Altronix eBridge1CT Installation Manual page 3

Single IP camera shown with composite video option:
Fig. 2
To Monitor
NVR Network
Video Server
(Head End
Equipment)
Composite
Video
Cable
Ethernet Switch
eBridge1CT
eBridge1CR
eBridge1CR
Input: 12VDC/275mA, 24VDC/110mA,
16VAC/375mA, 24VAC/200mA.
Blue LED Coax link status.
RJ45 LEDs Yellow - Speed
Green - Activity
Green LED Power
Z1409
I.T.E. 43KC
www.altronix.com
Up to 328 ft.
eBridge1CT
eBridge1CT
Input: 12VDC/275mA, 24VDC/110mA,
16VAC/375mA, 24VAC/200mA.
Blue LED Coax link status.
RJ45 LEDs Yellow - Speed
Green - Activity
Green LED Power
Z1409
Up to
1500 ft.
Fig. 2a
Mounting Hole
IP Camera
(external power
required).
Comp. Video
Cable
Coax
Structured Cable
Up to 328 ft.
Composite Video Cable
- 3 -
