APC-3x93P_3X93R
(SBC-7106 – 15")
User Manual
Release Date
_
Revision
Oct. 2014
V2.1
® 2014 Aplex Technology, Inc.
All Rights Reserved.
Published in Taiwan
Aplex Technology, Inc.
15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan
Tel: 886-2-82262881 Fax: 886-2-82262883 E-mail:
aplex@aplex.com.tw
URL:
www.aplex.com.tw
APC-3x93P_R (SBC-7106) User Manual
1

Advertisement

Table of Contents
loading

Related Manuals for Aplex APC-3x93P_3X93R

Summary of Contents for Aplex APC-3x93P_3X93R

  • Page 1 (SBC-7106 – 15”) User Manual Release Date Revision Oct. 2014 V2.1 ® 2014 Aplex Technology, Inc. All Rights Reserved. Published in Taiwan Aplex Technology, Inc. 15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan Tel: 886-2-82262881 Fax: 886-2-82262883 E-mail: aplex@aplex.com.tw...

  • Page 2: Warning

    Warning!___________________________________ This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions manual, it may cause interference to radio communications. It has been tested and found to comply with the limits for a Class A computing device pursuant to FCC Rules, which are designed to provide reasonable protection against such interference when operated in a commercial environment.

  • Page 3: Packing List

    Packing List Accessories (as ticked) included in this package are: □ Adaptor □ Driver & manual CD disc □ Other.___________________(please specify) Safety Precautions Follow the messages below to prevent your systems from damage: ◆ Avoid your system from static electricity on all occasions. ◆...

  • Page 4: Table Of Contents

    Table of Contents______________________ Warning!…………………………………………………………………………….……..….2 Packing List…………………………………………………………………………………..3 Safety Precautions…………………………………………………………………………..3 Chapter 1 Getting Started 1.1 Features…….……………………………………..….……………………..6 1.2 Specifications……………………………...……………………………..6 1.3 Dimensions……………………………………………………….……..…8 1.4 Brief Description………………………………………………….……..…9 Chapter 2 Hardware 2.1 Mainboard………………..…….……………………………………..…..10 2.2 Introduction…….………………….……………………………………….13 2.3 Jumpers Setting and Connectors............15 Chapter 3 BIOS Setup 3.1 Operations after POST Screen............21 3.2 BIOS Setup Utility……................21 3.3 Main Settings…..................22 3.4 Advanced Settings................23...
  • Page 5 Chapter 5 Touch Screen Installation 5.1 Windows 2000/XP/2003/Vista/WIN7 Universal Driver Installation for PenMount 6000 Series…..………………………………………………50 5.2 Software Functions……………………………………………………..60 Figures Figure 1.1: Dimensions of APC-3593P(R).……………………………..…..8 Figure 1.2: Front view of APC-3X93P(R)…………..……………………...…9 Figure 1.3: Rear view of APC-3X93P(R)…………..………………………...…9 Figure 2.1: Mainboard Dimensions…………………………………..……..12 Figure 2.2: Jumpers and Connectors Location_ Board Top………………...13 Figure 2.3: Jumpers and Connectors Location_ Board Bottom…………..14 APC-3x93P_R (SBC-7106) User Manual...

  • Page 6: Getting Started

    Chapter 1 Getting Started 1.1 Features Fanless and Low Power Consumption Stainless Steel Panel PC Intel® Atom™ Processor D2550 (1M Cache, 1.8GHz)  Onboard 2GB DDR3, optional 4G 11~32V DC wide-ranging power input M12 I/O Connector Full Flat bezel Design, Total 6 sides IP65/ IP69K Projective capacitive touch/ Resistive Type 1.2 Specifications APC-3593P(R)
  • Page 7 Max. Resolution 1024x768 Max. Color Contrast Ratio 800 : 1 Luminance (cd/m²) View angle(H°/V°) 160/145 Touch Screen (for APC-3X93P) Type Projective Capacitive Interface Light Transmission(%) Touch Screen (for APC-3X93R) Type Resistive touch window Interface Default RS-232 Light Transmission(%) Power Power Input 11~32V DC Power Consumption Max:19.5W...

  • Page 8: Dimensions

    1.3 Dimensions Figure 1.1: Dimensions of APC-3593P(R) APC-3x93P_R (SBC-7106) User Manual...

  • Page 9: Brief Description

    1.4 Brief Description of APC-3X93P/3X93R APC-3x93P/3X93R series comes with IP65 certificated and is powered by Intel Atom D2550 to provide low power consumption. The stainless steel chassis design makes it exceptionally suitable for strict hygiene regulations for food/chemical industry, medical, restaurant/kitchen applications, storage management and outdoor /information segment and so on.

  • Page 10: Chapter 2 Hardware

    Chapter 2 Hardware 2.1 Mainboard Specifications Board Size 170mm x 113mm CPU Support Intel Atom Processor D2550 (1M Cache, 1.8 GHz) Chipset Intel NM10 Express Memory Onboard 2GB DDRIII SDRAM Support Integrated Intel GMA 3600 (N2600) Graphics Display Mode 1 x CRT Port 1 x LVDS1 (18/24-bit single LVDS) Support Up to 1920 x1200 for CRT...
  • Page 11 Digital I/O 8-bit digital I/O Pin header via CN2 4-bit digital Input 4-bit digital Output 4-bit digital I/O Pin header via CN3 2-bit digital Input 2-bit digital Output Battery Support CR2477 Li battery by 2-pin header Audio Realtek ALC662 HD audio codec Line-in, Line-out, MIC via 2x6-pin header Audio Line out in phone jack Keyboard...

  • Page 12: Figure 2.1: Mainboard Dimensions

    (units :mm) Figure 2.1: Mainboard Dimensions APC-3x93P_R (SBC-7106) User Manual...

  • Page 13: Introduction

    2.2 Introduction SBC-7106 is a 4" industrial motherboard developed on the basis of Intel Cedarview-M Processors and NM10, which provides abundant peripheral interfaces to meet the needs of different customers. Also, it features dual GbE ports, 3-COM ports and one Mini PCIE configuration, one VGA port, one HDMI port, one LVDS interface.

  • Page 14: Figure 2.3: Jumpers And Connectors Location_ Board Bottom

    Board Bottom Figure 2.3: Jumpers and Connectors Location_ Board Bottom APC-3x93P_R (SBC-7106) User Manual...

  • Page 15: Jumpers Setting And Connectors

    2.3 Jumpers Setting and Connectors 1. JP5: (2.0mm Pitch 1X2 box Pin Header),ATX Power and Auto Power on jumper setting. Mode Open ATX Power Close Auto Power on (Default) 2. BAT1 : (1.25mm Pitch 1X2 box Pin Header) 3.0V Li battery is embedded to provide power for CMOS.
  • Page 16 CRT_V_SYNC CRT_DDCCLK Ground Ground 6. RS-232: (Switch),COM1 jumper setting, it provides selectable RS232 or RS422 or RS485 serial signal output. Function S_232 Pin# RS232 (Default) Pin1, Pin2, Pin3, Pin4, Pin5 RS422 OFF: (option) Pin1, Pin2, Pin3, Pin4, Pin5 RS485 OFF: (option) Pin1, Pin2, Pin3, Pin4, Pin5 7.
  • Page 17 RS232 (Default): Pin# Signal Name DCD# (Data Carrier Detect) RXD (Received Data) TXD (Transmit Data) DTR (Data Terminal Ready) Ground DSR (Data Set Ready) RTS (Request To Send) CTS (Clear To Send) JP1 select Setting (RI/5V/12V) BIOS Setup： Advanced/W83627UHG Super IO Configuration/Serial Port 1 Configuration【RS-232】...
  • Page 18 BIOS Setup： Advanced/W83627UHG Super IO Configuration/Serial Port 1 Configuration【RS-485】 10. COM2: (Type DB9 Rear serial port, standard DB9 Male serial port is provided to make a direct connection to serial devices. Pin# Signal Name DCD# (Data Carrier Detect) RXD (Received Data) TXD (Transmit Data) DTR (Data Terminal Ready) Ground...
  • Page 19 (Diameter 3.5mm Jack), HD Audio port, An onboard Realtek ALC662 codec is used to provide high quality audio I/O ports. Line Out can be connected to a headphone or amplifier. 15. USB45: USB4/USB5：(Double stack USB type A), Rear USB connector, it provides up to 4 USB2.0 ports, High-speed USB 2.0 allows data transfers up to480 Mb/s ,support USB full-speed and low-speed signaling.
  • Page 20 20. CN3 (1.27mm Pitch 2X30 Pin Header), For expand output connector, It provides four GPIO, Two USB 2.0,one PS/2 mouse，one PS/2 keyboard,two uart,one PCIe x1,one SMbus. Function Signal Name Pin# Pin# Signal Name Function 5V_S5_USB 5V_S5_USB 5V_S5_USB 5V_S5_USB USB23_OC CLKREQPSON_ATX- USB2 USB2_N USB2_P...

  • Page 21: Chapter 3 Bios Setup

    Chapter 3 BIOS Setup 3.1 Operations after POST Screen After CMOS discharge or BIOS flashing operation,.Press [Delete] key to enter CMOS Setup. After optimizing and exiting CMOS Setup, the POST screen displayed for the first time is as follows and includes basic information on BIOS, CPU, memory, and storage devices. 3.2 BIOS Setup Utility Press [Delete] key to enter BIOS Setup utility during POST, and then a main menu containing system summary information will appear.

  • Page 22: Main Settings

    3.3 Main Settings APC-3x93P_R (SBC-7106) User Manual...

  • Page 23: Advanced Settings

    System Time Set the system time, the time format is : Hour: 0 to 23 Minute: 0 to 59 Second 0 to 59 System Date Set the system date, the date format is: Note that the ‘Day’ automatically changes when you set the date. Day: Month: 01 to 12...
  • Page 24 PCI Latency Timer: [32 PCI Bus Clocks] [64 PCI Bus Clocks] [96 PCI Bus Clocks] [128 PCI Bus Clocks] [160 PCI Bus Clocks] [192 PCI Bus Clocks] [224 PCI Bus Clocks] [248 PCI Bus Clocks] VGA Palette Snoop: [Disabled] [Enabled] PERR# Generation: [Disabled] [Enabled]...
  • Page 25 S3 Video Repost: [Disabled] [Enabled] 3.4.3 CPU Configuration Processor Type Intel(R) Atom(TM) CPU N2600 EMT64 Not Supported Processor Speed 1600 MHz System Bus Speed 400 MHz Ratio Status Actual Ratio System Bus Speed 400 MHz Processor Stepping 30661 Microcode Revision L1 Cache RAM 2 x 56k L2 Cache RAM...
  • Page 26 Active Trip Point Hi [71C] Passive Trip Point [95] Passive TC1 Value Passive TC2 Value Passive TSP Value 3.4.5 IDE Configuration SATA Port0 Not Present SATA Port1 Not Present SATA Controller(S): [Enabled] [Disabled] Configure SATA as: [IDE] [AHCI] Misc Configuration for hard disk 3.4.6 USB Configuration USB Configuration USB Devices:...
  • Page 27 [Auto] [Manual] Mass Storage Devices： Multiplecard Reader 1 [Auto] [Floppy] [Forced FDD] [Hard Disk] [CD-ROM] 3.4.7 W83627UHG Super IO Configuration W83627UHG Super IO ch W83627UHG Serial Port 1 Configuration UART Mode Selection： [RS-232] [RS-485] [RS-422] Serial Port 2 Configuration Serial Port 3 Configuration UART Mode Selection：...
  • Page 28 AVCC : +5.203V VCC5V : +5.216V VSB5 : +5.203V VBAT : +3.334V 3.4.9 Serial Port Console Redirection COM0 Console Redirection [Enabled] [Disabled] Console Redirection Settings Serial Port for Out-of-Band Management/ Windows Emergency Management Services (EMS) Console Redirection [Disabled] [Enabled] Console Redirection Settings 3.4.10 PPM Configuration PPM Configuration EIST:...

  • Page 29: Chipset Settings

    [Enabled] [Disabled] C-state POPUP [Enabled] [Disabled] 3.5 Chipset Settings 3.5.1 Host Bridge ►Memory Frequency and Timing ►Intel IGD Configuration ******* Memory Information ******* Memory Frequency 800 MHz(DDR3) Tot al Memory 2048 MB DIMM#0 Not Present DIMM#1 2048 MB Memory Frequency and Timing APC-3x93P_R (SBC-7106) User Manual...
  • Page 30 MRC Fast Boot [Enabled] [Disabled] Max TOLUD [Dynamic] [1GB] [1.25GB] [1.5GB] [1.75GB] [2GB] [2.25GB] [2.5GB] [2.75GB] [3GB] [3.25GB] Intel IGD Configuration IGFX – Boot Type [VBIOS Default] [VGA] [LVDS] [VGA + LVDS] LCD Panel Type [VBIOS Default] [640x480，18bit] [800x480，18bit] [800x600，18bit] [1024x600，18bit ] [1024x768，18bit ] [1280x768，18bit ]...
  • Page 31 [Force Scaling] [off] [Maintain Aspect Ratio] Active LFP [LVDS] [No LVDS] [EDP] IGD Clock Source [External Clock] [Internal Clock] Fixed Graphics Memory [128MB] [256MB] ALS Support [Disabled] [Enabled] Back light Control [DC] [PWM] Back light Logic [Positive] [Negative] Back light Control Lev [Auto] [Disabled] [Level 8]...
  • Page 32 [Level 9] [Level 10] [Level 11] [Level 12] [Level 13] [Level 14] [Level 15] 3.5.2 South Bridge TPT Devices PCI Express Root Port 0 PCI Express Root Port 1 PCI Express Root Port 2 PCI Express Root Port 3 DMI Link ASPM Control [Enabled] [Disabled] PCI-Exp.

  • Page 33: Boot Settings

    3.6 Boot Settings Setup Prompt Timeout Bootup Numlock State [On] [off] Quiet Boot [Disabled] [Enabled] Fast Boot [Enabled] [Disabled] APC-3x93P_R (SBC-7106) User Manual...
  • Page 34 Skip VGA [Enabled] [Disabled] Skip USB [Disabled] Enabled] Skip PS2 [Disabled] [Enabled] CSM16 Module Version 07.69 Gatea20 Active [Upon Request] [Always] Option ROM Messages [Force BIOS] [Keep Current] Interrupt 19 Capture [Immediate] [Postponed] Boot Option #1 Boot Option #2 …… Sets the system boot order [SATA PM:*** …...
  • Page 35 [Legacy only] [UEFI only] Launch PXE OpROM poli [Do not Launch] [UEFI only] [Legacy only] Launch Storage OpROM [Legacy only] [Do not Launch] [UEFI only] Launch Video OpROM po [Do not Launch] [UEFI only] [Legacy only] Other PCI device ROM [UEFI OpROM] [Legacy OpROM] APC-3x93P_R (SBC-7106) User Manual...

  • Page 36: Security Settings

    3.7 Security Settings 3.7.1 Administrator Password 3.7.2 User Password Type the password with up to 20 characters and then press Enter key. This will clear all previously typed CMOS passwords. You will be requested to confirm the password. Type the password again and press Enter key. You may press Esc key to abandon password entry operation.

  • Page 37: Save And Exit Settings

    Once the password feature is used, you will be requested to type the password each time you enter BIOS setup. This will prevent unauthorized persons from changing your system configurations. Also, the feature is capable of requesting users to enter the password prior to system boot to control unauthorized access to your computer.
  • Page 38 Exit Without Saving Quit without saving? [Yes] [No] Save Changes and Reset Save & reset Save Configuration and reset? [Yes] [No] Discard Changes and Reset Reset Without Saving Reset without saving? [Yes] [No] Save Changes Save Setup Values Save configuration? [Yes] [No] Discard Changes...

  • Page 39: Chapter 4 Installation Of Drivers

    Chapter 4 Installation of Drivers This chapter describes the installation procedures for software and drivers under the windows 7. The software and drivers are included with the motherboard. The contents include Intel chipset driver, VGA driver, LAN drivers, Audio driver Installation instructions are given below. Important Note: After installing your Windows operating system (Windows 7), you must install first the Intel Chipset Software Installation Utility before proceeding with the...

  • Page 40: Intel Chipset Driver

    4.1 Intel Chipset Driver To install the Intel chipset driver, please follow the steps below. Step 1. Select Intel (R) Chipset NM10 Express from the list Step 2. Click Next to setup program. APC-3x93P_R (SBC-7106) User Manual...
  • Page 41 Step 3. Read the license agreement. Click Yes to accept all of the terms of the license agreement. Step 4. Click Next to continue. APC-3x93P_R (SBC-7106) User Manual...
  • Page 42 Step 5. Click Next. Step 6. Select Yes, I want to restart this computer now. Click Finish, then remove any installation media from the drives. APC-3x93P_R (SBC-7106) User Manual...

  • Page 43: Intel Graphics Media Accelerator Driver

    4.2 Intel Graphics Media Accelerator Driver To install the VGA drivers, follow the steps below to proceed with the installation. Step 1.Select Intel(R) VGA Chipset Driver. Step 2. Tick Automatically run WinSAT and enable the Windows Aero desktop theme(if supported). APC-3x93P_R (SBC-7106) User Manual...
  • Page 44 Step 3. Read license agreement. Click Yes. Step 4. Click Next. APC-3x93P_R (SBC-7106) User Manual...
  • Page 45 Step 5. Click Next. Step 6. Select Yes, I want to restart this computer now. APC-3x93P_R (SBC-7106) User Manual...

  • Page 46: Intel (R) Network Adapter

    4.3 Intel (R) Network Adapter To install the Intel (R) Network Adapter device driver, please follow the steps below. Step 1. Select LAN Driver. Step 2. Select 15” APC-3x93P_R (SBC-7106) User Manual...
  • Page 47 Step 3. Click Next to continue. Step 4. Click Install to begin the installation. APC-3x93P_R (SBC-7106) User Manual...

  • Page 48: Realtek Alc662 Hd Audio Driver Installation

    Step 5. Click Finish to exist the wizard. 4.4 Realtek ALC662 HD Audio Codec Driver Installation To install the Realtek ALC662 HD Audio Codec Driver, please follow the steps below. Step 1. Select Realtek AL662 Audio Codec Driver from the list APC-3x93P_R (SBC-7106) User Manual...
  • Page 49 Step 2. Click Next to continue. Step 3. Click Yes, I want to restart my computer now. Click Finish to complete the installation. APC-3x93P_R (SBC-7106) User Manual...

  • Page 50: Chapter 5 Touch Screen Installation

    Chapter 5 Touch Screen Installation This chapter describes how to install drivers and other software that will allow your touch screen work with different operating systems. 5.1 Windows 2000/2003/Vista/WIN7 Universal Driver Installation for PenMount 6000 Series Before installing the Windows 2000/WIN7 driver software, you must have the Windows 2000/WIN 7 system installed and running on your computer.
  • Page 51 Step 2. Select Resistive Touch. Step 3. Click Next to continue. APC-3x93P_R (SBC-7106) User Manual...
  • Page 52 Step 4. Read the license agreement. Click I Agree to agree the license agreement. Step 5. Choose the folder in which to install PenMount Windows Universal Driver. Click Install to start the installation. APC-3x93P_R (SBC-7106) User Manual...
  • Page 53 Step 6. Wait for installation. Then click Next to continue. Step 7. Click Continue Anyway. APC-3x93P_R (SBC-7106) User Manual...
  • Page 54 Step 8. Click Finish to complete installation. 5.1.2 Installing Software (Projected Capacitive) Step 1. Insert the product CD, the screen below would appear. Click touch panel driver. APC-3x93P_R (SBC-7106) User Manual...
  • Page 55 Step 2. Select Projected Capacitive. Step 3. Click Next to continue. APC-3x93P_R (SBC-7106) User Manual...
  • Page 56 Step 4. Select I accept the terms of the license agreement. Click Next. Step 5. Tick Install RS232 interface driver. Click Next. APC-3x93P_R (SBC-7106) User Manual...
  • Page 57 Step 6. Select None. Click Next. Step 7. Click OK. Step 8. Tick Support Muti-Monitor System. Click Next. APC-3x93P_R (SBC-7106) User Manual...
  • Page 58 Step 9. Go to C:\Program Files\eGalaxTouch. Click Next. Step 10. Click Next. APC-3x93P_R (SBC-7106) User Manual...
  • Page 59 Step 11. Tick Create a eGalaxTouch Utility shortcut on desktop. Click Next. Step 12. Wait for installation. APC-3x93P_R (SBC-7106) User Manual...

  • Page 60: Software Functions

    Step 13. Click Yes to do 4 point calibration. 5.2 Software Functions 5.2.1 Software Functions(Resistive Touch) Upon rebooting, the computer automatically finds the new 6000 controller board. The touch screen is connected but not calibrated. Follow the procedures below to carry out calibration. 1.
  • Page 61 Standard Calibration Click this button and arrows appear pointing to red squares. Use your finger or stylus to touch the red squares in sequence. After the fifth red point calibration is complete. To skip, press ‘ESC’. Advanced Calibration Advanced Calibration uses 4, 9, 16 or 25 points to effectively calibrate touch panel linearity of aged touch screens.
  • Page 62 Step 2.Click “Standard Calibration” to start calibration procedure NOTE: The older the touch screen, the more Advanced Mode calibration points you need for an accurate calibration. Use a stylus during Advanced Calibration for greater accuracy. Please follow the step as below: APC-3x93P_R (SBC-7106) User Manual...
  • Page 63 Step 3.Come back to “PenMount Control Panel” and select Tools then click Advanced Calibration. Step 4. Select Device to calibrate, then you can start to do Advanced Calibration. NOTE: Recommend to use a stylus during Advanced Calibration for greater accuracy. APC-3x93P_R (SBC-7106) User Manual...
  • Page 64 Plot Calibration Data Check this function and a touch panel linearity comparison graph appears when you have finished Advanced Calibration. The blue lines show linearity before calibration and black lines show linearity after calibration. Turn off EEPROM storage The function disable for calibration data to write in Controller.
  • Page 65 About This panel displays information about the PenMount controller and driver version. APC-3x93P_R (SBC-7106) User Manual...
  • Page 66 Multiple Monitors Multiple Monitors support from two to six touch screen displays for one system. The PenMount drivers for Windows 2000/WIN 7 support Multiple Monitors. This function supports from two to six touch screen displays for one system. Each monitor requires its own PenMount touch screen control board, either installed inside the display or in a central unit.
  • Page 67 2. When the mapping screen message appears, click OK. 3. Touch each screen as it displays “Please touch this monitor”. Following this sequence and touching each screen is called mapping the touch screens. Touching all screens completes the mapping and the desktop reappears on the monitors. Select a display and execute the “Calibration”...
  • Page 68 6. “Touch this screen to start its calibration” appears on one of the screens. Touch the screen. 7. “Touch the red square” messages appear. Touch the red squares in sequence. 8. Continue calibration for each monitor by clicking Standard Calibration and touching the red squares.
  • Page 69 Control Panel Open Control Panel Windows Beep Setting Beep function for each device Right Button When you select this function, a mouse icon appears in the right-bottom of the screen. Click this icon to switch between Right and Left Button functions.
  • Page 70 5.2.2 Software Functions(Projected Capacitive) General In this window, you can see there is USB Controller. Click OK to continue. Monitor Mapping to adjust touch panel to search for device APC-3x93P_R (SBC-7106) User Manual...
  • Page 71 Setting Beep Beep On Touch Beep On Release Beep From System Beep Beep From Sound Card Linearization Style 9 points 25 points Double Click Time Shorter Longer Double Click Area Smaller Bigger Normal mode Simulate the mouse mode APC-3x93P_R (SBC-7106) User Manual...
  • Page 72 Option Function Enable Constant Touch Enable Auto Right Click Enable Touch Enable Cursor Stabilization Constant Touch Area Auto Right Click Time APC-3x93P_R (SBC-7106) User Manual...
  • Page 73 Tools Click OK to continue the settings. 4 Points Calibration Do 4 points alignment to match display. Clear and Calibrate Clear linearization parameter and do 4 points alignment. Linearization Do 9 points linearization for better touchscreen linearity. Draw Test Do draw test to verify the touch accuracy. APC-3x93P_R (SBC-7106) User Manual...
  • Page 74 Display In this window, it shows the mode of display. Enable Multiple Monitors. Map to main display if system has only one display monitor Full Screen Lower Screen Left Screen Upper Screen Right Screen APC-3x93P_R (SBC-7106) User Manual...
  • Page 75 Other Other mode of display. Quarter1~4 and Customized area. Active Area Drag active area to enable Active Area Function. APC-3x93P_R (SBC-7106) User Manual...
  • Page 76 Hardware Saturn Hardware Configuration APC-3x93P_R (SBC-7106) User Manual...
  • Page 77 About To display information about eGalaxTouch and its version. APC-3x93P_R (SBC-7106) User Manual...
