Installing the System
Receiving and Inspecting the Server Cabinet
NOTE
Figure 2-2 Removing the Shipping Bolts and Plastic Cover
40
Figure 2-2 shows one ramp attached to the pallet on either side of the cabinet with
each ramp secured to the pallet using two bolts. In an alternate configuration, the
ramps are secured together on one side of the cabinet with one bolt.
Chapter 2
