6. SERVICE INFORMATION

6-1. WIRING DIAGRAM

MARINE PLUS
MODEL SERIES
MARINE DLX
PLUS
WASH 7.0 kg
CAPACITY
SPIN 3.2 kg
Max. 60 Ltr.
WATER
LEVEL
Min. 29 Ltr.
SUPPLY
INPUT POWER
SIZE IN mm
NET WEIGHT
MAHARASHTRA, INDIA
KSA-682 P
SPRING
LS-682S
7.0 kg 6.8 kg
3.2 kg 3.2 kg
60 Ltr. 60 Ltr.
29 Ltr. 29 Ltr.
240V, 50Hz AC
WASH : 350 W, SPIN : 180 W
L780xW480xH960
23.0 kg
WIRING DIAGRAM
ORANGE
WASH
TIMER
BUZZER
WASH
MOTOR
240V/50Hz
BLACK
GREEN
12
ORANGE
SPIN
TIMER
CAPACITOR
LIGHT BLUE
RED
BLUE PINK
SAFETY SWITCH
SPIN
MOTOR
YELLOW-BLACK
GREEN
CONNECTOR POINT
