6. SERVICE INFORMATION
6-2. DISASSEMBLY INFORMATION
ITEM
HOW TO DISASSEMBLE AND ASSEMBLE
FILTER UNIT
1. Pull out the filter unit from over flow filter lock, use
ASSEMBLY
use fingers to press and pull out (Fig 1)
2. Turn lint filter inside out, and rinse the dirt from filter.
(Fig 2)
3. Set back to the original position, inset the bottom
first as shown press down and lock as the arrow (Fig 3)
Over Flow Filter with Filter Unit
19
DRAWINGS
(Fig 1)
(Fig 2)
(Fig 3)
