Summary of Contents for Code CR1000
- Page 1 USER MANUAL NORTH AMERICA: ENGLISH CR1000 MANUAL VERSION 06 RELEASE DATE: JUNE 2014 www.codecorp.com Configuration Guide YouTube.com/codecorporation...
-
Page 2: Statement Of Agency Compliance
The software described in this manual may only be used in accordance with the terms of its license agreement. No part of this publication may be reproduced in any form or by any means without written permission from Code Corporation. This includes electronic or mechanical means such as photocopying or recording in information storage and retrieval systems. -
Page 3: Table Of Contents
2.0 - Attaching and Detaching a Cable ..............5 3.0 - Set Up ....................... 5 4.0 - Using a CR1000 Out of a Stand ..............6 5.0 - Using a CR1000 In a Stand ................ 6 6.0 - Reading Ranges ..................6 7.0 - Reader Feedback .................. -
Page 4: Included Items
1.0 - Included if Ordered CR1000 (Model #: CR1011 or CR1021) USB 2.0 Cable RS232 Cable 5VDC Power Supply C005905_06_CR1000_UserManual... -
Page 5: Attaching And Detaching A Cable
2.0 - Attaching and Detaching a Cable 3.0 - Set Up RS232 Plug in Wait 10 seconds 10 Sec. LED will flash Reader will beep C005905_06_CR1000_UserManual... -
Page 6: Using A Cr1000 Out Of A Stand
4.0 - Using a CR1000 5.0 - Using a CR1000 Out of a Stand In a Stand 10 cm 10 cm 6.0 - Reading Ranges CR1000 Performance Test Barcode Min Inches (mm) Max Inches (mm) 3 mil Code 39 3.1” (80 mm) 4.0”... -
Page 7: Reader Feedback
To turn symbologies on or off, scan the symbology barcodes symbologies that are not enabled by default. To turn located in the CR1000 Configuration Guide located on our symbologies on or off, scan the symbology barcodes located in website at www.codecorp.com/files.php. -
Page 8: Reader Id & Firmware Version
Note: Code will periodically release new firmware for CR1000 readers. For information on latest firmware visit our website at www.codecorp.com/codesupport.php. 11.0 - CR1000 Hole Mounting Pattern 34.08 mm NOTE 1: 15.53 mm Locating holes are 2 mm in diameter, hole depth is 1.5 mm. -
Page 9: Cr1000 Overall Dimensions
12.0 - CR1000 Overall Dimensions 2.6" (67 mm) 1.7" (30 mm) 2.2" (52 mm) 13.0 - USB Cable Example with Pinouts CONNECTOR A NAME WIRE COLOR CONNECTOR B NOTES: 24A WG 1. Part to be ROHS and Reach compliant. 28A WG WHITE 2. -
Page 10: Reader Pinouts
Cleaning the CR1000 Window CR1000 window should be clean to allow the best performance of the device. The window is the clear plastic piece inside the head of the reader. Do not touch the window. Your CR1000 uses CMOS technology that is much like a digital camera. A dirty window may stop the CR1000 from reading barcodes. -
Page 11: Warranty
Code’s maximum liability related to its performance, or failure to perform, as described herein shall be limited to the amount paid by Customer for the Code product that is subject to the claim. In no event will either party be liable for any lost profits, lost savings, incidental damage, or other economic consequential damages.
