6. SERVICE INFORMATION

6-2. DISASSEMBLY INFORMATION

ITEM
WASH TIMER
1) Disassembly of the WASH TIMER.
AND
Using screw driver unscrew the scre ws from the
1.
SPIN TIMER
Panel and Tub. (Fig 1)
Disassemble Knob assembled to the WASH TIMER &
2.
SPIN TIMER, WASH SELECT OR AND CYCLE SELECT OR.
(Fig. 2)
CAUTION :Please do not apply an excessive force.
Lift up Panel while Pulling to theFront. (Fig 3 )
3.
Remove the
4.
screws from Panel and
5.
Disassemble
LEVER- A DRAIN. (Fig4 )
6. Disassem ble the Wash Timer and Spin
the screw fitted to Body(F
UNPLUG POWER
HOW TO DISASSEMBLE AND ASSEMBLE
Timer plate asm from Panel by unscrewing the
Timer plate.
the COCK ROD -
ig 5)
WARNING
Unplug the power cord for the work
unnecessary to power on like disassembling.
Do not hold the plug by a wet hand.
Failing to unplug may cause an electric
shock.
A that is connected to the
Timer by removing
13
DIAGRAM
(Fig 1)
SCREW
PANEL
(Fig 2)
(Fig 3)
(Fig 4)
Cock Rod A fitment A fitment
(Fig 5)
SCREW
SCREW
