F
PAGE 14 — DA7000SSA2/SSA2GH GENERATOR• OPERATION AND PARTS MANUAL — REV. #0 (03/26/15)
A
D
G
Figure 1. Dimensions
Table 3. Dimensions
approx. 34.3 in
(870 mm)
Housing
44.9 in
(1140 mm)
approx. 40.4 in
(1025 mm)
Approx. Dry Weight
Approx. Wet Weight
B
E
H
J
K
A B C
29.1 in 7.9 in
(740 mm) (200 mm)
E F G
31.3 in 28.3 in
(795 mm) (720 mm)
I J K
23.2 in 25.6 in
(590 mm) (650 mm)
527 lbs (239 kg)
582 lbs (264 kg)

DIMENSIONS

C
I
L
D
approx. 6.5 in
(165 mm)
H
12.8 in
(325 mm)
L
approx. 17.9 in
(455 mm)
