MEITRACK® GPS Vehicle Tracker
Copyright © 2013 Meitrack Group All rights reserved.
File Name:
MEITRACK MVT100 User Guide
Project:
MVT100
Sub Project:

User Guide

Revision:
V5.0
User Guide
MVT100
Creator:
Cavana Cheung
Creation Date:
Update Date:
Page:
Confidential:
External Documentation
2010-09-09
2013-07-22
- 1 - of 16
- 1 -

Advertisement

Table of Contents
loading

Summary of Contents for MeiTrack MVT100

  • Page 1: User Guide

    MVT100 Creation Date: 2010-09-09 Update Date: 2013-07-22 Sub Project: User Guide Page: - 1 - of 16 Revision: V5.0 Confidential: External Documentation MEITRACK® GPS Vehicle Tracker User Guide MVT100 Copyright © 2013 Meitrack Group All rights reserved. - 1 -...
  • Page 2: Table Of Contents

    Formula for Built-in Battery Voltage and Extenal Power Voltage ........... - 15 - 8.2.6 AD Input (PIN6 Fuel Detection) ....................- 15 - 8.3 Mount the MVT100 unit ..........................- 16 - Copyright © 2013 Meitrack Group All rights reserved. - 2 -...
  • Page 3: Copyright And Disclaimer

    This product is easy to install and is built with an internal GPS and GSM antenna. The MVT100 is both waterproof and dust proof, making it an exceptional GPS tracker for your car, motorcycle, yacht and boat.
  • Page 4: Specifications

    8M Byte Sensor Motion Sensor GSM Frequency GSM 850/900/1800/1900MHz GPS Chip Latest U-blox 6 GPS chipset, 50 channels all-in-view tracking GPS Sensitivity -161dB Positioning Accuracy 10 meters, 2D RMS Copyright © 2013 Meitrack Group All rights reserved. - 4 -...
  • Page 5: Mvt100 And Accessories

    If you require the function of sending an SMS location report to the authorized phone number when it makes a call to the MVT100, please make sure the SIM installed supports displaying caller ID. Before installing the SIM card, turn off the power for MVT100.
  • Page 6: Charging

    Configuration and testing suggested prior to installation. Indications 7.3 LED There are two methods to turn on/off MVT100: press and hold the Power On/Off button for 3~5 seconds, or connect with external power 11~36V. GPS LED (Blue) One button is pressed or input is active.
  • Page 7: Track By Calling

    V5.0 Confidential: External Documentation 7.4 Track by Calling Make a call to MVT100 and it will report with one SMS. For example, Now,110727 02:48,V,16,23Km/h,61%,http://maps.google.com/maps?f=q&hl=en&q=22.540103,114.082329 &ie=UTF8&z=16&iwloc=addr&om=1 Click on the link then the location can be shown directly on Google Maps on your mobile phone.
  • Page 8: Multiple Phone Numbers- A71

    If no preset phone number, it is empty (default is empty). Send command “0000, A71” to delete all phone numbers. When the SOS button is pressed, MVT100 will make a call to phone number 1, 2 and 3. It will stop calling when one number answers.
  • Page 9: Geo-Fence Alarm - B05

    Status=1, turn on Anti-theft (default); the device alarms when input 2 (positive input) is active; Status=0, turn off Anti-theft; the device doesn’t alarm when input 2 (positive input) is active. Copyright © 2013 Meitrack Group All rights reserved. - 9 -...
  • Page 10: Time Zone- B35

    Click “Port(COM and LPT)”, and find “Prolific USB-to-Serial Comm Port”, if there is no “Prolific USB-to-Serial Comm Port”, please re-install the USB driver ( please refer to the MEITRACK Manager User Guide for detailed guidance). Copyright © 2013 Meitrack Group All rights reserved.
  • Page 11 Note: MEITRACK Manager is in the CD. The language will be automatically adjusted to the same language as your PC’s operation system. Please use “Ctrl+L” to change the language.
  • Page 12: Gprs Tracking

    Select Column 2 Tracking to set SMS tracking & monitoring phone number and GPRS parameters, such as Server IP, and Port (IP/Domain: 67.203.13.26, Port: 8800), APN, Time Interval, etc. Please refer to the MEITRACK Manager User Guide for more detailed information regarding configuration and functions.
  • Page 13: Installation

    V5.0 Confidential: External Documentation For more information about GPRS settings, please refer to MEITRACK SMS/GPRS Protocol. 8. Installation 8.1 Install I/O Cable The I/O cable is a 8-pin cable including power, analog input, negative input, output and USB port for configuration.
  • Page 14: Install / Connection Diagram

    8.2.1 Power/GND (PIN1, PIN2) Connect GND (-Black) and Power (+Red) wires to the battery of motorcycle/vehicle. 8.2.2 Digital Input (PIN 3, Negative Triggering)/SOS 8.2.3 Digital Input (PIN5, Positive Triggering) Copyright © 2013 Meitrack Group All rights reserved. - 14 -...
  • Page 15: Output (Pin7)

    11V-36V), connects with device power cable (0-5V). Please see above. Formula of AD Analog Input: Input Voltage = (AD1*3.3*2)/4096 0x0C9B=>3227(Decimal)=>(3227*3.3*2)/4096=5.1997V(Voltage) 0x0D9D=>3845(Decimal)=>(3845*3.3*2)/4096=5.6154V(Voltage) Formula of Remaining Fuel (Percentage) Remaining Fuel = AD1*6.6/20480*100% Copyright © 2013 Meitrack Group All rights reserved. - 15 -...
  • Page 16: Mount The Mvt100 Unit

    Option 1: Using 3M sticker Option 2: Using Screws Option 3: Using internal super magnet Please do not hesitate to email us at info@meitrack.com if you have any questions. Copyright © 2013 Meitrack Group All rights reserved. - 16 -...
