APC-3X19
User Manual
Release Date
Revision
Jan 2013
V1.0
® 2013 Aplex Technology, Inc.
All Rights Reserved.
Published in Taiwan
Aplex Technology, Inc.
15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan
Tel: 886-2-82262881 Fax: 886-2-82262883 E-mail:
aplex@aplex.com.tw
URL:
www.aplex.com.tw
APC-3X19 User Manual
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Aplex APC-3X19
Summary of Contents for Aplex APC-3X19
-
Page 1: User Manual
APC-3X19 User Manual Release Date Revision Jan 2013 V1.0 ® 2013 Aplex Technology, Inc. All Rights Reserved. Published in Taiwan Aplex Technology, Inc. 15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan Tel: 886-2-82262881 Fax: 886-2-82262883 E-mail: aplex@aplex.com.tw... -
Page 2: Warning
Disclaimer This information in this document is subject to change without notice. In no event shall Aplex Technology Inc. be liable for damages of any kind, whether incidental or consequential, arising from either the use or misuse of information in this document or in any related materials. -
Page 3: Packing List
Always disconnect power when the system is not in use. ◆ Disconnect power when you change any hardware devices. For instance, when you connect a jumper or install any cards, a surge of power may damage the electronic components or the whole system. APC-3X19 User Manual... -
Page 4: Table Of Contents
Warning!…………………………………………………………………………….……..….2 Disclaimer………………………………………………………………….…………………2 Packing List........................3 Safety Precautions......................3 Chapter 1 Getting Started 1.1 Specifications………………………………………….………….……...…..6 1.2 Dimensions…………………………………...……………….…………..8 1.3 Brief Description of APC-3X19………...………………….………………10 Chapter 2 Hardware Installation 2.1 Mainboard Specifications………………………..…………….…………16 2.2 Jumpers Setting and Connectors………………………….……………19 Chapter 3 BIOS Setup 3.1 Operations after POST Screen.............35 3.2 BIOS SETUP UTILITY..............35... - Page 5 Figures Figure 1.1: Dimensions of APC-3519………...……………………………...8 Figure 1.2: Dimensions of APC-3719………...……………………………...8 Figure 1.3: Dimensions of APC-3919………...……………………………...9 Figure 1.2: Overview of APC-3X19 ……….……..…………………………...10 Figure 2.1: Mainboard Overview……………………………………..……..…16 Figure 2.2: Mainboard Dimensions……………………………………………17 Figure 2.3: Jumpers and Connectors Location-TOP…………………...……19 Figure 2.4: Jumpers and Connectors Location- Bottom………………….…20 Figure 5.1: Bird’s Eye View of Control Board……………………………..75...
-
Page 6: Specifications
1 x PCIe x16 or 1 x PCI slot, default 1 x PCIe x16 OS support Windows XP embedded, Windows embedded standard 7, Windows 7 Pro for embedded 15” Display Type 17” 19” Max. Resolution 1024X768 1280X1024 1280X1024 Max. Color 262K 16.7M 16.7M Luminance (cd/m2) APC-3X19 User Manual... - Page 7 Mounting Panel mount/VESA 75 x 75/VESA 100 x 100 Dimensions (WxHxD) 410x310x116 439x348x119 484x400x119 (mm) Environmental 0~50 ﾟ C Operating Temperature -20~60 ﾟ C Storage Temperature 10~90% @40 ﾟ C non-condensing Storage Humidity Certificate CE/FCC Class A APC-3X19 User Manual...
-
Page 8: Dimensions
1.2 Dimensions Figure 1.1: Dimensions of APC-3519 Figure 1.2: Dimensions of APC-3719 APC-3X19 User Manual... -
Page 9: Figure 1.3: Dimensions Of Apc-3919
Figure 1.3: Dimensions of APC-3919 APC-3X19 User Manual... -
Page 10: Brief Description Of Apc-3X19
1.3 Brief Description of APC-3X19 The APC-3x19 is the fanless and high performance panel-mount industrial panel PC with 15”/17/19” TFT LCD. It powered by QM67 chipset and support Core i3/i5/i7 Processor up to i7 Quad core 2710QE. The panel PC has a rich variety of functions and peripherals. It comes with 2 x 2.5-inch hard... -
Page 11: Installation Of Hdd
1.4 Installation of HDD Step 1 There are 2 screws to deal with when enclosing or removing the HDD bracket. Step 2 There is 1 screw to deal with when enclosing or removing the HDD Tray. APC-3X19 User Manual... - Page 12 Loosen screw and draw the HDD bracket out as shown in the picture Step 4 Tighten four screws as shown in the picture. F Screw M3*5L 120° Step 5 Push into the HDD bracket as shown in the picture APC-3X19 User Manual...
- Page 13 Step 5 That’s how it should look after it has been installed. APC-3X19 User Manual...
-
Page 14: Installation Of Riser Card
1.5 Installation of Riser Card Step 1 There are 2 screws to deal with when enclosing or removing the bracket. Step 2 Remove the cover. APC-3X19 User Manual... - Page 15 Step 3 Loosen the screw. Step 4 Put the riser card in. Step 5 Tighten two screws. APC-3X19 User Manual...
-
Page 16: Mainboard Specifications
Chapter 2__________Hardware Installation 2.1 Mainboard Specifications Introduction Figure 2.1: Mainboard Overview APC-3X19 User Manual... -
Page 17: Figure 2.2: Mainboard Dimensions
170mm x 170mm CPU Support Support Socket G2,2nd Gen Intel Core i3/i5/i7 Processor Chipset Intel QM67 2 x SO-DIMM (204pins), up to 8GB DDRIII 800/1066MHz Memory Support Graphics Intel HD Grapics 2000/3000 Super I/O Winbond W83627UHG BIOS AMIBIOS APC-3X19 User Manual... - Page 18 1 x 3-pin power input connector (Wide range DC+9V~32V) 1 x ATX Power Input （2x2Pin and 3Pin, option） Management DC5V/12V output by 1x4 pin Connectors Power on/off switch by TB-522 or TB-523 Switches and LED Indicators Reset switch by MIO2 Power LED status by MIO2 APC-3X19 User Manual...
-
Page 19: Jumpers Setting And Connectors
Temperature Storage: -40℃ to 85℃ Humidity 10% - 90%, non-condensing, operating 12V/3.80A (Intel i5-2430M 2.4GHz Processor with 4GB Power Consumption DDR3) EMI/EMS Meet CE/FCC class A 2.2 Jumpers Setting and Connectors Jumpers and Connectors Location-TOP Figure 2.3: APC-3X19 User Manual... -
Page 20: Figure 2.4: Jumpers And Connectors Location- Bottom
When entering the POST screen, press the <DEL> key to enter CMOS Setup Utility to load optimal defaults. e) After the above operations, save changes and exit BIOS Setup. 2. BAT1 : (1.25mm Pitch 1X2 box Pin Header) 3.0V Li battery is embedded to provide power for CMOS. APC-3X19 User Manual... - Page 21 Close 2-3 ATX Power 5. DCIN: (5.08mm Pitch 1x3 Pin Connector),DC9V ~ DC32V System power input connector。 Pin# Power Input Pin1 DC+9V~32V Pin2 Ground Pin3 6. ATX12V_IN (ATX Power option): (2x2 Pin Connector),DC12V System power input connector. APC-3X19 User Manual...
- Page 22 (Socket G2), installing the 2nd GEN intel Core i3/i5/i7CPU Socket. 10. CPU_FAN1/SYS_FAN1: (2.54mm Pitch 1x3 Pin Header),Fan connector, cooling fans can be connected directly for use. You may set the rotation condition of cooling fan in menu of BIOS CMOS Setup. Pin# Signal Name APC-3X19 User Manual...
- Page 23 (2.0mm Pitch 1x6 box Pin Header), Backlight control connector for LVDS1. Pin# Signal Name +DC12V +DC12V Ground Ground BKLT_EN BKLT_CTRL Note: Pin6 is backlight control signal, support DC or PWM mode, mode select at BIOS CMOS menu. APC-3X19 User Manual...
- Page 24 LA_D3_N LB_D3_P LA_D3_P 15. JP_HDMI: (2.0mm Pitch 1x2 Pin Header), Reserved. 16. HDMI1: (HDMI 19P Connector), High Definition Multimedia Interface connector. 17. JP_DVI: (2.0mm Pitch 1x2 Pin Header), Reserved. 18. DVI-I: (DVI-I Connector), Digital Visual Interface-Integrated connector. APC-3X19 User Manual...
- Page 25 (option) Pin3-5, Pin6-8, Pin9-11, Pin10-12, Pin17-18 RS485 Close: (option) Pin3-5, Pin6-8, Pin9-11, Pin10-12, Pin15-16 Pin19-20 22. COM1: (Type DB9), Rear serial port, standard DB9 Male serial port is provided to make a direct connection to serial devices. APC-3X19 User Manual...
- Page 26 Signal Name 422_R- 422_R+ 422_T- 422_T+ Ground RS485 (option): Pin# Signal Name 485- 485+ Ground 23. JP2: (2.0mm Pitch 2x3 Pin Header),COM2 jumper setting, pin 1~6 are used to select signal out of pin 9 of COM2 port. APC-3X19 User Manual...
- Page 27 COM cable connection. Signal Name Pin# Pin# Signal Name Ground 26. JP3: (2.0mm Pitch 1x3 Pin Header) COM6 setting jumper, pin 1~3 are used to select signal out of pin 9 of COM6 port. JP3 Pin# Function APC-3X19 User Manual...
- Page 28 LAN1/LAN2: (RJ45 Connector), Rear LAN port, Two standard 10/100/1000M RJ-45 Ethernet ports are provided. Used Realtek RTL8111D chipset, LINK LED (green) and ACTIVE LED (yellow) respectively located at the left-hand and right-hand side of the Ethernet port indicate the activity and transmission state of LAN. APC-3X19 User Manual...
- Page 29 33. LED1 Power status, LED STATUS. Green LED for Motherboard 34. PCIE_16X (option) (4x30 Pin), Riser Card expansion connector. Can expand support one PCIeX16 or two PCIeX8 Signal. ASB-M8671T：PCIE_16X connector in the top. ASB-M8671B：PCIE_16X connector in the Bottom. APC-3X19 User Manual...
- Page 30 485+ / 422TX+ 422RX+ COM3 485- / 422TX- 422RX- RS422 COM3 3P3V_S0 Ground WAN_LED RS485 5V_S5 5V_S5 RXD4 DCD4- DTR4- TXD4 COM4 COM4 DSR4- Ground CTS4- RTS4- 5V_S5 RI4- 5V_USB_1011 5V_S5 USB10_N USB9_N USB10 USB9 USB10_P USB9_P APC-3X19 User Manual...
- Page 31 Pin2- Pin4: POWER LED, They are used to connect power LED. When the system is powered on or under S0/S1 state, the LED is normally on, when the system is under S4/S5 state, the LED is off. USB01 OC-, “USB01_OC-“ Signal. Pin3: Pin5: USB23 OC-,“USB23_OC-“ Signal. APC-3X19 User Manual...
- Page 32 Signal Name +DC5V Ground Note: Output current of the connector must not be above 1A. 42. SATA_P2/SATA_P4: (2.5mm Pitch 1x4 box Pin Header), Two onboard 5V and 12V output connectors are reserved to provide power for SATA devices. APC-3X19 User Manual...
- Page 33 47. H3/H4: M_SATA1 SCREW HOLES, H3 and H4 for mini MSATA card (50.95mmx30mm Socket 52 Pin) assemble. 48. CPU SCREW HOLES: CPU FAN SCREW HOLES, Four screw holes for fixed CPU Cooler assemble. 49. TB-525E161: APC-3X19 User Manual...
- Page 34 TB-525E161 connect to ASB-M8671T PCIE_16X connector, PCIE_16X is located at the top,It provides one PCIE X16 slot. APC-3X19 User Manual...
-
Page 35: Bios Setup
Press [Delete] key to enter BIOS Setup utility during POST, and then a main menu containing system summary information will appear. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit APC-3X19 User Manual... -
Page 36: System Overview
Advanced Chipset Boot Security Save & Exit BIOS Information Choose the system BIOS Vendor American Megatrends Default language Core Version 4.6.4.0 Compliancy UEFI 2.1 Project Version M8671V01 X64 Build Date and Time 05/21/2012 16:15:28 System Language [English] APC-3X19 User Manual... -
Page 37: Advanced Settings
Security Save & Exit Legacy OpROM Support Enable or Disable Boot Launch Storage OpROM [Disabled] Option for Legacy Launch Storage OpROM [Enabled] Network Devices. ►PCI Subsystem Settings ►ACPI Settings ►CPU Configuration ►SATA Configuration ►Thermal Configuration ►PCH-FW Configuration APC-3X19 User Manual... - Page 38 [128 PCI Bus Clocks] [160 PCI Bus Clocks] [192 PCI Bus Clocks] [224 PCI Bus Clocks] [248 PCI Bus Clocks] VGA Palette Snoop: [Disabled] [Enabled] PERR# Generation: [Disabled] [Enabled] SERR# Generation: [Disabled] [Enabled] PCI Express Device Settings: Relaxed Ordering: APC-3X19 User Manual...
- Page 39 [2048 Bytes] [4096 Bytes] PCI Express Link Settings: ASPM Support: [Disabled] [Enabled] WARNING:Ebabling ASPM may cause some PCI-E devices to fail Extended Synch: [Disabled] [Enabled] 3.4.2 ACPI Settings Enable ACPI Auto Configuration: [Disabled] [Enabled] Enable Hibernation: [Enabled] APC-3X19 User Manual...
- Page 40 L1 Code Cache 32 KB x 2 L2 Cache 256 KB x 2 L3 Cache 3072 KB CPU Speed 2400 MHz 64-bit Supported Hyper-Threading: [Enabled] [Disabled] Active Processor Cores [All] Limit CPUID Maximum: [Disabled] [Enabled] Execute Disable Bit: [Enabled] APC-3X19 User Manual...
- Page 41 Serial ATA Port 0 Empty Software Preserve Unknown Serial ATA Port 1 Empty Software Preserve Unknown Serial ATA Port 2 Empty Software Preserve Unknown Serial ATA Port 3 Empty Software Preserve Unknown Serial ATA Port 4 Empty Software Preserve Unknown APC-3X19 User Manual...
- Page 42 Legacy USB Support: [Enabled] [Disabled] EHCI Hand-off: [Disabled] [Enabled] Port 60/64 Emulation [Enabled] [Disabled] USB hardware delays and time-outs: USB transfer time-out: [20 sec] [10 sec] [5 sec] [1 sec] Device reset time-out: [20 sec] [10 sec] APC-3X19 User Manual...
- Page 43 : +11.685 V +3.3V : +3.280 V +1.5V : +1.520 V 5VSB : +5.010 V VBAT : +3.136 V 3.4.10 Sandybridge PPM Configuration Sandybridge PPM Configuration EIST [Enabled] [Disabled] Turbo Mode [Enabled] [Disabled] CPU C3 Report [Enabled] [Disabled] APC-3X19 User Manual...
-
Page 44: Chipset Settings
F1 : General Help F2: Previous Values F3:Optimized Defaults F4:Save and Exit ESC Exit Version 2.10.1208. Copyright (C) 2010 American Megatrends , Inc. 3.5.1 ► System Agent (SA) Configuration ►PCH-IO Configuration System Agent (SA) Configuration System Agent RC Version 1.2.1.0 APC-3X19 User Manual... - Page 45 650 MHz Graphics Turbo IMON Current Primary Display [Auto] [IGFX] [PEG] [PCI] Internal Graphics [Auto] [Disabled] [Enabled] GTT Size [2MB] [1MB] Aperture Size [256MB] [128MB] [512MB] DVMT Pre-allocated [64MB] [0MB] [32MB] [96MB] [128MB] [160MB] [192MB] [224MB] [256MB] APC-3X19 User Manual...
- Page 46 LVDS] [1366 X 768 LVDS] [1680 X 1050 LVDS] [1920 X 1200 LVDS] [1440 X 900 LVDS] [1600 X 900 LVDS] [1024 X 768 LVDS2] [1280 X 800 LVDS] [1920 X 1080 LVDS] [2048 X 1536 LVDS] APC-3X19 User Manual...
- Page 47 [Level 2 ] [Level 3 ] [Level 4 ] [Level 5 ] Spread Spectrum clock chip [Off ] [Hardware ] [Software ] TV1 Standard [VBIOS Default] [NTSC_M] [NTSC_M_J] [NTSC_433] [PAL_B] [PAL_G] [PAL_D] [PAL_H] [PAL_I] [PAL_M] [PAL_N] [SECAM_L] APC-3X19 User Manual...
- Page 48 [SECAM_K] [HDTV_STD_SMPTE_240M_1080i59] [HDTV_STD_SMPTE_240M_1080i60] [HDTV_STD_SMPTE_295M_1080i50] [HDTV_STD_SMPTE_295M_1080p50] [HDTV_STD_SMPTE_296M_720p50] [HDTV_STD_SMPTE_296M_720p60] [HDTV_STD_CEAEIA_7702A_480p60 [HDTV_STD_CEAEIA_7702A_480i60] TV2 Standard [VBIOS Default] [NTSC_M] [NTSC_M_J] [NTSC_433] [PAL_B] [PAL_G] [PAL_D] [PAL_H] [PAL_I] [PAL_M] [PAL_N] [SECAM_L] [SECAM_B] [SECAM_D] [SECAM_G] [SECAM_H] [SECAM_K] [HDTV_STD_SMPTE_240M_1080i59] [HDTV_STD_SMPTE_240M_1080i60] [HDTV_STD_SMPTE_295M_1080i50] [HDTV_STD_SMPTE_295M_1080p50] [HDTV_STD_SMPTE_296M_720p50] [HDTV_STD_SMPTE_296M_720p60] [HDTV_STD_CEAEIA_7702A_480p60 [HDTV_STD_CEAEIA_7702A_480i60] APC-3X19 User Manual...
- Page 49 [Not Present] PEG1 – Gen X [Auto] [Gen1] [Gen2] PEG2 [Not Present] PEG2 – Gen X [Auto] [Gen1] [Gen2] PEG3 [Not Present] PEG3 – Gen X [Auto] [Gen1] [Gen2] Always Enable PEG [Disabled] [Enabled] PEG ASPM [Disabled] APC-3X19 User Manual...
- Page 50 CAS Latency (tCL) Minimum delay time CAS to RAS (tRPmin) Row Precharge (tRPmin) Active to Precharge (tRPmin) DIMM profile [Default DIMM profile] [XMP profile 1] [XMP profile 2] Memory Frofile [Auto] [1067] [1333] [1600] [1867] [2133] ECC Support [Enabled] APC-3X19 User Manual...
- Page 51 Memory Scrambler [Disabled] [Enabled] MRC Fast Boot [Enabled] [Disabled] Force Cold Reset [Enabled] [Disabled] Scrambler Seed Generation off [Disabled] [Enabled] Memory Remap [Enabled] [Disabled] Channel A DIMM Control [Enabled Both DIMMS] [Disabled DIMM0] [Disabled DIMM1] [Disabled Both DIMMS] APC-3X19 User Manual...
- Page 52 PECI Injecred Temperature [Disabled] [Enabled] EXTTS# via TS-on-Board [Disabled] [Enabled] EXTTS# via TS-on-DIMM [Disabled] [Enabled] Virtual Temperature Sensor (VTS) [Disabled] [Enabled] ►GT-Power Management Control GT Info GT2 (0X116) RC6 (Render Standby) [Enabled] [Disabled] GT overClocking Support [Disabled] [Enabled] APC-3X19 User Manual...
-
Page 53: Boot Settings
F2: Previous Values F3:Optimized Defaults F4:Save and Exit ESC Exit Version 2.10.1208. Copyright (C) 2010 American Megatrends , Inc. Setup Prompt Timeout Bootup Numlock State [On] [off] Quiet Boot [Enabled] [Disabled] CSM16 Module Verison 07.64 Gatea20 Active APC-3X19 User Manual... -
Page 54: Security Settings
The password length must be 3 to 20 Characters long. Enter: Select Administrator Password +/- : Charge Opt. User Password F1 : General Help F2: Previous Values F3:Optimized Defaults F4:Save and Exit ESC Exit Version 2.10.1208. Copyright (C) 2010 American Megatrends , Inc. 3.7.1 Administrator Password APC-3X19 User Manual... -
Page 55: Save & Exit Settings
Main Advanced Chipset Boot Security Save & Exit Save Changes and Exit Exit system setup after Discard Changes and Exit Saving the changes. Save Changes and Reset Discard Changes and Reset Save Options Save Changes Discard Changes APC-3X19 User Manual... - Page 56 Save Setup Values Save configuration? [Yes] [No] Discard Changes Load Previous Values Load Previous Values? [Yes] [No] Restore Defaults Load Optimized Defaults Load optimized Defaults? [Yes] [No] Save user Defaults Save Values as User Defaults Save configuration? APC-3X19 User Manual...
- Page 57 [Yes] [No] Restore user Defaults Restore User Defaults Restore User Defaults? [Yes] [No] Launch EFI Shell from filesystem device WARNING Not Found [ok] APC-3X19 User Manual...
-
Page 58: Chapter 4 Installation Of Drivers
Driver, Microsoft .NET Framework 3.5 Service, Touch Panel Driver. Installation instructions are given below. Important Note: After installing your Windows operating system (Windows XP), you must install first the Intel Chipset Software Installation Utility before proceeding with the installation of drivers. APC-3X19 User Manual... -
Page 59: Intel Chipset Driver
4.1 Intel Chipset Driver To install the Intel chipset driver, please follow the steps below. Step 1. Access Industrial Panel PC. Select Intel QM67 Chipset Driver. Step 2. Click Next to setup program. APC-3X19 User Manual... - Page 60 Step 3. Read the license agreement. Click Yes to accept the terms of the license agreement. Step 4. Click Next to continue. APC-3X19 User Manual...
- Page 61 Step 5. Click Next. Step 6. Select Yes, I want to restart this computer now. Click Finish then remove any installation media from the drives. APC-3X19 User Manual...
-
Page 62: Intel (R) Vga Chipset Driver
4.2 Intel (R) VGA Chipset Driver To install the VGA drivers, follow the steps below to proceed with the installation. Step 1. Select Intel(R) VGA Chipset Driver. Step 2. Click Yes to continue. APC-3X19 User Manual... - Page 63 Step 3. Click Next to continue setup program. Step 4. Read the license agreement. Click Yes to accept the license agreement. APC-3X19 User Manual...
- Page 64 Step 5. Click Next. Step 6. Click Continue Anyway. APC-3X19 User Manual...
- Page 65 Step 7. Click Continue Anyway. Step 8. Click Next. APC-3X19 User Manual...
- Page 66 Step 9. Select Yes, I want to restart this computer now. Click Finish. APC-3X19 User Manual...
-
Page 67: Intel(R) Network Adapter Driver
4.3 Intel(R) Network Adapter Driver To install the Intel 82574L Network adapter Driver, please follow the steps below. Step 1. Select Intel(R) Network Adapter. Step 1. Wait for extracting the files then click Next to continue. APC-3X19 User Manual... - Page 68 Step 2. Click Next. Step 3. Read the license agreement. Select I accept the terms in the license agreement then click Next to continue. APC-3X19 User Manual...
- Page 69 Step 4. Select Drivers, Intel(R) PROSet for Windows* Device Manager, Advanced Network Services. Click Next to continue. Step 5. Click Install to begin the installation. APC-3X19 User Manual...
- Page 70 Step 6. Click Finish to compete the installation. APC-3X19 User Manual...
-
Page 71: Realtek Hd Audio Driver Installation
To install the Realtek High Definition (HD) Audio driver, please follow the steps below. Step 1. Select Realtek ALC662 HD Audio Codec Driver from the list. Step 2. Wait for extracting the files then click Next to continue. APC-3X19 User Manual... - Page 72 Step 3. Click Next to continue the installation. Step 4. Select Yes, I want to restart my computer now. then click Finish. APC-3X19 User Manual...
-
Page 73: Microsoft .Net Framework 3.5 Service
To install the Realtek High Definition (HD) Audio driver, please follow the steps below. Step 1. Select Microsoft .NET Framework 3.5 Service. Step 2. Select I have read and ACCEPT the terms of the License Agreement. Click Install. APC-3X19 User Manual... - Page 74 Step 2. Wait for installation. Step 3. Click Exit to complete the installation. APC-3X19 User Manual...
-
Page 75: Chapter 5 Touch Screen Installation
PM6500, PM6300. 5.2.1 Installing Software If you have an older version of the PenMount Windows 2000/XP driver installed in your system, please remove it first. Follow the steps below to install the PenMount DMC6000 Windows 2000/XP driver. APC-3X19 User Manual... - Page 76 “Unknown Device”. Do not use this hardware wizard. Press Cancel. Step 2. Insert the Aplex product CD install setup.exe. the screen below would appear. Se touch panel driver Step 3. Click Next to continue.
- Page 77 Step 4. Read the license Agreement. Click I agree to agree the license agreement. Step 5. Choose the folder in which to install PenMount Windows Universal Driver. Click Install to start the installation. APC-3X19 User Manual...
- Page 78 Step 6. Wait for installation. Then click Next to continue. Step 7. Click OK. APC-3X19 User Manual...
- Page 79 Step 8 Click Finish to compete installation. APC-3X19 User Manual...
-
Page 80: Software Functions
‘Advanced Calibration’ adjusts aging touch screens. Standard Calibration Click this button and arrows appear pointing to red squares. Use your finger or stylus to touch the red squares in sequence. After the fifth red point calibration is complete. To skip, press ‘ESC’. APC-3X19 User Manual... - Page 81 -calibration 0 ( Standard Calibration) Dmcctrl.exe - calibration ($) 0= Standard Calibration 4=Advanced Calibration 4 9=Advanced Calibration 9 16=Advanced Calibration 16 25=Advanced Calibration 25 Step 1. Please select a device then click Configure. You can also double click the device too. APC-3X19 User Manual...
- Page 82 Step 2. Click Standard Calibration to start calibration procedure NOTE: The older the touch screen, the more Advanced Mode calibration points you need for an accurate calibration. Use a stylus during Advanced Calibration for greater accuracy. Please follow the step as below: APC-3X19 User Manual...
- Page 83 Step 3. Come back to PenMount Control Panel and select Tools then Click Advanced Calibration. Step 4. Select Device to calibrate, then you can start to do “Advanced Calibration”. NOTE: Recommend to use a stylus during Advanced Calibration for greater accuracy. APC-3X19 User Manual...
- Page 84 Setting APC-3X19 User Manual...
- Page 85 About This panel displays information about the PenMount controller and driver version. APC-3X19 User Manual...
- Page 86 Note: Before you can use multiple monitors you need to map each monitor. Enable the multiple display function as follows: Step 1.In PenMount Control Panel, under Multiple Monitors tag, check the “Multiple Monitor Support” box. Then click “Map Touchscreens” to assign touch controllers to displays. APC-3X19 User Manual...
- Page 87 Step 2. When the mapping screen message appears, click OK. APC-3X19 User Manual...
- Page 88 4. If you more monitor mapping one touch screen, Please press ‘S’ to skip mapping step. Tools Draw Tests or demonstrates the PenMount touch screen operation. Advanced Calibration Enable Advanced Calibration function Right Button Icon Enable right button function. The icon can show on Desktop or System Tray (menu bar). APC-3X19 User Manual...
- Page 89 You can see how many devices of PenMount controller that are plugged to your system PenMount Monitor Menu Icon The PenMount monitor icon (PM) appears in the menu bar of Windows 2000/XP system when you turn on PenMount Monitor in PenMount Utilities. APC-3X19 User Manual...
- Page 90 • Intel 845G/GE Display Driver Rotate Function Configuring the Rotate Function 1. Install the rotation software package. 2. Choose the rotate function (0°, 90°, 180°, 270°) in the 3rd party software. The calibration screen appears automatically. Touch this point and rotation is mapped. APC-3X19 User Manual...
- Page 91 NOTE: The Rotate function is disabled if you use Monitor Mapping APC-3X19 User Manual...
