP Service Personnel.
Step 6. Lift the server into place and secure as required.
Step 7. After the server is secured, reinstall the previously removed cell boards and bulk power supplies.
44
System damage can occur through improper removal and reinstallation of bulk
power supplies and cell boards. Refer to Chapter 6, "Removal and Replacement" for
the correct procedures to remove and reinstall these components.
