Videocon SPRING-WM VSP70LPW-SFK Service Manual page 32

BILL OF MATERIAL
1 PC 1100005267 PIPE,FEEDING PORT SUPPORT,6800
0770
1 PC 1100042802 CAP,NOZZLE,RUBBER,CHINA,MULTIE 6800
0790
2 PC 1100005287 SCREW,SPECIAL,TAPPING,435
0811
ASM 1200032259 ASSY,BODY B,MARINE / DLX PLUS,VG GREY
1 PC 1200027867 BODY B,MARINE/MARINE DLX,VG GREY
1050
1 PC 1100019311 COVER,NOZZLE,MULTIE 6800 DLX
1060
2 PC 1100000922 SCREW,SPECIAL,TAPPING,XTB4+12C
0050
1 PC 1200030998 COVER,OUTER TUB,MULTIE 6800,LIGHT GREY
1070
2 PC 1100005281 SCREW,BIND,TAPPING,M4X14.5,6800
0040
1 PC 1200013715 LID,INNER,MULTIE 6800 DLX,NATURAL
1080
1 PC 1100019404 FLEXIBLE,WIRE,UNIT,MULTIE 6800 DLX
1130
1 PC 1100019319 SPRING,LID HINGE,MULTIE 6800 DLX
1140
1 PC 1100019324 SWITCH,SAFETY,MULTIE 6800 DLX
1250
1 PC 1100005257 LEVER A,ACTUATING,MULTIE 6800
1120
1 PC 1200031522 LID,SPIN,MULTIE 6800 DLX,LIGHT GREY
1090
1 PC 1200031523 INSERT,SPIN LID,MARINE,TRANS SMOKE GREY
1100
1 PC 1100005299 STICKER,CAUTION,MULTIE 6800
1110
ASM 1200035223 ASSY,PANEL A,SPRING7.0KG,L GREY,ECO WASH
1200035156 PANEL A,SPRING,7.0KG,W/P,LIGHT GREY
1 PC
1150
1200035152 DECO, PANEL A,SPRING,7.0KG,PRIN,LT GREY
1151
1 PC 1200035162 PLATE,TIMER,SPRING, 7.0KG
1160
5 PC 1100000922 SCREW,SPECIAL,TAPPING,XTB4+12C
0050
1 PC 1100019530 TIMER,WASH,40MIN,1SHAFT,MECHANICAL,DLX
1170
1 PC 1100005281 SCREW,BIND,TAPPING,M4X14.5,6800
0040
1 PC 1100019531 TIMER,SPIN,MULTIE 6000/6800 DLX
1180
2 PC 1100028631 SCREW,MS,SPECIAL,TAPPING,435
1300
1 PC 1100005214 BUZZER WITHOUT KNOB,WITHOUT CASTOR
1200
2 PC 1100006701 SCREW,BIND,TAPPING,XTB3+12C,SA63/6800
1220
1 PC 1200013714 LEVER A,DRAIN,MULTIE 6800 DLX
1240
1 PC 1100005295 SPRING,FLAT,50.5MM,6800
1190
0.86 M 1100009335 POLYESTER STRIP,6MMX2000M
1230
1100048782 HANGER A,FEED HOSE,MARINE/DLX,LIGHT GREY
1 PC
1310
2 PC 1100006700 SCREW,BIND,TAPPING,10BU
0160
1 PC 1100054704 FEEDING, PORT A, SPRING, 7.0KG
1320
1 PC 1100054705 LEVER,FEEDING PORT,SPRING LIGHT GREY
1330
1 PC 1100019317 O RING,FEED HOSE HANGER A,MULTIE 6800DLX
1340
1 PC 1100005300 STICKER,EXCESS FLOW,MULTIE 6800
1270
1100044148 UNIT,VALVE FRAME,MULTIE 6800,THREAD LID
0920
ASM 1100054706 UNIT,TIMER KNOB,SPRING,LIGHT GREY
4 PC 1100054707 TIMER KNOB BODY,SPRING,7.0KG,LIGHT GREY
1280
4 PC 1100054708 TIMER KNOB DECO, SPRING, CROME PLT
1290
1100005267 PIPE,FEEDING PORT SUPPORT,6800
1100042802 CAP,NOZZLE,RUBBER,CHINA,MULTIE 6800
1100005287 SCREW,SPECIAL,TAPPING,435
1200032396 ASSY,BODY B,MARINE/DLX PLUS,PINK FUS
1200032243 BODY B,MARINE/MARINE DLX,PINK
1100019311 COVER,NOZZLE,MULTIE 6800 DLX
1100000922 SCREW,SPECIAL,TAPPING,XTB4+12C
1200032232 COVER,OUTER TUB,MULTIE 6800,PARKER WHITE
1100005281 SCREW,BIND,TAPPING,M4X14.5,6800
1200013715 LID,INNER,MULTIE 6800 DLX,NATURAL
1100019404 FLEXIBLE,WIRE,UNIT,MULTIE 6800 DLX
1100019319 SPRING,LID HINGE,MULTIE 6800 DLX
1100019324 SWITCH,SAFETY,MULTIE 6800 DLX
1100005257 LEVER A,ACTUATING,MULTIE 6800
1200032239 LID,SPIN,MULTIE 6800 DLX, PARKER WHITE
1200032238 INSERT,SPIN LID,MARINE,TRANSPARENT
1100005299 STICKER,CAUTION,MULTIE 6800
1200035224 ASSY,PANEL A,SPRING 7.0KG, PARKER WT.ECO
1200035157 PANEL A,SPRING,7.0KG,W/P,PARKER WHITE
1200035153 DECO, PANEL A,SPRING,7.0KG,PRIN,PINK
1200035162 PLATE,TIMER,SPRING, 7.0KG
1100000922 SCREW,SPECIAL,TAPPING,XTB4+12C
1100019530 TIMER,WASH,40MIN,1SHAFT,MECHANICAL,DLX
1100005281 SCREW,BIND,TAPPING,M4X14.5,6800
1100019531 TIMER,SPIN,MULTIE 6000/6800 DLX
1100028631 SCREW,MS,SPECIAL,TAPPING,435
1100005214 BUZZER WITHOUT KNOB,WITHOUT CASTOR
1100006701 SCREW,BIND,TAPPING,XTB3+12C,SA63/6800
1200013714 LEVER A,DRAIN,MULTIE 6800 DLX
1100005295 SPRING,FLAT,50.5MM,6800
1100009335 POLYESTER STRIP,6MMX2000M
1100049377 HANGER A,FEED HOSE,MARINE, PARKER WHITE
1100006700 SCREW,BIND,TAPPING,10BU
1100054704 FEEDING, PORT A, SPRING, 7.0KG
1100054709 LEVER,FEEDING PORT,SPRING, PARKER WHITE
1100019317 O RING,FEED HOSE HANGER A,MULTIE 6800DLX
1100005300 STICKER,EXCESS FLOW,MULTIE 6800
1100044148 UNIT,VALVE FRAME,MULTIE 6800,THREAD LID
1100054710 UNIT,TIMER KNOB,DECO,SPRING,PARKER WHITE
1100054711 TIMER KNOB BODY,SPRING,7.0KG,PARKER WHITE
1100054708 TIMER KNOB DECO, SPRING, CROME PLT
