Aplex APC-3x84A User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
APC-3x84A/APC-3x85A
(SBC-7106)
User Manual
Release Date
_
Revision
Oct. 2014
V1.2
® 2014 Aplex Technology, Inc.
All Rights Reserved.
Published in Taiwan
Aplex Technology, Inc.
15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan
Tel: 886-2-82262881 Fax: 886-2-82262883 E-mail:
aplex@aplex.com.tw
URL:
www.aplex.com.tw
APC-3x84A /APC-3x85AUser Manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the APC-3x84A and is the answer not in the manual?

Questions and answers

Related Manuals for Aplex APC-3x84A

Summary of Contents for Aplex APC-3x84A

  • Page 1 (SBC-7106) User Manual Release Date Revision Oct. 2014 V1.2 ® 2014 Aplex Technology, Inc. All Rights Reserved. Published in Taiwan Aplex Technology, Inc. 15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan Tel: 886-2-82262881 Fax: 886-2-82262883 E-mail: aplex@aplex.com.tw...

  • Page 2: Warning

    Disclaimer This information in this document is subject to change without notice. In no event shall Aplex Technology Inc. be liable for damages of any kind, whether incidental or consequential, arising from either the use or misuse of information in this document or in any related materials.

  • Page 3: Packing List

    Always disconnect power when the system is not in use. ◆ Disconnect power when you change any hardware devices. For instance, when you connect a jumper or install any cards, a surge of power may damage the electronic components or the whole system. APC-3x84A /APC-3x85AUser Manual...

  • Page 4: Table Of Contents

    Disclaimer………………………………………………………………….…………………2 Packing List…………………………………………………………………………………..3 Safety Precautions…………………………………………………………………………..3 Chapter 1 Getting Started 1.1 Features…………………………………………..….……………………..6 1.2 Specifications……………………………………………………………….6 1.3 Dimensions………………………………...…………………………..8 1.4 Brief Description of APC-3x84A/APC-3x85A…………………….………9 Chapter 2 Hardware 2.1 Mainboard………..………..…….……………………………………..…..11 2.2 Introduction..…….………………….……………………………………...14 2.3 Jumpers Setting and Connectors............16 Chapter 3 BIOS Setup 3.1 Operations after POST Screen…............22 3.2 BIOS Setup Utility…................23...
  • Page 5 5.2 Software Functions................56 Figures Figure 1.1: Dimensions of APC-3284A/APC-3285A……...……………..…..8 Figure 1.2: Dimensions of 3584A/APC-3585A…………………………..…..8 Figure 1.3: Front View of APC-3X84A…………..……………………………...9 Figure 1.4: Rear View of APC-3X84A…………..……….……………………..9 Figure 1.5: Front View of APC-3X85A………………….……………………..10 Figure 1.6: Rear View of APC-3X85A…………………………………………10 Figure 2.1: Mainboard Dimensions…………………………………..……..13 Figure 2.2: Jumpers and Connectors Location_ Board Top………………...14...

  • Page 6: Chapter 1 Getting Started

    1 x 3 pin terminal block connector 1 x Power switch Storage Space 1 x 2.5” SATA 2 Movable device 1 x Internal SD slot Expansion On board 1 x Mini PCIe half size expansion bus Display 12.1” TFT-LCD 15” TFT-LCD Display Type APC-3x84A /APC-3x85AUser Manual...
  • Page 7 Resistive Touch Interface Default RS-232 Light Transmission Power Power Input 11~32V DC Mechanical Stainless steel (APC-3x84A) Construction Steel/Black (APC-3x85A) IP Rating 5 sides IP65 Mounting VESA 75 x 75 Dimension 330 x 260 x 51 398 x 316 x 51.8...

  • Page 8: Dimensions

    1.3 Dimensions Figure 1.1: Dimensions of APC-3284A/APC-3285A Figure 1.2: Dimensions of APC-3584A/APC-3585A APC-3x84A /APC-3x85AUser Manual...

  • Page 9: Brief Description Of Apc-3X84A/Apc-3X85A

    1.4 Brief Description of APC-3x84A/APC-3x85A The APC-3x84A/APC-3X85A is the fanless and low power consumption panel-mount industrial panel pc with 12”/15” TFT LCD. It powered by . The panel PC comes with a Intel ® Atom Processor D2550 1.8G rich variety of functions and peripherals. It comes with 1 x 2.5-inch hard disk drive and 1 x Internal SD DDR3 2GB 800 MHz (for 12.1”...

  • Page 10: Figure 1.5: Front View Of Apc-3X85A

    Figure 1.5: Front View of APC-3X85A Figure 1.6: Rear View of APC-3X85A APC-3x84A /APC-3x85AUser Manual...

  • Page 11: Chapter 2 Hardware

    1 x RS-232/RS-422/RS-485, DB9 connector for external (COM1) pin 9 w/5V/12V/Ring select 1 x RS232 port, DB9 connector for external (COM2) Serial pin 9 w/5V/12V/Ring select 1 x RS422/485 header via CN2 (COM3) 2 x UART via CN3 (COM5,COM6) APC-3x84A /APC-3x85AUser Manual...
  • Page 12 Software programmable 1 – 255 second by Super I/O Timer Operating: -20℃ to 70℃ Temperature Storage: -40℃ to 85℃ Humidity 5% - 95%, non-condensing, operating Power 12V /0.95A (Intel Atom N2600 processor with 2GB DDR3 DRAM) Consumption Meet CE/FCC class A EMI/EMS APC-3x84A /APC-3x85AUser Manual...

  • Page 13: Figure 2.1: Mainboard Dimensions

    (units :mm) Figure 2.1: Mainboard Dimensions APC-3x84A /APC-3x85AUser Manual...

  • Page 14: Introduction

    LVDS interface. To satisfy the special needs of high-end customers, CN1 and CN2 and CN3 richer extension functions. The product is widely used in various sectors of industrial control. 2.2.1 Jumpers Setting and Connectors Board Top Figure 2.2: Jumpers and Connectors Location_ Board Top APC-3x84A /APC-3x85AUser Manual...

  • Page 15: Figure 2.3: Jumpers And Connectors Location_ Board Bottom

    Board Bottom Figure 2.3: Jumpers and Connectors Location_ Board Bottom APC-3x84A /APC-3x85AUser Manual...

  • Page 16: Jumpers Setting And Connectors

    Pin1 DC+9V~32V Pin2 Ground Pin3 6. VGA1: (CRT 2.0mm Pitch 2X6 Pin Header), Video Graphic Array Port, Provide 2x6Pin cable to VGA Port. Signal Name Pin# Pin# Signal Name CRT_RED Ground CRT_GREEN Ground CRT_BLUE Ground CRT_H_SYNC CRT_DDCDATA APC-3x84A /APC-3x85AUser Manual...
  • Page 17 Rear serial port, standard DB9 Male serial port is provided to make a direct connection to serial devices. COM1 port is controlled by pins No.1~6 of JP1,select output Signal RI or 5V or 12V, For details, please refer to description of JP1 and S_232 and S_422 setting. APC-3x84A /APC-3x85AUser Manual...

  • Page 18: Chapter 3 Bios Setup

    JP1 select Setting (RI/5V/12V) BIOS Setup： Advanced/W83627UHG Super IO Configuration/Serial Port 1 Configuration【RS-232】 RS422 (option): Pin# Signal Name 422_RX+ 422_RX- 422_TX- 422_TX+ Ground BIOS Setup： Advanced/W83627UHG Super IO Configuration/Serial Port 1 Configuration【RS-422】 RS485 (option): Pin# Signal Name 485- 485+ Ground APC-3x84A /APC-3x85AUser Manual...
  • Page 19 SATA Connectors, one SATA connectors are provided, with transfer (SATA 7Pin+15Pin), speed up to 3.0Gb/s. 20 SD1: (SD card socket),Secure Digital Memory Card socket. 23. LINE_OUT: (Diameter 3.5mm Jack), HD Audio port, An onboard Realtek ALC662 codec is used to APC-3x84A /APC-3x85AUser Manual...
  • Page 20 ACTIVE LED (yellow) respectively located at the left-hand and right-hand side of the Ethernet port indicate the activity and transmission state of LAN. 26. BUZ1: Onboard buzzer. 27 LED1: LED STATUS. Green LED for Motherboard Power status. 28. LED2: LED STATUS. Green LED for Motherboard Standby Power Good status. APC-3x84A /APC-3x85AUser Manual...
  • Page 21 DTRCOM5_CTS- GPIO24 ICH_GPIO24 ICH_GPIO13 GPIO13 GPIO26 ICH_GPIO26 ICH_GPIO27 GPIO27 Ground Ground PE1_TX_N0 PE1_TX_P0 PE1_RX_N0 PE1_RX_P0 PCIE PCIE Ground Ground CLK_100M_PE1_N CLK_100M_PE1_P PM_PCIE_WAKE PLTRST_BUF- SMBUS SMB_CLK_S5 SMB_DATA_S5 SMBUS PE1_CLKREQ Ground PCIE PCIE 3P3V_S5 3P3V_S5 3P3V_S5 3P3V_S5 12V_S0 12V_S0 APC-3x84A /APC-3x85AUser Manual...

  • Page 22: Operations After Post Screen

    After CMOS discharge or BIOS flashing operation,.Press [Delete] key to enter CMOS Setup. After optimizing and exiting CMOS Setup, the POST screen displayed for the first time is as follows and includes basic information on BIOS, CPU, memory, and storage devices. APC-3x84A /APC-3x85AUser Manual...

  • Page 23: Bios Setup Utility

    3.2 BIOS Setup Utility Press [Delete] key to enter BIOS Setup utility during POST, and then a main menu containing system summary information will appear. APC-3x84A /APC-3x85AUser Manual...

  • Page 24: Main Settings

    Second : 0 to 59 System Date: Set the system date, the date format is: Note that the ‘Day’ automatically changes when you set the date. Day: Month: 01 to 12 Date: 01 to 31 1998 to 2099 Year: APC-3x84A /APC-3x85AUser Manual...

  • Page 25: Advanced Settings

    [32 PCI Bus Clocks] [64 PCI Bus Clocks] [96 PCI Bus Clocks] [128 PCI Bus Clocks] [160 PCI Bus Clocks] [192 PCI Bus Clocks] [224 PCI Bus Clocks] [248 PCI Bus Clocks] VGA Palette Snoop: [Disabled] [Enabled] APC-3x84A /APC-3x85AUser Manual...
  • Page 26 [Disabled] [Enabled] S3 Video Repost: [Disabled] [Enabled] 3.4.3 CPU Configuration Processor Type Intel(R) Atom(TM) CPU N2600 EMT64 Not Supported Processor Speed 1600 MHz System Bus Speed 400 MHz Ratio Status Actual Ratio System Bus Speed 400 MHz APC-3x84A /APC-3x85AUser Manual...
  • Page 27 Active Trip Point Lo [55 C] Active Trip Point Hi [71C] Passive Trip Point [95] Passive TC1 Value Passive TC2 Value Passive TSP Value 3.4.5 IDE Configuration SATA Port0 Not Present SATA Port1 Not Present SATA Controller(S): [Enabled] [Disabled] APC-3x84A /APC-3x85AUser Manual...
  • Page 28 [10 sec] [30 sec] [40 sec] Device power-up delay [Auto] [Manual] Mass Storage Devices： Multiplecard Reader 1 [Auto] [Floppy] [Forced FDD] [Hard Disk] [CD-ROM] 3.4.7 W83627UHG Super IO Configuration W83627UHG Super IO ch W83627UHG Serial Port 1 Configuration APC-3x84A /APC-3x85AUser Manual...
  • Page 29 : +12.302V +3.3V : +3.320V +1.5V : +1.528V AVCC : +5.203V VCC5V : +5.216V VSB5 : +5.203V VBAT : +3.334V 3.4.9 Serial Port Console Redirection COM0 Console Redirection [Enabled] [Disabled] Console Redirection Settings Serial Port for Out-of-Band Management/ APC-3x84A /APC-3x85AUser Manual...
  • Page 30 [Enabled] [Disabled] CPU C state Report [Enabled] [Disabled] Enhanced C state [Enabled] [Disabled] CPU Hard C4E [Enabled] [Disabled] CPU C6 state [Enabled] [Disabled] C4 Exit Timing [Fast] [Default] [Slow] C-state POPDOWN [Enabled] [Disabled] C-state POPUP [Enabled] [Disabled] APC-3x84A /APC-3x85AUser Manual...

  • Page 31: Chipset Settings

    ►Memory Frequency and Timing ►Intel IGD Configuration ******* Memory Information ******* Memory Frequency 800 MHz(DDR3) Tot al Memory 2048 MB DIMM#0 Not Present DIMM#1 2048 MB Memory Frequency and Timing MRC Fast Boot [Enabled] [Disabled] Max TOLUD [Dynamic] APC-3x84A /APC-3x85AUser Manual...
  • Page 32 [VGA + LVDS] LCD Panel Type [VBIOS Default] [640x480，18bit] [800x480，18bit] [800x600，18bit] [1024x600，18bit ] [1024x768，18bit ] [1280x768，18bit ] [1280x800，18bit ] [1280x1024，18bit] [1366x768，18bit] [1024x768，24bit] [1280x768，24bit] [1280x800，24bit] [1280x1024，24bit] Panel Scaling [Auto] [Force Scaling] [off] [Maintain Aspect Ratio] Active LFP [LVDS] APC-3x84A /APC-3x85AUser Manual...
  • Page 33 [Negative] Back light Control Lev [Auto] [Disabled] [Level 8] [Level 1] [Level 2] [Level 3] [Level 4] [Level 5] [Level 6] [Level 7] [Level 8] [Level 9] [Level 10] [Level 11] [Level 12] [Level 13] [Level 14] APC-3x84A /APC-3x85AUser Manual...
  • Page 34 [Disabled] PCI-Exp. High Priorit [Disabled] [Enabled] High Precision Event Timer Configuration High Precision Timer [Enabled] [Disabled] SLP_S4 Assertion Widt [1-2 Seconds] [2-3 Seconds] [3-4 Seconds] [4-5 Seconds] Restore AC Power Loss [Last State] [Power off] [Power on] APC-3x84A /APC-3x85AUser Manual...

  • Page 35: Boot Settings

    3.6 Boot Settings Setup Prompt Timeout Bootup Numlock State [On] [off] Quiet Boot [Disabled] [Enabled] Fast Boot [Enabled] [Disabled] APC-3x84A /APC-3x85AUser Manual...
  • Page 36 Boot Option #1 Boot Option #2 …… Sets the system boot order [SATA PM:*** … ] Hard Drive BBS Priorities Boot Option #1 SATA PM:***… ****** Disabled CSM Parameters Launch CSM [Always] [Never] Boot option filter [UEFI and Legacy] APC-3x84A /APC-3x85AUser Manual...
  • Page 37 Launch PXE OpROM poli [Do not Launch] [UEFI only] [Legacy only] Launch Storage OpROM [Legacy only] [Do not Launch] [UEFI only] Launch Video OpROM po [Do not Launch] [UEFI only] [Legacy only] Other PCI device ROM [UEFI OpROM] [Legacy OpROM] APC-3x84A /APC-3x85AUser Manual...

  • Page 38: Security Settings

    To clear the password, just press Enter key when password input window pops up. A confirmation message will be shown on the screen as to whether the password will be disabled. You will have direct access to BIOS setup without typing any password after system reboot once the password is disabled. APC-3x84A /APC-3x85AUser Manual...

  • Page 39: Save And Exit Settings

    Security Option is set to Setup, you will be requested for password for entering BIOS setup. 3.8 Save and Exit Settings Save Changes and Exit Save & Exit Setup save Configuration and exit ? [Yes] [No] Discard Changes and Ext APC-3x84A /APC-3x85AUser Manual...
  • Page 40 Load Optimized Defaults Load optimized Defaults? [Yes] [No] Save user Defaults Save Values as User Defaults Save configuration? [Yes] [No] Restore user Defaults Restore User Defaults Restore User Defaults? [Yes] [No] Launch EFI Shell from filesystem device WARNING Not Found [ok] APC-3x84A /APC-3x85AUser Manual...

  • Page 41: Chapter 4 Installation Of Drivers

    VGA driver, LAN drivers, Audio driver Installation instructions are given below. Important Note: After installing your Windows operating system (Windows 7), you must install first the Intel Chipset Software Installation Utility before proceeding with the installation of drivers. APC-3x84A /APC-3x85AUser Manual...

  • Page 42: Intel Chipset Driver

    4.1 Intel Chipset Driver To install the Intel chipset driver, please follow the steps below. Step 1. Select Intel (R) Chipset NM10 Express from the list Step 2. Click Next to setup program. APC-3x84A /APC-3x85AUser Manual...
  • Page 43 Step 3. Read the license agreement. Click Yes to accept all of the terms of the license agreement. Step 4. Click Next to continue. APC-3x84A /APC-3x85AUser Manual...
  • Page 44 Step 5. Click Next. Step 6. Select Yes, I want to restart this computer now. Click Finish, then remove any installation media from the drives. APC-3x84A /APC-3x85AUser Manual...

  • Page 45: Intel Graphics Media Accelerator Driver

    To install the VGA Drivers, follow the steps below to proceed with the installation. Step 1.Select Intel(R) VGA Chipset Driver. Step 2. Click Automatically run WinSAT and enable the Windows Aero desktop theme (if supported). Click Next. APC-3x84A /APC-3x85AUser Manual...
  • Page 46 Step 3. Read license agreement, click Yes. Step 4. Click Next. APC-3x84A /APC-3x85AUser Manual...
  • Page 47 Step 5. Click Next to continue. Step 6. Select Yes, I want to restart this computer now. Click Finish. APC-3x84A /APC-3x85AUser Manual...

  • Page 48: Intel (R) Network Adapter

    4.3 Intel (R) Network Adapter To install the Intel (R) Network Adapter device driver, please follow the steps below. Step 1. Select LAN Driver. Step 2. Select 12”~15”. APC-3x84A /APC-3x85AUser Manual...
  • Page 49 Step 3. Click Next to continue. Step 4. Click Install to begin the installation. APC-3x84A /APC-3x85AUser Manual...

  • Page 50: Realtek Alc662 Hd Audio Driver Installation

    Step 5. Click Finish to exist the wizard. 4.4 Realtek ALC662 HD Audio Codec Driver Installation To install the Realtek ALC662 HD Audio Codec Driver, please follow the steps below. Step 1. Select Realtek AL662 Audio Codec Driver from the list APC-3x84A /APC-3x85AUser Manual...
  • Page 51 Step 2. Click Next to continue. Step 3. Click Yes, I want to restart my computer now. Click Finish to complete the installation. APC-3x84A /APC-3x85AUser Manual...

  • Page 52: Chapter 5 Touch Screen Installation

    If you have an older version of the PenMount Windows 2000/XP driver installed in your system, please remove it first. Follow the steps below to install the PenMount DMC6000 Windows 2000/XP driver. Step 1. Insert the product CD, the screen below would appear. Click touch panel driver. APC-3x84A /APC-3x85AUser Manual...
  • Page 53 Step 2. Click Next to continue. Step 3. Read the license agreement. Click I Agree to agree the license agreement. APC-3x84A /APC-3x85AUser Manual...
  • Page 54 Step 4. Choose the folder in which to install PenMount Windows Universal Driver. Click Install to start the installation. Step 5. Wait for installation. Then click Next to continue. APC-3x84A /APC-3x85AUser Manual...
  • Page 55 Step 6. Click Continue Anyway. Step 7. Click Finish to complete installation. APC-3x84A /APC-3x85AUser Manual...

  • Page 56: Software Functions

    ‘Advanced Calibration’ adjusts aging touch screens. Standard Calibration Click this button and arrows appear pointing to red squares. Use your finger or stylus to touch the red squares in sequence. After the fifth red point calibration is complete. To skip, press ‘ESC’. APC-3x84A /APC-3x85AUser Manual...
  • Page 57 Calibration) Dmcctrl.exe - calibration ($) 0= Standard Calibration 4=Advanced Calibration 4 9=Advanced Calibration 9 16=Advanced Calibration 16 25=Advanced Calibration 25 Step 1. Please select a device then click “Configure”. You can also double click the device too. APC-3x84A /APC-3x85AUser Manual...
  • Page 58 Step 2.Click “Standard Calibration” to start calibration procedure NOTE: The older the touch screen, the more Advanced Mode calibration points you need for an accurate calibration. Use a stylus during Advanced Calibration for greater accuracy. Please follow the step as below: APC-3x84A /APC-3x85AUser Manual...
  • Page 59 Step 3.Come back to “PenMount Control Panel” and select Tools then click Advanced Calibration. Step 4. Select Device to calibrate, then you can start to do Advanced Calibration. NOTE: Recommend to use a stylus during Advanced Calibration for greater accuracy. APC-3x84A /APC-3x85AUser Manual...
  • Page 60 Beep Frequency – modifies sound frequency Beep Duration – modifies sound duration Cursor Stabilizer Enable the function support to prevent cursor shake. Use press and hold You can set the time out and area for you need as right click APC-3x84A /APC-3x85AUser Manual...
  • Page 61 About This panel displays information about the PenMount controller and driver version. APC-3x84A /APC-3x85AUser Manual...
  • Page 62 Enable the multiple display function as follows: 1. Check the Enable Multiple Monitor Support box; then click Map Touch Screens to assign touch controllers to displays. When the mapping screen message appears, click OK. APC-3x84A /APC-3x85AUser Manual...
  • Page 63 Touching all screens completes the mapping and the desktop reappears on the monitors. Select a display and execute the “Calibration” function. A message to start calibration appears. Click OK. “Touch this screen to start its calibration” appears on one of the screens. Touch the screen. APC-3x84A /APC-3x85AUser Manual...
  • Page 64 This panel displays information about the PenMount controller and this driver version. PenMount Monitor Menu Icon The PenMount monitor icon (PM) appears in the menu bar of Windows 2000/XP system when you turn on PenMount Monitor in PenMount Utilities. PenMount Monitor has the following function APC-3x84A /APC-3x85AUser Manual...
  • Page 65 2. Choose the rotate function (0°, 90°, 180°, 270°) in the 3rd party software. The calibration screen appears automatically. Touch this point and rotation is mapped. NOTE: The Rotate function is disabled if you use Monitor Mapping. APC-3x84A /APC-3x85AUser Manual...
