SERVICE MANUAL

MODEL:
SPRING-
WM VSP70LPW-SFK
WM VSP70PPW-SFK
WM VSP70EPW-SFK
WM VSP70APW-SFK

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPRING-WM VSP70LPW-SFK and is the answer not in the manual?

Questions and answers

Related Manuals for Videocon SPRING-WM VSP70LPW-SFK

Summary of Contents for Videocon SPRING-WM VSP70LPW-SFK

  • Page 1: Service Manual

    SERVICE MANUAL MODEL: SPRING- WM VSP70LPW-SFK WM VSP70PPW-SFK WM VSP70EPW-SFK WM VSP70APW-SFK...

  • Page 2: Table Of Contents

    SAFETY PRECAUTION ! DISASSEMBLE POWER CORD BEFORE SERVICING RECONNECT ALL GROUNDING DEVICES IMPORTANT SAFETY NOTICE ! This service information is intended for individuals possessing adequate background of electrical, electronic and mechanical experience. Any attempt to repair this appliance may result in personal injury or property damage.

  • Page 3: Specification

    1. SPECIFICATIONS Spring MODEL : Power Supply 240V, 50 Hz AC Washing Capacity 7.0 Kg Max. 60 Liters* Water Level Min. 29 Liters Rated Power Wash : 350 Watts Consumption Spin : 180 Watts Spinning Drum speed 1350 ~ 1400 rpm Weight of the Machine 23 kg Machine Dimensions...

  • Page 4: Precaution

    2. PRECAUTION When performing troubleshooting and part replacement during servicing, note the following safety precautions: 1-1.Safety Precautions 1-1-1.Use Genuine Parts The components of the washing machine have safety features such as non-combustibility and voltage withstanding.Therefore, always use the same part as suggested by the maker. In particular, be sure to use only design rated parts in case of major safety parts identified by the marker.

  • Page 5: Cautions For Safety

    3. CAUTIONS FOR SAFETY Please observe the following notes for safety. The symbols indicate as follows. Meaning Symbol Indicates possibility of death or serious injury of a repair technician and a WARNING person near by through them is conducted work, or of a user by a defect of the product after the work performed by the technician.
  • Page 6 3. CAUTIONS FOR SAFETY WARNING After repair, measure insulation resistance between the charging part (power cord plug) and the non-charging metallic part (ground) with an insulation resistance meter(500V).The resistance shall be10M Ohm or more. Failing to check the insulation resistance may cause a short circuit, electric CHECK INSULA- shock or other diseases to the customer.
  • Page 7 3.CAUTIONS FOR SAFETY CAUTION Ask an service enginer to install the product. Install the product securely and safely according to the electrical equipment technical standard and the wiring standard. INSTALL Incorrect work causes an electric shock and a fire. CAREFULLY Do not pull the power cordwhen unplugging.

  • Page 8: Installation Instructions

    4. INSTALLATION INSTRUCTION 4-1.Installation 15cm 4-1.Level Specifications and Wall-Clearance Distances 15cm 1) Instal the washing machine on a solid and level floor. 2) Place menton an inclined, weak or rough floor may cause abnormal noise or trembling. 3) Place the machine at least 15cm away from the wall. 4-2.
  • Page 9 4. INSTALLATION INSTRUCTION 4-5. Positioning the Drain Hose 1)When there is no threshold, the length of the drain hose should not exceed 3m. 2)When it is necessary to connect the drain hose with the drain outlet far away, connect the extension hose and applicable parts available from...

  • Page 10: Operating Instructions

    5. OPERATING INSTRUCTION 5-1. IDENTIFICATION OF PARTS Spinning Cap Inlet Hose 1. Control Panel of Machine 8. Spinner Lid 2. Water Inlet 9. Inner Lid 3. Water Supply Selector 10. Drain Hose Hanger 4. Wash Tub Lid 11. Spinner Tub 5.

  • Page 11: Control Panel Information

    5. OPERATING INSTRUCTION 5-2. CONTROL PANEL INFORMATION SPRING 1. Water Inlet : This is used to direct water supply to wash tub for washing or spin tub for spin shower. 2. Wash Timer : This timer is used for Auto SOAK, WASH and RINSE operations. Following combination can be selected.

  • Page 12: Care And Maintenance

    5. OPERATING INSTRUCTION 5-3. CARE AND MAINTENANCE BE SURE TO REMOVE THE POWER PLUG FROM MAIN POWER SUPPLY BEFORE CLEANING THE MACHINE. 1. Pull out the lint filter from the lock, use fingers to press and pull out at the part of the lint filter’s side 2.

  • Page 13: Service Information

    6. SERVICE INFORMATION 6-1. WIRING DIAGRAM MARINE PLUS KSA-682 P WIRING DIAGRAM ORANGE SPRING MODEL SERIES SPIN MARINE DLX LS-682S TIMER ORANGE PLUS WASH CAPACITOR TIMER WASH 7.0 kg 7.0 kg 6.8 kg CAPACITY SPIN 3.2 kg 3.2 kg 3.2 kg LIGHT BLUE Max.

  • Page 14: Disassembly Information

    6. SERVICE INFORMATION 6-2. DISASSEMBLY INFORMATION ITEM HOW TO DISASSEMBLE AND ASSEMBLE DIAGRAM (Fig 1) WASH TIMER 1) Disassembly of the WASH TIMER. SCREW Using screw driver unscrew the scre ws from the SPIN TIMER Panel and Tub. (Fig 1) Disassemble Knob assembled to the WASH TIMER &...
  • Page 15 6. SERVICE INFORMATION 6-2. DISASSEMBLY INFORMATION Item How to Disassemble and Assemble Drawings (Fig 1) BACK Untighten the screws from BACK COVER andTUB, and disassemble it by removing the Snap Locks. (Fig 1 ) COVER COVER-BACK SCREW Remove a plastic bag on Connector part, and (Fig 2) cut off all wire.(Fig2) PLASTIC BAG...
  • Page 16 6. SERVICE INFORMATION 6-2. DISASSEMBLY INFORMATION Item How to Disassemble and Assemble Drawings (Fig 1) BASKET- OUTER TUB COVER is fitted to BODY B with snap locks. To remove OUTER TUB COVER, hold it tightly from SPIN LID SPINNING center and PULL upwards. Snap locks will disengage from the BODY B.
  • Page 17 6. SERVICE INFORMATION 6-2. DISASSEMBLY INFORMATION 1. Remove the Cap from Pulsator assy, Using “-ve” PULSATOR Screw Driver (Fig.1) 2. Unscrew the Pulsator Assy, Using ‘+ve’ Screw Driver. (Fig. 1) PULSATOR V-BELT 3. Remove V BELT from Gear Box Motor Pulley (Fig. 2) GEAR BOX Keeping the SPIN LID at open position, FLEXIBLE WIRE...
  • Page 18 6. SERVICE INFORMATION 6-2. DISASSEMBLY INFORMATION ITEM HOW TO DISASSEMBLE AND ASSEMBLE DRAWINGS (Fig 5) 6. Lay down the machine of soft board placed on floor, to avoid scratch or damage on machine. (Fig. 5) SPIN MOTOR WASH MOTOR (Fig 6) Unscrew the screws from Base and Tub for all four sides.
  • Page 19 6. SERVICE INFORMATION 6-2. DISASSEMBLY INFORMATION ITEM HOW TO DISASSEMBLE AND ASSEMBLE DRAWINGS 11. Untighten Brake Asm Nut and Bolt. Pull the Brake Asm (Fig 9 ) upside and remove it from Spin Motor shaft. PULL Remove the Brake Frame.(Fig9) COUPLING SPIN MOTOR BOLT...
  • Page 20 6. SERVICE INFORMATION 6-2. DISASSEMBLY INFORMATION ITEM HOW TO DISASSEMBLE AND ASSEMBLE DRAWINGS (Fig 1) FILTER UNIT 1. Pull out the filter unit from over flow filter lock, use ASSEMBLY use fingers to press and pull out (Fig 1) Over Flow Filter with Filter Unit (Fig 2) 2.

  • Page 21: Troubleshooting

    6. SERVICE INFORMATION 6-3. TROUBLE SHOOTING TYPICAL FAILURE POSSIBLE CAUSE REPAIR Wash No agitation or Power plug is not connected properly Insert power plug correctly Rinse poor agitation Defective Motor Defective Timer Replace Defective Gear-Box Clothes or objects bit in pulsator gap Remove pulsator and check.
  • Page 22 6. SERVICE INFORMATION 6-3. TROUBLE SHOOTING TYPICAL FAILURE POSSIBLE CAUSE REPAI R Brake shoe is worn off or broken Replace brake shoe Spinning basket does not stop Brake arm does not move Replace brake frame Brake spring is broken away or elesticity is Replace brake Spring insufficient Excessive...

  • Page 23: Check Point After Repair

    6. SERVICE INFORMATION 6-4. CHECK POINT AFTER REPAIR After repairing, be sure to make the following trial operation to see if the washer operates normally. CheckPoint Inspection & Judgement 1) Insulation resistance Unplug the cord from the power outlet and turn on all the timers.Then measure the insulation resistance between the plug (both of 2pins) and grounding wire of themachine.

  • Page 24: Exploded View

    7. EXPLODED VIEW 7-1. PANEL ASSEMBLY 1240 1220 0040 1190 1170 1160 0260 1200 0050 1320 0160 1310 1340 1230 1300 1180 1330 0380 1270 PASTE ON BODY B 1280 1290 1151 1150...
  • Page 25 7. EXPLODED VIEW 7-2. BODY - B ASSEMBLY 1100 1140 1110 1090 1080 0050 1070 1120 0050 1250 1130 0050 1410 1060 1050...

  • Page 26: Tub Assembly

    7. EXPLODED VIEW 7-3. TUB ASSEMBLY 1400 0060 1390 0120 0110 1380 0100 1370 1030 0070 0150 0160 0160 0080 0090 0140 0130 0210 0830 1360 0840 1020 0860 0900 0910 1000 0780 0850 1010 0790 0820 0770 0750 0800 0810 0760 0520...
  • Page 27 7. EXPLODED VIEW 7-4. BASE ASSEMBLY 0650 0680 0660 0670 0640 0630 0620 0610 0600 0720 0690 0570 0620 0700 0580 0370 0730 0590 0540 0710 0550 0560 0740 1300...
  • Page 28 7. EXPLODED VIEW 7-5. MAIN LINE ASSY - 1...
  • Page 29 7. EXPLODED VIEW 7-6. MAIN LINE ASSY - 2...

  • Page 30: Bill Of Material

    1300007627 BOX,PACKING,3PLY,PRINTED,MARINE/DLX PLUS 1300007627 BOX,PACKING,3PLY,PRINTED,MARINE/DLX PLUS 0320 1300000867 TAPE,BOPP,60MMX65M,TRANSPARENT 1300000867 TAPE,BOPP,60MMX65M,TRANSPARENT 0330 1300002820 STRAP,PP,15 X 0.7MM 1300002820 STRAP,PP,15 X 0.7MM 0340 1100043048 STICKER,VINYL,SERVICE,VIDEOCON 1100043048 STICKER,VINYL,SERVICE,VIDEOCON 1410 1200031519 TUB,SPIN,MULTIE 6800,SA63,LIGHT GREY 1200031519 TUB,SPIN,MULTIE 6800,SA63,LIGHT GREY 0140 1100019014 UNIT,COUPLING,SHAFT 108.4,METAL,6800 1100019014 UNIT,COUPLING,SHAFT 108.4,METAL,6800 1360...
  • Page 31 BILL OF MATERIAL 1100006700 SCREW,BIND,TAPPING,10BU 1100006700 SCREW,BIND,TAPPING,10BU 0160 1100040694 UNIT,SCREW 673,O RING,WASHER 651,6800 1100040694 UNIT,SCREW 673,O RING,WASHER 651,6800 1100005261 O RING,PULSATOR,SA 63,MULTIE 6800 1100005261 O RING,PULSATOR,SA 63,MULTIE 6800 0100 1100005315 WASHER,SPECIAL,651 1100005315 WASHER,SPECIAL,651 0110 1100005289 SCREW,SPECIAL,673,6800 1100005289 SCREW,SPECIAL,673,6800 0120 1200032258 ASSY,BASE A,MARINE / DLX PLUS,VG GREY 1200032400 ASSY,BASE A,MARINE/DLX PLUS 7.0,PINK FUS 1200031416 ASSY,TUB A,MARINE/DLX PLUS, LIGHT GREY 1200032399 ASSY,TUB A,MARINE PLUS, PARKER WHITE...
  • Page 32 BILL OF MATERIAL 1100005267 PIPE,FEEDING PORT SUPPORT,6800 1100005267 PIPE,FEEDING PORT SUPPORT,6800 0770 1100042802 CAP,NOZZLE,RUBBER,CHINA,MULTIE 6800 1100042802 CAP,NOZZLE,RUBBER,CHINA,MULTIE 6800 0790 1100005287 SCREW,SPECIAL,TAPPING,435 1100005287 SCREW,SPECIAL,TAPPING,435 0811 1200032259 ASSY,BODY B,MARINE / DLX PLUS,VG GREY 1200032396 ASSY,BODY B,MARINE/DLX PLUS,PINK FUS 1200027867 BODY B,MARINE/MARINE DLX,VG GREY 1200032243 BODY B,MARINE/MARINE DLX,PINK 1050 1100019311 COVER,NOZZLE,MULTIE 6800 DLX...
