PLUS
eBridge100STR
EoC and PoE/PoE+ Adapter Kit
eBridge100RM - EoC and PoE/PoE+ Receiver
eBridge100ST - EoC and PoE/PoE+ Hardened Transceiver
Installation Guide
I.T.E. 43KC
More than just power.
Rev. 111014
TM
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
Advertisement
Related Manuals for Altronix eBridge100STR
Summary of Contents for Altronix eBridge100STR
- Page 1 PLUS eBridge100STR EoC and PoE/PoE+ Adapter Kit eBridge100RM - EoC and PoE/PoE+ Receiver eBridge100ST - EoC and PoE/PoE+ Hardened Transceiver Installation Guide I.T.E. 43KC More than just power. Rev. 111014 Installing Company: _______________ Service Rep. Name: __________________________________ Address: _____________________________________________ Phone #: __________________...
- Page 2 100Mbps full duplex and power over Coax cable in a PoE+ compliant format. The eBridge100RM is powered via a PoE midspan, such as the Altronix Netway series, or by an endspan. The receiver passes the PoE(+) compliant power over cable to the eBridge100ST transceiver which in turn passes this power to an enabled IP Camera/ device.
- Page 3 *Note: Caution: once PoE connection is established between eBridge100RM and eBridge100ST, disconnection from eBridge100ST will not disable the PoE output voltage on the eBridge100RM. Although the eBridge100ST can be reconnected, caution should be taken not to connect coax wiring from eBridge100RM to any non-PoE device. eBridge100STR Installation Guide - 3 -...
- Page 4 Power/PoE Class Max. Length (meters) 13W/0 4W/1 6.5W/2 13W/3 Altronix is not responsible for any typographical errors. ––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty MEMBER IIeBridge100STR...
