SAFETY PRECAUTION !
DISASSEMBLE POWER CORD BEFORE SERVICING
RECONNECT ALL GROUNDING DEVICES
IMPORTANT SAFETY NOTICE !
This service information is intended for individuals
possessing adequate background of electrical,
electronic and mechanical experience.
Any attempt to repair this appliance may result in
personal injury or property damage.
The manufacturer or seller cannot be responsible
for the interpretation of this information, nor can it
assume any liability in connection with its use.
CONTENTS
1. SPECIFICATION________________________________________2
2. PRECAUTION__________________________________________3
3. CAUTIONS FOR SAFETY_________________________________4
4. INSTALLATION INSTRUCTIONS___________________________7
5. OPERATING INSTRUCTIONS_____________________________9
5-1 IDENTIFICATION OF PARTS___________________________9
5-2 CONTROL PANEL INFORMATION_______________________10
5-3 CARE AND MAINTENANCE____________________________11
6. SERVICE INFORMATION________________________________12
6-1 WIRING DIAGRAM___________________________________12
6-2 DISASSEMBLY INFORMATION_________________________13
6-3 TROUBLESHOOTING_________________________________20
6-4 CHECK POINT AFTER REPAIR_________________________22
7. EXPLODED VIEW_______________________________________23
8. BILL OF MATERIAL______________________________________29
1
