Videocon SPRING-WM VSP70LPW-SFK Service Manual page 31

BILL OF MATERIAL
4 PC 1100006700 SCREW,BIND,TAPPING,10BU
0160
ASM 1100040694 UNIT,SCREW 673,O RING,WASHER 651,6800
1 PC 1100005261 O RING,PULSATOR,SA 63,MULTIE 6800
0100
1 PC 1100005315 WASHER,SPECIAL,651
0110
1 PC 1100005289 SCREW,SPECIAL,673,6800
0120
1200032258 ASSY,BASE A,MARINE / DLX PLUS,VG GREY
ASM
1200031416 ASSY,TUB A,MARINE/DLX PLUS, LIGHT GREY
ASM
1200032259 ASSY,BODY B,MARINE / DLX PLUS,VG GREY
ASM
1200035223 ASSY,PANEL A,SPRING7.0KG,L GREY,ECO WASH
ASM
1200032258 ASSY,BASE A,MARINE / DLX PLUS,VG GREY
ASM
1 PC 1200027866 BASE A,MARINE/MARINE DLX,VG GREY
0540
2 PC 1100006687 HOLDER,LEAD WIRE,1.4X90 MM,COMMON
0260
2 PC 1100005221 CASTOR WHEEL,SA63,MULTIE 6800
0550
2 PC 1100005290 SHAFT,CASTOR,MULTIE 6800
0560
3 PC 1100001074 WASHER B,MOTOR,741
0570
1 PC 1200000379 MOTOR,125W
0580
3 PC 1100019019 UNIT,MOTOR WASHER A,613,SA63/43
0590
3 PC 1100005286 SCREW,SPECIAL,TAPPING,515,6800
0600
1100048296 UNIT,MOTOR PULLEY,FAN,SCREW,6800,G BOX
1 PC
0630
1 PC 1100000931 SCREW,STOP,XXE08C12,SA63
0640
1 PC 1100034613 BRAKE WHEEL,CI,60MM,MULTIE 6800,WTH BOLT
0650
1 PC 1100019012 UNIT,SPIN MOTOR PLATE,SA43
0660
1 PC 1100000957 SPRING,BRAKE,SA43,MULTIE 6800
0670
3 PC 1100005282 SCREW,PAN HEAD,XSN4+6S,6800
0680
1 PC 1200003202 MOTOR,45W
0690
3 PC 1100017314 UNIT,SUSPENSION,BUFFER,HOLDER A,B,SA63
0700
3 PC 1100006698 SCREW,SPECIAL,TAPPING,25A
0710
1 PC 1100005316 LEAD,WIRE,GREEN,600MM,EARTH,MULTIE 6800
0720
1 PC 1100005279 SCREW,5X12
0620
1 PC 1100005220 CAPACITOR,FILM,240V,9.5+4.0MFD,J
0730
2 PC 1100036791 UNIT,RUBBER LEG,WASHER 592,MULTIE 6800
0740
2 PC 1100028631 SCREW,MS,SPECIAL,TAPPING,435
1300
1 PC 1100001089 WASHER,SPECIAL,608,FA55/61/71
0610
ASM 1200031416 ASSY,TUB A,MARINE/DLX PLUS, LIGHT GREY
1 PC 1200031521 TUB A,MARINE/MARINE DLX,LIGHT GREY
0760
1 PC 1100028307 CAP,TUB,BOTTOM,MULTIE 6800,NATURAL
0800
1100048781 CAP,TUB,MARINE/MARINE DLX,LIGHT GREY
1 PC
0810
1 PC 1100005309 WASHER,BEARING CASE A,MULTIE 6800
0820
1 PC 1100005266 PACKING,MECHANISM CASE,RUBBER,MULTIE6800
0830
1 PC 1100005212 BUSHING,SHAFT,MULTIE 6800
0840
1100042752 GEAR BOX,ASSY,WITH PULLY,MULTIE 6800
1 PC
0850
6 PC 1100005285 SCREW,SPECIAL,TAPPING,514,6800
0860
1 PC 1100021349 UNIT,BUFFER OUTER,BUSH,6800/SA63
0900
1 PC 1100005240 HOLDER A,BUFFER,MULTIE 6800
0910
1 PC 1100005242 HOSE B,FLEXIBLE,DRAIN,MULTIE 6800
1030
1 PC 1100005264 PACKING,CHECK VALVE,RUBBER,6800
1040
1 PC 1100006695 PIPE,OVERFLOW,230MM,6800
1020
1 PC 1100019553 FOAM,PE,1100X20X2MM,MULTIE 6800DLX
0780
1 PC 1100005228 FILTER,UNIT,MULTIE 6800,APPLIANCES GREY
1010
1 PC 1100005229 FILTER,OVER FLOW,6800,DARK GREY
1000
1100006700 SCREW,BIND,TAPPING,10BU
1100040694 UNIT,SCREW 673,O RING,WASHER 651,6800
1100005261 O RING,PULSATOR,SA 63,MULTIE 6800
1100005315 WASHER,SPECIAL,651
1100005289 SCREW,SPECIAL,673,6800
1200032400 ASSY,BASE A,MARINE/DLX PLUS 7.0,PINK FUS
1200032399 ASSY,TUB A,MARINE PLUS, PARKER WHITE
1200032396 ASSY,BODY B,MARINE/DLX PLUS,PINK FUS
1200035224 ASSY,PANEL A,SPRING 7.0KG, PARKER WT.ECO
1200032400 ASSY,BASE A,MARINE/DLX PLUS 7.0,PINK FUS
1200032236 BASE A,MARINE/MARINE,PINK
1100006687 HOLDER,LEAD WIRE,1.4X90 MM,COMMON
1100005221 CASTOR WHEEL,SA63,MULTIE 6800
1100005290 SHAFT,CASTOR,MULTIE 6800
1100001074 WASHER B,MOTOR,741
1200000379 MOTOR,125W
1100019019 UNIT,MOTOR WASHER A,613,SA63/43
1100005286 SCREW,SPECIAL,TAPPING,515,6800
1100048296 UNIT,MOTOR PULLEY,FAN,SCREW,6800,G BOX
1100000931 SCREW,STOP,XXE08C12,SA63
1100034613 BRAKE WHEEL,CI,60MM,MULTIE 6800,WTH BOLT
1100019012 UNIT,SPIN MOTOR PLATE,SA43
1100000957 SPRING,BRAKE,SA43,MULTIE 6800
1100005282 SCREW,PAN HEAD,XSN4+6S,6800
1200003202 MOTOR,45W
1100017314 UNIT,SUSPENSION,BUFFER,HOLDER A,B,SA63
1100006698 SCREW,SPECIAL,TAPPING,25A
1100005316 LEAD,WIRE,GREEN,600MM,EARTH,MULTIE 6800
1100005279 SCREW,5X12
1100005220 CAPACITOR,FILM,240V,9.5+4.0MFD,J
1100036791 UNIT,RUBBER LEG,WASHER 592,MULTIE 6800
1100028631 SCREW,MS,SPECIAL,TAPPING,435
1100001089 WASHER,SPECIAL,608,FA55/61/71
1200032399 ASSY,TUB A,MARINE PLUS, PARKER WHITE
1200032234 TUB A,MARINE/MARINE DLX,PARKER WHITE
1100028307 CAP,TUB,BOTTOM,MULTIE 6800,NATURAL
1100049381 CAP,TUB,MARINE,PARKER WHITE
1100005309 WASHER,BEARING CASE A,MULTIE 6800
1100005266 PACKING,MECHANISM CASE,RUBBER,MULTIE6800
1100005212 BUSHING,SHAFT,MULTIE 6800
1100042752 GEAR BOX,ASSY,WITH PULLY,MULTIE 6800
1100005285 SCREW,SPECIAL,TAPPING,514,6800
1100021349 UNIT,BUFFER OUTER,BUSH,6800/SA63
1100005240 HOLDER A,BUFFER,MULTIE 6800
1100005242 HOSE B,FLEXIBLE,DRAIN,MULTIE 6800
1100005264 PACKING,CHECK VALVE,RUBBER,6800
1100006695 PIPE,OVERFLOW,230MM,6800
1100019553 FOAM,PE,1100X20X2MM,MULTIE 6800DLX
1100031519 FILTER,UNIT,MULTIE 6800P,CREAM WHITE
1100031518 FILTER,OVER FLOW,MULTIE 6800P,WHITE
