APC-3x84A/APC-3x85A
(with motherboard SBC-7106)
User Manual
Release Date
Revision
Aug. 2015
V1.3
®2015 Aplex Technology, Inc.
All Rights Reserved.
Published in Taiwan
Aplex Technology, Inc.
15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan
Tel: 886-2-82262881 Fax: 886-2-82262883 E-mail:
aplex@aplex.com.tw
URL:
www.aplextec.com
APC-3x84A /APC-3x85AUser Manual
0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the APC-3284A and is the answer not in the manual?

Questions and answers

Related Manuals for Aplex APC-3284A

Summary of Contents for Aplex APC-3284A

  • Page 1 (with motherboard SBC-7106) User Manual Release Date Revision Aug. 2015 V1.3 ®2015 Aplex Technology, Inc. All Rights Reserved. Published in Taiwan Aplex Technology, Inc. 15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan Tel: 886-2-82262881 Fax: 886-2-82262883 E-mail: aplex@aplex.com.tw...

  • Page 2: Revision History

    Revision History Reversion Date Descriptions 2013/10/03 Official Version 2013/10/21 Modify CPU, 12.1” LCD, dimensions, and touch interface Spec. 2014/10/30 17” and 19” change motherboard to SBC-7106A 2015/08/11 Modify IO Port Serial/Parallel, 12.1” LCD, operating temperature, motherboard and Expansion slot spec., add power consumption spec.

  • Page 3: Warning!/Disclaimer

    This information in this document is subject to change without notice. In no event shall Aplex Technology Inc. be liable for damages of any kind, whether incidental or consequential, arising from either the use or misuse of information in this document or in any related materials.

  • Page 4: Packing List/Safety Precautions

    Packing List Accessories (as ticked) included in this package are: □ AC power cable □ Driver & manual CD disc □ Other.___________________(please specify) Safety Precautions Follow the messages below to prevent your systems from damage: ◆ Avoid your system from static electricity on all occasions. ◆...

  • Page 5: Table Of Contents

    Table of Contents Revision History………………………………………………………………………………….1 Warning!/Disclaimer…………………………………………………………………………..2 Packing List/Safety Precautions…………………………………………………………..3 Chapter 1 Getting Started 1.1 Features……………………………………………………..….……………………..6 1.2 Specifications…………………..…………………………………………………….6 1.3 Dimensions…………………………..……………...…………………………..8 1.4 Brief Description of APC-3x84A/APC-3x85A……..…………….………9 Chapter 2 Hardware 2.1 Mainboard………..………..…….………………………………..…………..…..11 2.2 Motherboard Specifications….…………………………..………………...11 2.3 Jumpers Setting and Connectors..........15 Chapter 3 BIOS Setup 3.1 Operations after POST Screen…..........21 3.2 BIOS Setup Utility…..............22 3.3 Main Settings…................23...
  • Page 6 5.1 Windows 2000/XP USB Driver Installation for PenMount 6000 Series………………………..……………………………………………………….51 5.2 Software Functions..............55 Figures Figure 1.1: Dimensions of APC-3284A/APC-3285A……..……………..…8 Figure 1.2: Dimensions of 3584A/APC-3585A……………………………...8 Figure 1.3: Front View of APC-3X84A…………..……………………………...9 Figure 1.4: Rear View of APC-3X84A…………..……….……………………...9 Figure 1.5: Front View of APC-3X85A………………….……………………..10 Figure 1.6: Rear View of APC-3X85A……………………………………..……10...

  • Page 7: Getting Started

    Onboard 2GB DDR3 800 MHz, 4GB is for option  11~32V DC wide-ranging power input  5 sides IP 65  5-Wire Resistive Touch Screen 1.2 Specifications APC-3284A/85A APC-3584A/85A System Intel® Atom Processor D2550 1.8G Motherboard SBC-7106 System Chipset Intel NM10 Express...
  • Page 8 5 sides IP65 Mounting VESA mount 75 x 75 Dimension 330 x 260 x 51 mm 398 x 319 x 51.8 mm Net Weight (Kgs) 4.3 Kg (APC-3284A) 6.9 Kg (APC-3584A) 4 Kg (APC-3285A) 6.5 Kg (APC-3585A) Environmental Operating 0~50°C (with HDD) Temperature -20~60°C (with Industrial SSD for 15”)

  • Page 9: Dimensions

    1.3 Dimensions Figure 1.1: Dimensions of APC-3284A/APC-3285A Figure 1.2: Dimensions of APC-3584A/APC-3585A APC-3x84A /APC-3x85AUser Manual...

  • Page 10: Brief Description Of Apc-3X84A/Apc-3X85A

    1.4 Brief Description of APC-3x84A/APC-3x85A The APC-3x84A/APC-3X85A is the fanless and low power consumption panel-mount industrial panel pc with 12”/15” TFT LCD. It powered by Intel ® Atom Processor D2550 . The panel PC comes with a rich variety of functions and peripherals. It comes 1.8G with 1 x 2.5-inch hard disk drive and for data storage , support...

  • Page 11: Figure 1.5: Front View Of Apc-3X85A

    Figure 1.5: Front View of APC-3X85A Figure 1.6: Rear View of APC-3X85A APC-3x84A /APC-3x85AUser Manual...

  • Page 12: Chapter 2 Hardware

    Chapter 2 Hardware 2.1 Motherboard Introduction SBC-7106 is a 4" industrial motherboard developed on the basis of Intel Cedarview-M Processors and NM10, which provides abundant peripheral interfaces to meet the needs of different customers. Also, it features dual GbE ports, 3-COM ports and one Mini PCIE configuration, one VGA port, one HDMI port, one LVDS interface.
  • Page 13 BIOS AMIBIOS Storage 1 x SATA Connector (7P) 1 x SATA Connector (7P+15P) 1 x SD Socket (USB to SD) Ethernet 2 x PCIe GbE LAN by Realtek RTL8111E 2 x USB 2.0 (type A)stack ports (USB4/USB5) 2 x USB 2.0 Pin header via CN3 (USB2/USB3) 2 x USB 2.0 Pin header via CN1 (USB0/USB1) 1 x USB 2.0 for MPCIE1 (USB7) 1 x RS-232/RS-422/RS-485, DB9 connector for external...

  • Page 14: Figure 2.1: Mainboard Dimensions

    1 x HDD LED status via CN1 1 x Buzzer External I/O port 2 x COM Ports (COM1/COM2) 2 x USB 2.0 Ports (stack) 2 x GbE LAN Ports 1 x HDMI Port 1 x Stack audio Jack (Line out) Watchdog Timer Software programmable 1 –...

  • Page 15: Figure 2.2: Jumpers And Connectors Location_ Board Top

    2.2.1 Jumpers Setting and Connectors Board Top Figure 2.2: Jumpers and Connectors Location_ Board Top Board Bottom Figure 2.3: Jumpers and Connectors Location_ Board Bottom APC-3x84A /APC-3x85AUser Manual...

  • Page 16: Jumpers Setting And Connectors

    2.3 Jumpers Setting and Connectors 1. JP5: (2.0mm Pitch 1X2 box Pin Header),ATX Power and Auto Power on jumper setting. Mode Open ATX Power Close Auto Power on (Default) 3. BAT1 : (1.25mm Pitch 1X2 box Pin Header) 3.0V Li battery is embedded to provide power for CMOS.
  • Page 17 9. RS-232: (Switch),COM1 jumper setting, it provides selectable RS232 or RS422 or RS485 serial signal output. Function S_232 Pin# RS232 (Default) ON: Pin1, Pin2, Pin3, Pin4 RS422 (option) OFF: Pin1, Pin2, Pin3, Pin4 RS485 (option) OFF: Pin1, Pin2, Pin3, Pin4 10.

  • Page 18: Chapter 3 Bios Setup

    BIOS Setup： Advanced/W83627UHG Super IO Configuration/Serial Port 1 Configuration【RS-232】 RS422 (option): Pin# Signal Name 422_RX+ 422_RX- 422_TX- 422_TX+ Ground BIOS Setup： Advanced/W83627UHG Super IO Configuration/Serial Port 1 Configuration【RS-422】 RS485 (option): Pin# Signal Name 485- 485+ Ground BIOS Setup： Advanced/W83627UHG Super IO Configuration/Serial Port 1 Configuration【RS-485】...
  • Page 19 Pin# Signal Name DCD# (Data Carrier Detect) RXD (Received Data) TXD (Transmit Data) DTR (Data Terminal Ready) Ground DSR (Data Set Ready) RTS (Request To Send) CTS (Clear To Send) 16. LED3: LED STATUS. Green LED for Touch Power status. 19 SATA1: SATA Connectors, one SATA connectors are provided, with (SATA 7Pin+15Pin),...
  • Page 20 Each USB Type A Receptacle (2 Ports) Current limited value is 1.5A. If the external USB device current exceeds 1.5A, please separate connectors into different Receptacle. 25. LAN1/LAN2: Connector Rear LAN port, Two standard 10/100/1000M RJ-45 LAN1/LAN2: (RJ45 Ethernet ports are provided. Used Realtek RTL8111E chipset, LINK LED (green) and ACTIVE LED (yellow) respectively located at the left-hand and right-hand side of the Ethernet port indicate the activity and transmission state of LAN.
  • Page 21 Ground Ground PS/2 MS PS2_MSCLK PS2_MSDATA PS/2 MS PS/2 KB PS2_KBCLK PS2_KBDATA PS/2 KB COM6_RI COM6_DCD- COM6 COM6 COM6_TXD COM6_RXD (UART) (UART) COM6_DTR RICOM6_RTS- COM6_DSR COM6_CTS- Ground Ground COM5_RI COM5_DCD- COM5 COM5 COM5_TXD COM5_RXD (UART) (UART) COM5_DTR DSRCOM5_RTS- COM5_DSR DTRCOM5_CTS- GPIO24 ICH_GPIO24 ICH_GPIO13...

  • Page 22: Operations After Post Screen

    Chapter 3 BIOS Setup Description 3.1 Operations after POST Screen After CMOS discharge or BIOS flashing operation,.Press [Delete] key to enter CMOS Setup. After optimizing and exiting CMOS Setup, the POST screen displayed for the first time is as follows and includes basic information on BIOS, CPU, memory, and storage devices.

  • Page 23: Bios Setup Utility

    3.2 BIOS Setup Utility Press [Delete] key to enter BIOS Setup utility during POST, and then a main menu containing system summary information will appear. APC-3x84A /APC-3x85AUser Manual...

  • Page 24: Main Settings

    3.3 Main Settings System Time: Set the system time, the time format is: Hour : 0 to 23 Minute : 0 to 59 Second : 0 to 59 System Date: Set the system date, the date format is: Day: Note that the ‘Day’ automatically changes when you set the date.

  • Page 25: Advanced Settings

    3.4 Advanced Settings 3.4.1 PCI Subsystem Settings PCI Bus Driver Versio V2.05.02 PCI Common Settings: PCI Latency Timer: [32 PCI Bus Clocks] [64 PCI Bus Clocks] [96 PCI Bus Clocks] [128 PCI Bus Clocks] [160 PCI Bus Clocks] [192 PCI Bus Clocks] [224 PCI Bus Clocks] [248 PCI Bus Clocks] VGA Palette Snoop:...
  • Page 26 [Disabled] [Enabled] PERR# Generation: [Disabled] [Enabled] SERR# Generation: [Disabled] [Enabled] 3.4.2 ACPI Settings Enable ACPI Auto Conf: [Disabled] [Enabled] Enable Hibernation: [Enabled] [Disabled] ACPI Sleep State: [Both S1 and S3 available for OS to choose from ] [Suspend Disabled] [S1 only(CPU Stop Clock) ] [S3 only (Suspend to RAM) ] Lock Legacy Resources: [Disabled]...
  • Page 27 Processor Speed 1600 MHz System Bus Speed 400 MHz Ratio Status Actual Ratio System Bus Speed 400 MHz Processor Stepping 30661 Microcode Revision L1 Cache RAM 2 x 56 k L2 Cache RAM 2 x 512k Processor Core Dual Hyper-Threading Supported Hyper-Threading: [Enabled]...
  • Page 28 3.4.5 IDE Configuration SATA Port0 Not Present SATA Port1 Not Present SATA Controller(S): [Enabled] [Disabled] Configure SATA as: [IDE] [AHCI] Misc Configuration for hard disk 3.4.6 USB Configuration USB Configuration USB Devices: 1 Drive ，1 keyboard Legacy USB Support: [Enabled] [Disabled] EHCI Hand-off: [Disabled]...
  • Page 29 Mass Storage Devices： Multiplecard Reader 1 [Auto] [Floppy] [Forced FDD] [Hard Disk] [CD-ROM] 3.4.7 W83627UHG Super IO Configuration W83627UHG Super IO ch W83627UHG Serial Port 1 Configuration UART Mode Selection： [RS-232] [RS-485] [RS-422] Serial Port 2 Configuration Serial Port 3 Configuration UART Mode Selection：...
  • Page 30 +1.5V : +1.528V AVCC : +5.203V VCC5V : +5.216V VSB5 : +5.203V VBAT : +3.334V 3.4.9 Serial Port Console Redirection COM0 Console Redirection [Enabled] [Disabled] Console Redirection Settings Serial Port for Out-of-Band Management/ Windows Emergency Management Services (EMS) Console Redirection [Disabled] [Enabled] Console Redirection Settings...

  • Page 31: Chipset Settings

    [Fast] [Default] [Slow] C-state POPDOWN [Enabled] [Disabled] C-state POPUP [Enabled] [Disabled] 3.5 Chipset Settings 3.5.1 Host Bridge ►Memory Frequency and Timing ►Intel IGD Configuration ******* Memory Information ******* APC-3x84A /APC-3x85AUser Manual...
  • Page 32 Memory Frequency 800 MHz(DDR3) Tot al Memory 2048 MB DIMM#0 Not Present DIMM#1 2048 MB Memory Frequency and Timing MRC Fast Boot [Enabled] [Disabled] Max TOLUD [Dynamic] [1GB] [1.25GB] [1.5GB] [1.75GB] [2GB] [2.25GB] [2.5GB] [2.75GB] [3GB] [3.25GB] Intel IGD Configuration IGFX –...
  • Page 33 [1280x1024，18bit] [1366x768，18bit] [1024x768，24bit] [1280x768，24bit] [1280x800，24bit] [1280x1024，24bit] Panel Scaling [Auto] [Force Scaling] [off] [Maintain Aspect Ratio] Active LFP [LVDS] [No LVDS] [EDP] IGD Clock Source [External Clock] [Internal Clock] Fixed Graphics Memory [128MB] [256MB] ALS Support [Disabled] [Enabled] Back light Control [DC] [PWM] Back light Logic...
  • Page 34 Back light Control Lev [Auto] [Disabled] [Level 8] [Level 1] [Level 2] [Level 3] [Level 4] [Level 5] [Level 6] [Level 7] [Level 8] [Level 9] [Level 10] [Level 11] [Level 12] [Level 13] [Level 14] [Level 15] 3.5.2 South Bridge TPT Devices PCI Express Root Port 0 PCI Express Root Port 1...

  • Page 35: Boot Settings

    [Enabled] [Disabled] SLP_S4 Assertion Widt [1-2 Seconds] [2-3 Seconds] [3-4 Seconds] [4-5 Seconds] Restore AC Power Loss [Last State] [Power off] [Power on] 3.6 Boot Settings APC-3x84A /APC-3x85AUser Manual...
  • Page 36 Setup Prompt Timeout Bootup Numlock State [On] [off] Quiet Boot [Disabled] [Enabled] Fast Boot [Enabled] [Disabled] Skip VGA [Enabled] [Disabled] Skip USB [Disabled] [Enabled] Skip PS2 [Disabled] [Enabled] CSM16 Module Version 07.69 Gatea20 Active [Upon Request] [Always] Option ROM Messages [Force BIOS] [Keep Current] Interrupt 19 Capture...
  • Page 37 Sets the system boot order Hard Drive BBS Priorities [SATA PM:*** … ] Boot Option #1 SATA PM:***… ****** Disabled CSM Parameters Launch CSM [Always] [Never] Boot option filter [UEFI and Legacy] [Legacy only] [UEFI only] Launch PXE OpROM poli [Do not Launch] [UEFI only] [Legacy only]...

  • Page 38: Security Settings

    3.7 Security Settings 6.4.1 Administrator Password 6.4.2 User Password Type the password with up to 20 characters and then press Enter key. This will clear all previously typed CMOS passwords. You will be requested to confirm the password. Type the password again and press Enter key. You may press Esc key to abandon password entry operation.

  • Page 39: Save And Exit Settings

    be disabled. You will have direct access to BIOS setup without typing any password after system reboot once the password is disabled. Once the password feature is used, you will be requested to type the password each time you enter BIOS setup. This will prevent unauthorized persons from changing your system configurations.
  • Page 40 [Yes] [No] Discard Changes and Ext Exit Without Saving Quit without saving? [Yes] [No] Save Changes and Reset Save & reset Save Configuration and reset? [Yes] [No] Discard Changes and Reset Reset Without Saving Reset without saving? [Yes] [No] Save Changes Save Setup Values Save configuration? [Yes] [No]...

  • Page 41: Chapter 4 Installation Of Drivers

    Chapter 4 Installation of Drivers This chapter describes the installation procedures for software and drivers under the windows 7. The software and drivers are included with the motherboard. The contents include Intel chipset driver, VGA driver, LAN drivers, Audio driver Installation instructions are given below.

  • Page 42: Intel Chipset Driver

    4.1 Intel Chipset Driver To install the Intel chipset driver, please follow the steps below. Step 1. Select Intel (R) Chipset NM10 Express from the list Step 2. Click Next to setup program. APC-3x84A /APC-3x85AUser Manual...
  • Page 43 Step 3. Read the license agreement. Click Yes to accept all of the terms of the license agreement. Step 4. Click Next to continue. APC-3x84A /APC-3x85AUser Manual...
  • Page 44 Step 5. Click Next. Step 6. Select Yes, I want to restart this computer now. Click Finish, then remove any installation media from the drives. APC-3x84A /APC-3x85AUser Manual...

  • Page 45: Intel Graphics Media Accelerator Driver

    4.2 Intel Graphics Media Accelerator Driver To install the VGA Drivers, follow the steps below to proceed with the installation. Step 1.Select Intel(R) VGA Chipset Driver. Step 2. Click Automatically run WinSAT and enable the Windows Aero desktop theme (if supported). Click Next. APC-3x84A /APC-3x85AUser Manual...
  • Page 46 Step 3. Read license agreement, click Yes. Step 4. Click Next. APC-3x84A /APC-3x85AUser Manual...
  • Page 47 Step 5. Click Next to continue. Step 6. Select Yes, I want to restart this computer now. Click Finish. APC-3x84A /APC-3x85AUser Manual...

  • Page 48: Intel (R) Network Adapter

    4.3 Intel (R) Network Adapter To install the Intel (R) Network Adapter device driver, please follow the steps below. Step 1. Select LAN Driver. Step 2. Select 12”~15”. APC-3x84A /APC-3x85AUser Manual...
  • Page 49 Step 3. Click Next to continue. Step 4. Click Install to begin the installation. APC-3x84A /APC-3x85AUser Manual...

  • Page 50: Realtek Alc662 Hd Audio Driver Installation

    Step 5. Click Finish to exist the wizard. 4.4 Realtek ALC662 HD Audio Codec Driver Installation To install the Realtek ALC662 HD Audio Codec Driver, please follow the steps below. Step 1. Select Realtek AL662 Audio Codec Driver from the list APC-3x84A /APC-3x85AUser Manual...
  • Page 51 Step 2. Click Next to continue. Step 3. Click Yes, I want to restart my computer now. Click Finish to complete the installation. APC-3x84A /APC-3x85AUser Manual...

  • Page 52: Chapter 5 Touch Screen Installation

    Chapter 5 Touch Screen Installation This chapter describes how to install drivers and other software that will allow your touch screen work with different operating systems. 5.1 Windows XP/2003/Vista/7 Universal Driver Installation for PenMount 6000 Series Before installing the Windows XP/2003/Vista/7 driver software, you must have the Windows XP/2003/Vista/7 system installed and running on your computer.
  • Page 53 Step 2. Click Next to continue. Step 3. Read the license agreement. Click I Agree to agree the license agreement. APC-3x84A /APC-3x85AUser Manual...
  • Page 54 Step 4. Choose the folder in which to install PenMount Windows Universal Driver. Click Install to start the installation. Step 5. Wait for installation. Then click Next to continue. APC-3x84A /APC-3x85AUser Manual...
  • Page 55 Step 6. Click Continue Anyway. Step 7. Click Finish to complete installation. APC-3x84A /APC-3x85AUser Manual...

  • Page 56: Software Functions

    5.2 Software Functions Upon rebooting, the computer automatically finds the new 6000 controller board. The touch screen is connected but not calibrated. Follow the procedures below to carry out calibration. 1. After installation, click the PenMount Monitor icon “PM” in the menu bar. 2.
  • Page 57 Advanced Calibration Advanced Calibration uses 4, 9, 16 or 25 points to effectively calibrate touch panel linearity of aged touch screens. Click this button and touch the red squares in sequence with a stylus. To skip, press ESC’. Command Calibration Command call calibration function. Use command mode call calibration function, this can uses Standard, 4, 9, 16 or 25 points to calibrate E.g.
  • Page 58 NOTE: The older the touch screen, the more Advanced Mode calibration points you need for an accurate calibration. Use a stylus during Advanced Calibration for greater accuracy. Please follow the step as below: APC-3x84A /APC-3x85AUser Manual...
  • Page 59 Step 3.Come back to “PenMount Control Panel” and select Tools then click Advanced Calibration. Step 4. Select Device to calibrate, then you can start to do Advanced Calibration. APC-3x84A /APC-3x85AUser Manual...
  • Page 60 NOTE: Recommend to use a stylus during Advanced Calibration for greater accuracy. Plot Calibration Data Check this function and a touch panel linearity comparison graph appears when you have finished Advanced Calibration. The blue lines show linearity before calibration and black lines show linearity after calibration.
  • Page 61 About This panel displays information about the PenMount controller and driver version. APC-3x84A /APC-3x85AUser Manual...
  • Page 62 Multiple Monitors Multiple Monitors support from two to six touch screen displays for one system. The PenMount drivers for Windows 2000/XP support Multiple Monitors. This function supports from two to six touch screen displays for one system. Each monitor requires its own PenMount touch screen control board, either installed inside the display or in a central unit.
  • Page 63 Touch each screen as it displays “Please touch this monitor”. Following this sequence and touching each screen is called mapping the touch screens. Touching all screens completes the mapping and the desktop reappears on the monitors. Select a display and execute the “Calibration” function. A message to start calibration appears.
  • Page 64 Continue calibration for each monitor by clicking Standard Calibration and touching the red squares. NOTES: 1. If you use a single VGA output for multiple monitors, please do not use the Multiple Monitor function. Just follow the regular procedure for calibration on each of your desktop monitors.
  • Page 65 Control Panel Open Control Panel Windows Beep Setting Beep function for each device Right Button When you select this function, a mouse icon appears in the right-bottom of the screen. Click this icon to switch between Right and Left Button functions.
