BILL OF MATERIAL

MODEL: SPRING 7.0KG,LIGHT GREY
Exploded Model
View Code
QTY UNIT
SAP CODE
1 PC 1100045167 STICKER,PVC,GERM & RUST,FREE,SA COMMON
0510
0.3 G 1400000124 ACRABOND,998
0390
0.5 G 1400000334 GREASE,MOLYKOTE,G4500
0400
0.5 G 1400000131 GREASE,OKS LC PREMIUM
0430
2 G 1400000125 ACRABOND,999
0440
10 G 1400002189 ACRABOND,997,07 07,PURPLE COLOUR
0530
1 PC 1300000868 SHEET,CORRUGATED,BOTTOM,5PLY,MULTIE 6800
0020
1 PC 1300003965 BUFFER,THERMOCOL,BOTTOM,4PC,MULTIE 6800
0030
15 PC 1100005281 SCREW,BIND,TAPPING,M4X14.5,6800
0040
9 PC 1100000922 SCREW,SPECIAL,TAPPING,XTB4+12C
0050
3 PC 1100006700 SCREW,BIND,TAPPING,10BU
0160
1 PC 1200031516 PULSATOR,PUNCH,MARINE,LIGHT GREY
0130
1 PC 1100021128 CAM,PUNCH PULSATOR,MULTIE 6800 S DLX
0080
1 PC 1100045008 FOLLOWER,PUNCH PULSATOR, VG GREY,MARINE
0070
1100048679 CROWN,PUNCH,PULSATOR,MARINE,LIGHT GREY
1 PC
0060
3 PC 1100043833 ROTOR,WITH TAB,MULTIE 6800,VG GREY
0090
1 PC 1100029807 V BELT,L688MM,MULTIE 6000
0210
1 PC 1100006692 MAINS CORD,5A/250V,MULTIE 6800
0220
5 PC 1100000705 HOLDER,LEAD WIRE,1.4X170 MM,COMMON
0270
1 PC 1300003416 BUFFER,THERMOCOL,SPIN TUB,MULTIE6800DLX
0280
0.6 M 1100043686 TAPE INSULATION, PVC, BLACK, W19MM
0380
8 PC 1100000618 CONNECTOR A,COMMON
0230
1 G 1100005202 BAG,POLYETHYLENE,CONNECTOR,MULTIE 6800
0200
1 PC 1200027662 COVER,BACK,MULTIE 6800,VG GREY
0240
1 PC 1100054702 STICKER,WIRING DIAGRAM,SPRING,7.0KG
0250
1100054703 INSTRUCTION MANUAL,MARINE PLUS, SPRING
1 PC
0480
1 PC 1100021350 SHEET,INSTRUCTION,MULTIE 6800/SA63
0190
1 PC 1200031517 LID,WASH,MULTIE 6800 DLX,LIGHT GREY
0170
1200031518 INSERT,WASH LID,MARINE,TRANS SMOKE GREY
1 PC
0180
1 PC 1100005216 CAP A,SPIN,MULTIE 6800,NATURAL
0460
1 PC 1100000729 HOSE A,INLET,SA,COMMON,GREY
0470
1 PC 1100000981 STICKER,PAPER,TESTED OK,COMMON
0350
1300007242 SHEET,FOAM,PE,750X150X1MM
1 PC
0450
0.05 KG 1300000860 BAG,POLYETHYLENE,MACHINE,MULTIE 6800
0290
1 PC 1300008333 BUFFER,THERMOCOL,TOP,SPARKLE,7.0KG
0300
1 PC 1300008334 BUFFER,THERMOCOL,MIDDLE,SPARKEL,7.0KG
0310
1 PC 1300003968 WOODEN,STICK,25X14X755MM,MULTIE 6800
1350
1 PC 1300007627 BOX,PACKING,3PLY,PRINTED,MARINE/DLX PLUS
0320
1 M 1300000867 TAPE,BOPP,60MMX65M,TRANSPARENT
0330
6.2 M 1300002820 STRAP,PP,15 X 0.7MM
0340
1 PC 1100043048 STICKER,VINYL,SERVICE,VIDEOCON
1410
1 PC 1200031519 TUB,SPIN,MULTIE 6800,SA63,LIGHT GREY
0140
1 PC 1100019014 UNIT,COUPLING,SHAFT 108.4,METAL,6800
1360
1 PC 1100005270 PLATE,SPIN TUB,6800
1370
4 PC 1100005280 SCREW,ASSEMBLED,624
1380
1 PC 1100005226 COVER,SPIN TUB BOTTOM,6800
1390
1 PC 1100005283 SCREW,PAN HEAD,XSN4+6BNS,6800
1400
1 PC 1200031520 BALANCER,SINGLE,MULTIE 6800,LIGHT GREY
0150
(WM VSP70LPW-SFK)
DESCRIPTION
MODEL: SPRING 7.0KG,PINK FUSION
(WM VSP70PPW-SFK)
DESCRIPTION
SAP CODE
1100045167 STICKER,PVC,GERM & RUST,FREE,SA COMMON
1400000124 ACRABOND,998
1400000334 GREASE,MOLYKOTE,G4500
1400000131 GREASE,OKS LC PREMIUM
1400000125 ACRABOND,999
1400002189 ACRABOND,997,07 07,PURPLE COLOUR
1300000868 SHEET,CORRUGATED,BOTTOM,5PLY,MULTIE 6800
1300003965 BUFFER,THERMOCOL,BOTTOM,4PC,MULTIE 6800
1100005281 SCREW,BIND,TAPPING,M4X14.5,6800
1100000922 SCREW,SPECIAL,TAPPING,XTB4+12C
1100006700 SCREW,BIND,TAPPING,10BU
1200032233 PULSATOR,PUNCH,MARINE,PARKER WHITE
1100021128 CAM,PUNCH PULSATOR,MULTIE 6800 S DLX
1100049379 FOLLOWER,PUNCH PULSATOR, PINK,MARINE
1100049380 CROWN,PUNCH,PULSATOR,MARINE,PARKER WHITE
1100031520 ROTOR,WITH TAB,MULTIE 6800P,LIGHT PINK
1100029807 V BELT,L688MM,MULTIE 6000
1100006692 MAINS CORD,5A/250V,MULTIE 6800
1100000705 HOLDER,LEAD WIRE,1.4X170 MM,COMMON
1300003416 BUFFER,THERMOCOL,SPIN TUB,MULTIE6800DLX
1100043686 TAPE INSULATION, PVC, BLACK, W19MM
1100000618 CONNECTOR A,COMMON
1100005202 BAG,POLYETHYLENE,CONNECTOR,MULTIE 6800
1200027662 COVER,BACK,MULTIE 6800,VG GREY
1100054702 STICKER,WIRING DIAGRAM,SPRING,7.0KG
1100054703 INSTRUCTION MANUAL,MARINE PLUS, SPRING
1100021350 SHEET,INSTRUCTION,MULTIE 6800/SA63
1200032240 LID,WASH,MULTIE 6800 DLX, PARKER WHITE
1200032235 INSERT,WASH LID,MARINE,TRANSPARENT
1100005216 CAP A,SPIN,MULTIE 6800,NATURAL
1100000729 HOSE A,INLET,SA,COMMON,GREY
1100000981 STICKER,PAPER,TESTED OK,COMMON
1300007242 SHEET,FOAM,PE,750X150X1MM
1300000860 BAG,POLYETHYLENE,MACHINE,MULTIE 6800
1300008333 BUFFER,THERMOCOL,TOP,SPARKLE,7.0KG
1300008334 BUFFER,THERMOCOL,MIDDLE,SPARKEL,7.0KG
1300003968 WOODEN,STICK,25X14X755MM,MULTIE 6800
1300007627 BOX,PACKING,3PLY,PRINTED,MARINE/DLX PLUS
1300000867 TAPE,BOPP,60MMX65M,TRANSPARENT
1300002820 STRAP,PP,15 X 0.7MM
1100043048 STICKER,VINYL,SERVICE,VIDEOCON
1200031519 TUB,SPIN,MULTIE 6800,SA63,LIGHT GREY
1100019014 UNIT,COUPLING,SHAFT 108.4,METAL,6800
1100005270 PLATE,SPIN TUB,6800
1100005280 SCREW,ASSEMBLED,624
1100005226 COVER,SPIN TUB BOTTOM,6800
1100005283 SCREW,PAN HEAD,XSN4+6BNS,6800
1200031520 BALANCER,SINGLE,MULTIE 6800,LIGHT GREY
29
S BOM
Y
Y
Y
