APC-3XX9A
Panel PC User Manual
Release Date
_
Revision
Aug. 2014
V1.0
® 2014
All Rights Reserved.
Published in Taiwan
Aplex Technology, Inc.
15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan
Tel: 886-2-82262881 Fax: 886-2-82262883 E-mail:
aplex@aplex.com.tw
URL:
www.aplex.com.tw
APC-3XX9A User Manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the APC-3XX9A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aplex APC-3XX9A

Summary of Contents for Aplex APC-3XX9A

  • Page 1 Release Date Revision Aug. 2014 V1.0 ® 2014 All Rights Reserved. Published in Taiwan Aplex Technology, Inc. 15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan Tel: 886-2-82262881 Fax: 886-2-82262883 E-mail: aplex@aplex.com.tw URL: www.aplex.com.tw APC-3XX9A User Manual...

  • Page 2: Warning

    Electric Shock Hazard – Do not operate the machine with its back cover removed. There are dangerous high voltages inside. APC-3XX9A User Manual...

  • Page 3: Packing List

    Always disconnect power when the system is not in use. ◆ Disconnect power when you change any hardware devices. For instance, when you connect a jumper or install any cards, a surge of power may damage the electronic components or the whole system. APC-3XX9A User Manual...

  • Page 4: Table Of Contents

    Getting Started 1.1 Features……..………………………………………………………………6 1.2 Specifications……………………………………………………………….6 1.3 Dimensions………………………………………………………………….8 1.4 Installation of HDD………………………………………………………..10 1.5 Installation of PCIe Add-on &CF………………..…………………….…12 1.6 Brief Description of APC-3XX9A………………………………………14 Chapter 2 Hardware 2.1 Mainboard Specifications...……………………………………………….16 2.2 Jumpers and Headers Setting Guide.……………………...……………18 2.3 I/O Panel………………………………………………………………..27 2.4 Installation……………………………………………………………….…28 2.5 Driver Installation Guide………………………………………..…………31...
  • Page 5 5.3 Software Functions………………………..………………………………78 Figures Figure 1.1: Dimensions of APC-3229A……………………………………..…8 Figure 1.2: Dimensions of APC-3249A………………………………………..9 Figure 1.3: Front View of APC-3229A……………………………………….14 Figure 1.4: Rear View of APC-3229A………………………………………..14 Figure 1.5: Front View of APC-3249A……………………………………….15 Figure 1.6: Rear View of APC-3249A………………………………………..15 APC-3XX9A User Manual...

  • Page 6: Getting Started

    1 x Rocker switch for power on/off (for option)  2 x LED light for power and HDD indication Storage 2 x 2.5" SATA HDD space (Easily Accessible storage design) Support RAID 0/1 CD/DVD-R Device 1 x Slim DVDRW device for option APC-3XX9A User Manual...
  • Page 7 Operating Temperature 0~50 ﾟ C -20~60 ﾟ C Storage Temperature 10~90% @40℃ non-condensing Storage Humidity Vibration 1G / 5 ~ 500Hz (Random) / Operation Shock 19G peak acceleration(11 msec. duration)/operation Certificate Meet CE/FCC Class A Waterproof / Dustproof Panel IP65 APC-3XX9A User Manual...

  • Page 8: Dimensions

    1.3 Dimensions Figure 1.1: Dimensions of the APC-3229A APC-3XX9A User Manual...

  • Page 9: Figure 1.2: Dimensions Of Apc-3249A

    Figure 1.2: Dimensions of the APC-3249A APC-3XX9A User Manual...

  • Page 10: Installation Of Hdd

    Step 1 There are 2 screws to deal with when Installing of HDD. Step 2 Loosen screw and draw the HDD bracket out as shown in the picture. Step 3 Tighten four screws as shown in the picture APC-3XX9A User Manual...
  • Page 11 Step 4 Push into the HDD bracket as shown in the picture. Step 5 Tighten the 2 screws as shown in the picture. APC-3XX9A User Manual...

  • Page 12: Installation Of Pcie Add-On &Cf

    1.5 Installation of PCIe Add-on &CF Step 1 There are 2 screws to deal with when enclosing or removing the chassis. Step 2 Remove the storage cover. Step 3 The PCIe slot is inside. APC-3XX9A User Manual...
  • Page 13 Step 5 After sliding the addon into the PCIe expansion slot, get the one screw as circled tightened to finish the connection. Step 6 To finish the job, just fasten the 2 screws as shown in the picture. APC-3XX9A User Manual...

  • Page 14: Brief Description Of Apc-3Xx9A

    1.6 Brief Description of the APC-3XX9A APC-3XX9A is a fanless and high-performance panel-mount industrial panel PC with 21.5”/24” TFT LCD. It is powered by an Intel 4 Gen Core i5-4402E 1.6GHz processor. The panel PC has a rich variety of functions and peripherals. It comes with two 2.5” SATA HDD space and one optional...

  • Page 15: Figure 1.5: Front View Of Apc-3249A

    Figure 1.5: Front View of APC-3249A Figure 1.6: Rear View of APC-3249A APC-3XX9A User Manual...

  • Page 16: Chapter 2 Hardware

    Supports max resolution 1920x1200 LVDS HDMI Supports HDMI 1.4a, max resolution 4096x2304 Display Port Supports max resolution 3840x2160 Multi Display Yes (Three Display) Ethernet Ethernet 10/100/1000 Mbps Controller GbE LAN1: Intel® I210, LAN2: Intel® I217LM (with v-Pro support) APC-3XX9A User Manual...
  • Page 17 Timer Interval Power Input PWR DC-in 12V~19V Requirements Power On AT/ATX Supported -AT : Directly PWR on as power input ready -ATX : Press button to PWR on after power input ready Temperature 0ºC – 60ºC Environment APC-3XX9A User Manual...

  • Page 18: Jumpers And Headers Setting Guide

    7 : Digital Input / Output Power Select 17 : USB2.0 Port (USB12) 8 : ATX/AT Mode Jumper 18 : Clear CMOS Header 9 : COM3, 4, 5, 6 Headers (RS232) 19 : BKT_PWR1 Header 10 : Printer Port Header 20 : PNL_PWR1 Header APC-3XX9A User Manual...

  • Page 19: Jumpers Setup

    BIOS, you must boot up the system first, and then shut it down before you do the clear-CMOS action. Please be noted that the password, date, time, user default profile and MAC address will be cleared only if the CMOS battery is removed. APC-3XX9A User Manual...

  • Page 20: Onboard Headers And Connectors

    Onboard Headers and Connectors APC-3XX9A User Manual...
  • Page 21 APC-3XX9A User Manual...
  • Page 22 APC-3XX9A User Manual...
  • Page 23 APC-3XX9A User Manual...
  • Page 24 APC-3XX9A User Manual...
  • Page 25 APC-3XX9A User Manual...
  • Page 26 APC-3XX9A User Manual...

  • Page 27: I/O Panel

    2.3 I/O Panel * There are two LED next to the LAN port. Please refer to the table below for the LAN port LED indications. APC-3XX9A User Manual...

  • Page 28: Installation

    4. Whenever you uninstall any component, place it on a grounded antistatic pad or in the bag that comes with the component. 2.4.3 Installation of Memory Modules (SO-DIMM) This motherboard provides two 204-pin DDR3 (Double Data Rate 3) SO-DIMM slots. APC-3XX9A User Manual...
  • Page 29 2.4.5 Expansion Slots (PCI Express, mini-PCIe and mini-SATA Slots) There is 1 PCI Express slot, 1 mini-PCIe slot and 1 mini-SATA slot on this motherboard. PCIE slot: PCIE1 (PCIE x16 slot; Blue) is used for PCI Express x16 lane width graphics cards. APC-3XX9A User Manual...
  • Page 30 APC-3XX9A User Manual...

  • Page 31: Driver Installation Guide

    CD driver page. Please follow the order from top to bottom to install those required drivers. Therefore, the drivers you install can work properly. APC-3XX9A User Manual...

  • Page 32: Chapter 3 Bios Setup

    Use < > key or < > key to choose among the selections on the menu bar, and then press <Enter> to get into the sub screen. You can also use the mouse to click your required item. APC-3XX9A User Manual...

  • Page 33: Main Screen

    3.1.2 Navigation Keys Please check the following table for the function description of each navigation key 3.2 Main Screen When you enter the UEFI Setup Utility, the Main screen will appear and display the system overview. APC-3XX9A User Manual...

  • Page 34: Advanced Screen

    FAT32/16/12 file system. If you execute Instant Flash utility, the utility will show the UEFI files and their respective information. Select the proper UEFI file to update your UEFI, and reboot your system after UEFI update process completes. APC-3XX9A User Manual...
  • Page 35 CPU C3 State Support Enable C3 sleep state for lower power consumption. CPU C6 State Support Enable C6 deep sleep state for lower power consumption. CPU C7 State Support Enable C7 deep sleep state for lower power consumption. APC-3XX9A User Manual...
  • Page 36 CPU does not support Intel Virtualization Technology. Hardware Prefetcher Use this item to turn on/off the MLC streamer prefetcher. Adjacent Cache Line Prefetch Use this item to turn on/off prefetching of adjacent cache lines. APC-3XX9A User Manual...

  • Page 37: Chipset Configuration

    Select disable to disable the integrated graphics when an external graphics card is installed. Select enable to keep the integrated graphics enabled at all times. Render Standby Use this to enable or disable Render Standby by Internal Graphics Device. The default value is [Enabled]. APC-3XX9A User Manual...
  • Page 38 Select the Video Device which will be activated during POST. This has no effect if external graphics present. Secondary boot display selection will appear based on your selection. VGA modes will be supported only on primary display. Configuration options: [VBIOS Default], [CRT], [DVI], [HDMI] and [LVDS]. The default value is [VBIOS Default]. APC-3XX9A User Manual...
  • Page 39 Keep this option enabled for higher HDD and SDD I/O performance, lower latency and increased system responsiveness. Hard Disk S.M.A.R.T. Use this item to enable or disable the S.M.A.R.T. (Self-Monitoring, Analysis, and Reporting Technology) feature. Configuration options: [Disabled] and [Enabled]. APC-3XX9A User Manual...
  • Page 40 Intel(R) Rapid Start Technology Use this item to enable or disable Intel(R) Rapid Start Technology. Intel(R) Rapid Start Technology is a new zero power hibernation mode which allows users to resume in just 5-6 seconds. The default is [Disabled]. APC-3XX9A User Manual...
  • Page 41 Use this item to enable or disable Intel(R) Smart Connect Technology. Intel(R) Smart Connect Technology keeps your e-mail and social networks, such as Twitter, Facebook, etc. updated automatically while the computer is in sleep mode. The default is [Enabled]. APC-3XX9A User Manual...
  • Page 42 MEBx Debug Message Output Use this to enable or disable MEBx Debug Message Output. The default is [Disabled]. Un-Configure ME Un-Configure ME without password. The default is [Disabled]. Amt Wait Timer Set timer to wait before sending ASF_GET_BOOT_OPTIONS. APC-3XX9A User Manual...
  • Page 43 Trigger CIRA boot. The default is [Disabled]. USB Configure Use this to enable or disable USB Configure function. The default is [Enabled]. PET Progress User can enable or disable PET Events progress to receive PET events or not. The default is [Enabled]. APC-3XX9A User Manual...

  • Page 44: Super Io Configuration

    Use this to set parameters of COM6. LPT1 Port Configuration Use this set parameters of the onboard parallel port. WDT Timeout Reset This allows users to enable/disable the Watch Dog Timer timeout to reset system. The default value is [Disabled]. APC-3XX9A User Manual...

  • Page 45: Acpi Configuration

    Use this item to enable or disable RTC (Real Time Clock) to power on the system. USB Keyboard/Remote Power On Use this item to enable or disable USB Keyboard/Remote to power on the system. USB Mouse Power On APC-3XX9A User Manual...

  • Page 46: Usb Configuration

    [UEFI Setup Only] - USB devices are allowed to use only under UEFI setup and Windows / Linux Legacy USB 3.0 Support Use this option to enable or disable legacy support for USB 3.0 devices. The default value is [Enabled]. APC-3XX9A User Manual...
  • Page 47 3.3.10 Voltage Configuration DRAM Voltage Use this to select DRAM Voltage. The default value is [Auto]. APC-3XX9A User Manual...

  • Page 48: Hardware Health Event Monitoring Screen

    This allows you to enable or disable case open detection feature. The default is value [Disabled]. Clear Status This option appears only when the case open has been detected. Use this option to keep or clear the record of previous chassis intrusion status. APC-3XX9A User Manual...

  • Page 49: Boot Screen

    BIOS Setup). 3. If you are using an external graphics card, the VBIOS must support UEFI GOP in order to boot. Boot From Onboard LAN Use this item to enable or disable the Boot From Onboard LAN feature. APC-3XX9A User Manual...
  • Page 50 AddOn ROM information when the system boots, then please select [Enabled]. Configuration options: [Enabled] and [Disabled]. The default value is [Enabled]. Please disable CSM when you enable Fast Boot option. The default value is [Enabled]. APC-3XX9A User Manual...

  • Page 51: Security Screen

    3.6 Security Screen In this section, you may set, change or clear the supervisor/user password for the system. Secure Boot Use this to enable or disable Secure Boot. The default value is [Disabled]. APC-3XX9A User Manual...

  • Page 52: Exit Screen

    Load UEFI default values for all the setup questions. F9 key can be used for this operation. Launch EFI Shell from filesystem device Attempts to Launch EFI Shell application (Shell64.efi) from one of the available filesystem devices. APC-3XX9A User Manual...

  • Page 53: Chapter 4 Installation Of Drivers

    Technology Driver, and iAMT Driver. Installation instructions are given below. Important Note: After installing your Windows operating system (Windows 7/8), you must install first the Intel Chipset Software Installation Utility before proceeding with the installation of drivers. APC-3XX9A User Manual...

  • Page 54: Intel Chipset Driver

    4.1 Intel Chipset Driver To install the Intel Chipset Driver, please follow the steps below. Step 1. Select Intel (R) Chipset QM87 Driver from the list Step 2. Click Next to setup program. APC-3XX9A User Manual...
  • Page 55 Step 3. Read the license agreement. Click Yes to accept all of the terms of the license agreement. Step 4. Click Next to continue. APC-3XX9A User Manual...
  • Page 56 Step 5. Click Next. Step 6. Select Yes, I want to restart this computer now. Click Finish, then remove any installation media from the drives. APC-3XX9A User Manual...

  • Page 57: Intel Graphics Media Accelerator Driver

    4.2 Intel Graphics Media Accelerator Driver To install the VGA drivers, follow the steps below to proceed with the installation. Step 1.Select Intel(R) HD Graphics Driver. Step 2. Tick Automatically run WinSAT and enable the Windows Aero desktop theme(if supported). Click Next. APC-3XX9A User Manual...
  • Page 58 Step 3. Read license agreement. Click Yes. Step 4. Click Next. APC-3XX9A User Manual...
  • Page 59 Step 5. Click Next. Step 6. Select Yes, I want to restart this computer now. Click Finish. APC-3XX9A User Manual...

  • Page 60: Intel(R) Network Adapter

    4.3 Intel (R) Network Adapter To install the Intel (R) Network Adapter Device Driver, please follow the steps below. Step 1. Select Intel (R) Network Adapter Realtek. Step 2. Click Next to continue. APC-3XX9A User Manual...
  • Page 61 Step 3. Read license agreement. Click I accept the terms in the license agreement. Click Next Step 4. Click Advanced Network Services. Click Next APC-3XX9A User Manual...
  • Page 62 Step 5. Click Install to begin the installation. Step 6. Click Finish to exist the wizard. APC-3XX9A User Manual...

  • Page 63: Realtek Alc662 Audio Codec Driver Installation

    4.4 Realtek ALC662 Audio Codec Driver Installation To install the Realtek ALC662 HD Audio Codec Driver, please follow the steps below. Step 1. Select Realtek ALC662 Audio Codec Driver from the list Step 2. Click Next to continue. APC-3XX9A User Manual...
  • Page 64 Step 3. Click Yes, I want to restart my computer now. Click Finish to complete the installation. APC-3XX9A User Manual...

  • Page 65: Intel(R) Usb 3.0 Driver

    4.5 Intel (R) USB 3.0 Driver To install the Intel (R) USB 3.0 Driver, please follow the steps below. Step 1. Select Intel (R) USB 3.0 Driver. Step 2. Click Next. APC-3XX9A User Manual...
  • Page 66 Step 3. Read license agreement. Click Yes Step 4. Click Next APC-3XX9A User Manual...
  • Page 67 Step 5. Click Next Step 6. Click Yes, I want to restart this computer now. Click Finish to complete the installation. APC-3XX9A User Manual...

  • Page 68: Intel(R) Smart Connect Technology Driver

    4.6 Intel (R) Smart Connect Technology Driver To install the Intel (R) Smart Connect Technology Driver, please follow the steps below. Step 1. Select Intel (R) Smart Connect Technology Driver. Step 2. Click Next APC-3XX9A User Manual...
  • Page 69 Step 3. Read license agreement. Click I accept the terms in the License Agreement. Click Next. Step 4. Select the icons in the tree below to change the way features will be installed. Click Next. APC-3XX9A User Manual...
  • Page 70 Step 5. Click Install to begin the installation. Step 6. Click Finish to exist the wizard. APC-3XX9A User Manual...
  • Page 71 Step 7. Click Yes to restart your system for the configuration changes made to Intel(R) Smart Connect Technology Driver. APC-3XX9A User Manual...

  • Page 72: Intel(R) Iamt Driver

    4.7 Intel (R) iAMT Driver To install the Intel (R) iAMT Driver, please follow the steps below. Step 1. Select Intel (R) iAMT Driver. Step 2. Click Next. APC-3XX9A User Manual...
  • Page 73 Step 3. Read license agreement. Click Yes Step 4. Click Yes APC-3XX9A User Manual...
  • Page 74 Step 5. Click Yes, I want to restart this computer now. Click Finish to complete the installation. APC-3XX9A User Manual...

  • Page 75: Chapter 5 Touch Screen Installation

    PM6500, PM6300. 5.2 Installing Software Follow the steps below to install the PenMount DMC6000 Windows 7/8 driver. Step 1. Insert the product CD, the screen below would appear. Click Touch Panel Driver. APC-3XX9A User Manual...
  • Page 76 Step 2. Click Next to continue. Step 3. Read the license agreement. Click I Agree to agree the license agreement. APC-3XX9A User Manual...
  • Page 77 Step 4. Choose the folder in which to install PenMount Windows Universal Driver. Click Install to start the installation. Step 5. Click Yes APC-3XX9A User Manual...

  • Page 78: Software Functions

    The functions of the PenMount Control Panel are Device, Multiple Monitors,Tools and About, which are explained in the following sections. Device In this window, you can find out that how many devices be detected on your system. APC-3XX9A User Manual...
  • Page 79 Standard, 4, 9, 16 or 25 points to calibrate E.g. Please run ms-dos prompt or command prompt c:\Program Files\PenMount Universa Driver\Dmcctrl.exe -calibration 0 ( Standard Calibration) Dmcctrl.exe - calibration ($) 0= Standard Calibration 4=Advanced Calibration 4 9=Advanced Calibration 9 16=Advanced Calibration 16 25=Advanced Calibration 25 APC-3XX9A User Manual...
  • Page 80 Step 1. Please select a device then click “Configure”. You can also double click the device too. Step 2. Click “Standard Calibration” to start calibration procedure APC-3XX9A User Manual...
  • Page 81 NOTE: The older the touch screen, the more Advanced Mode calibration points you need for an accurate calibration. Use a stylus during Advanced Calibration for greater accuracy. Please follow the step as below: Step 3. Come back to “PenMount Control Panel” and select Tools then click Advanced Calibration. APC-3XX9A User Manual...
  • Page 82 Advanced Calibration. The blue lines show linearity before calibration and black lines show linearity after calibration. Turn off EEPROM storage The function disable for calibration data to write in Controller. The default setting is Enable. APC-3XX9A User Manual...
  • Page 83 Beep Frequency – modifies sound frequency Beep Duration – modifies sound duration Cursor Stabilizer Enable the function support to prevent cursor shake. Use press and hold as You can set the time out and area for you need. right click APC-3XX9A User Manual...
  • Page 84 Edge Compensation You can use Edge Compensation to calibrate more subtly. About This panel displays information about the PenMount controller and driver version. APC-3XX9A User Manual...
  • Page 85 Please note once you turn on this function the rotating function is disabled. Enable the multiple display function as follows: 1. Check the Enable Multiple Monitor Support box; then click Map Touch Screens to assign touch controllers to displays. APC-3XX9A User Manual...
  • Page 86 4. Touching all screens completes the mapping and the desktop reappears on the monitors. 5. Select a display and execute the “Calibration” function. A message to start calibration appears. Click OK. APC-3XX9A User Manual...
  • Page 87 This panel displays information about the PenMount controller and this driver version. PenMount Monitor Menu Icon The PenMount monitor icon (PM) appears in the menu bar of Windows 7/8 system when you turn on PenMount Monitor in PenMount Utilities. APC-3XX9A User Manual...
  • Page 88 2. Choose the rotate function (0°, 90°, 180°, 270°) in the 3rd party software. The calibration screen appears automatically. Touch this point and rotation is mapped. NOTE: The Rotate function is disabled if you use Monitor Mapping APC-3XX9A User Manual...
