3.1 - Specifying Feedback

The CR1200 features one LED on the top of the unit. The LED gives visual feedback based on the operation of the
CR1200 (see Table 3.1). The LED may display Red, Amber, or Green. Confi gurable sound and vibration features provide
audible and tactile feedback.
Condition
Successful Power Up
Successful connection with the host via USB
Sucessful decode and data transfer to the
Confi guration Code suffessfully decoded and
processed
Read the following codes to set the beep and vibration modes:
Vibration On / Beep On (Default)
Save Settings
cable
host
Table 3.1 LED Feedback Conditions
Vibrate On / Beep Off
Figure 3.1
Sound/Vibration
1 Beep/Vibration
1 Beep/Vibration
1 Beep/Vibration
2 Beeps/Vibrations
separated by a slight pause
Vibrate Off / Beep On
LED
Sequence:
Amber
Green
Amber
None
Flash Green
Flash Green
C003525_03_CR1200 User Manual 11
