This section discusses the confi guration of various operational features of the CR1200 including:
• Settings Lock—Lock the CR1200 to prevent inadvertent changes to the current confi guration.
• Mirror Decoding—Set the CR1200 to read mirror images of codes.
• Adding Prefi xes or Suffi xes—Add prefi x or suffi x strings to the communications packet sent to the host
application.
• Text Commands—Set the CR1200 to accept text commands from the host application.

6.1 - Settings Lock

To lock or unlock the current settings on your reader, read the codes below:
Reader Settings Locked
Note: This feature does not lock the following commands:
• Prefi x and Suffi x programming codes
Clear All CodeXML Rules
• Suffi x Erase/None commands

6.2 - Mirror Decoding

Scan the following codes to enable/disable the mirroring feature:
Mirroring On
Note: The Mirroring feature allows the CR1200 to read codes as they are seen through a mirror (inversed 180°). If the
Mirroring feature is enabled, non-mirrored reading ability will be disabled.
6.3 - Adding Prefi x Settings
Some applications may require specifi c characters be present at the front or back of decode packets sent to the host. The
Add Prefi x and Add Suffi x options allow you to add the characters required by the host application.
Save Settings
Reader Settings Unlocked
Mirroring Off (Default)
C003525_03_CR1200 User Manual 27
