- Page 1 USER MANUAL CR1500 MANUAL VERSION 06 UPDATED: OCTOBER 2022 D030210_06_CR1500_User_Manual...
- Page 2 The software described in this manual may only be used in accordance with the terms of its license agreement. No part of this publication may be reproduced in any form or by any means without written permission from Code Corporation. This includes electronic or mechanical means such as photocopying or recording in information storage and retrieval systems.
-
Page 3: Table Of Contents
13. USB Cable Example with Pinouts ................. 10 14. RS232 Cable Examples with Pinouts ..............10 15. Reader Pinouts ....................10 16. CR1500 Maintenance ..................11 17. Online Resources for the CR1500 ................ 11 18. Contact Code for Support ..................12 18. Warranty ......................12 D030210_06_CR1500_User_Manual... -
Page 4: Cr1500 Readers & Accessories
1. CR1500 Readers & Accessories 1.1 Readers Part Number Description CR1500-K10x Cabled, Light Gray, CodeShield® Level 3 CR1500-K20x Cabled, Dark Gray, CodeShield Level 2 CR1500-L20x CPM Reader, Cabled, Dark Gray, CodeShield Level 2 CR1500-M20x XHD Reader, Cabled, Dark Gray 1.2 Accessories Part Number Description CRA-US2... -
Page 5: Unpacking & Installation
2. Unpacking & Installation 2.1 CR1500 & Cables USB Cable RS232 Cable 5VDC CR1500 Power Supply 2.2 Universal Stand D030210_06_CR1500_User_Manual... -
Page 6: Attaching & Detaching A Cable
3. Attaching & Detaching a Cable 4. Setup Plug In Wait 2 seconds 2 Sec. LED will Flash Reader will beep Reader will vibrate D030210_06_CR1500_User_Manual... -
Page 7: Using A Cr1500 Outside Of A Universal Stand
CR1500-KXXX (standard) CR1500-LXX CR1500-M2XX Min/Max Distance Min/Max Distance Min/Max Distance 3 mil Code 39 3.3” (85 mm)/4.2” (107mm) 0.6” (14 mm) / 1.5” (39 mm) 5.8 mil PDF417 0.4” (9 mm) / 1.7” (44 mm) 7.5 mil Code 39 0.7” (18 mm) / 6.6” (167 mm) 0.9”... -
Page 8: Reader Feedback
Default by Default The following are symbologies that are turned Code barcode readers can read a number of on by default. To turn symbologies on or off, barcode symbologies that are not enabled scan the symbology barcodes in the CR1500 by default. -
Page 9: Reader Id, Firmware Version & License
Number Number (if there is any) <RD><RR MD=”CR1500” /></RD><RD><RR SN=”1060000003” /></RD><RD><FW VS=”1.1.4” /></RD><RD><LC GL=”” /></RD> Note: Code will periodically release new firmware for CR1500 readers. For information on latest firmware please see codecorp.com/products/code-reader-1500. 12. CR1500 Overall Dimensions 77 mm (3.0”) D 132 mm (5.2”) H... -
Page 10: Usb Cable Example With Pinouts
13. USB Cable Example with Pinouts Notes: CONNECTOR A NAME CONNECTOR B 1. Part to be ROHS and Reach compliant. 2. Maximum voltage tolerance = 5V +/- 10% 3. Caution: Exceeding the maximum voltage will void manufacturer warranty. SHELL Connector A Connector B 14. -
Page 11: Cr1500 Maintenance
The Firmware and Software tabs contain downloads for the device. They include: • The latest device firmware • CortexTools3, a Windows utility program to configure your code Reader, create configuration barcodes, update reader firmware, set data parsing rules, load custom JavaScript applications, upload images to your PC and much more •... -
Page 12: Contact Code For Support
Code Support will respond by telephone or email. If it is deemed necessary to return the device to Code for repair, Code Support will provide a Return Authorization (RMA) Number and shipping instructions. Packaging or shipping improperly may result in damage to the device and void the warranty.
