Compak F10 MASTER CONIC OD Instruction Manual page 23

NOTE: Based on extensive experience and a medium-hard coffee blend, we
recommend replacing the burrs following the quantities in next table:
F8 OD
F10 CONIC OD
F10 MASTER CONIC OD
12.3. Silicon curtain replacement (F8 model)
The silicon curtain ensures consistency in the dose and reduces static electricity.
Located inside the coffee outlet (
1.
Remove the grind regulator control knob (
Allen key No. 2.5.
2. Remove the four screws securing the cover using an Allen key No. 2.5.
3. Remove the four screws fixing the base of aluminum siding, using an Allen key
No. 2.5.
4.
Remove the coffee outlet (
Allen key No. 2.5 At this point, access to the silicon curtain is possible. Replace
the silicon curtain with a new silicon curtain of different thicknesses according
to the needs of each coffee. Simply remove the screw curtain using a #10 Torx
wrench.
22
), it can be replaced by following the steps below:
), by removing the two retaining screws using an
ORIGINAL INSTRUCTIONS | Ref. quality process 002/03 | v. 21/07/2015 | K06315
Steel Red Speed Lucidate
800 Kg
1200 Kg
1200 Kg
) loosening the fixing bolt with an
3500 Kg
7500 Kg
7500 Kg
