2.2.2 - PS/2 Cable Installation Guide

CR1200 must have a serial number greater than 10050561 and a fi rmware version greater than 4126 to use a PS/2
cable.
1. Power off the computer. If you disconnect the computer's keyboard while it is powered on, your computer will lock up.
2. Attach the the PS/2 cable to the CR1200.
3. If you have a cabled keyboard, detach the keyboard cable from the computer and connect that same connector to the
female connection on the CR1200 PS/2 cable (Figure 1.17).
4. Now connect the male CR1200 PS/2 connector into the keyboard port on the computer (Figure 1.18).
5. Power on the computer. The CR1200 is powered by the PS/2 port and does not require a power supply.
Figure 1.17
Figure 1.18
PS/2 Factory Reset Save Settings
Code does not guarantee compatibility
with all models of computers.
C003525_03_CR1200 User Manual 7
