Installation Instructions
The ZDV3624NB, ZDV3624LPB, ZDV3628N, ZDV3628LP, ZDV3632N, ZDV3632LP
This appliance may be installed in an aftermarket permanently located, manufactured home (USA only)
or mobile home, where not prohibited by local codes.
This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not
convertible for use with other gases, unless a certified kit is used.
are Certified to: ANSI Z21.50a-2000, CSA 2.22a-2000, CGA 2.17-M91, CSA P.4.1-02
Stock #'s: ZDV3624NB, ZDV3624LPB, ZDV3628N, ZDV3628LP, ZDV3632N and ZDV3632LP
are Certified to: ANSI Z21.88b-2003, CSA-2.33b-2003, CGA 2.17-M91, CSA P.4.1-02
Direct Vent Gas Fireplace
These instructions must be kept with the unit for future reference.
WARNING: If the information in these instructions are not followed exactly, a fire
or explosion may result causing property damage, personal injury or loss of life.
Warning: Improper installation, adjustment, alteration, service or maintenance
can cause property damage, personal injury or loss of life. Refer to this manual.
Installation and service must be performed by a qualified installer, service
agency or the gas supplier.
Do not store or use gasoline or other flammable vapors and liquids in the
If you can not reach your gas supplier, call the fire department.
Listed Certified for USA. and Canada
Model Numbers ZDV3624, ZDV3624B, ZDV3628, ZDV3632
Stock #'s: ZDV3624N, ZDV3624LP
"Zero Clearance"
Read this complete manual before beginning installation.
FOR YOUR SAFETY
vicinity of this or any other appliance.
What To Do If You Smell Gas
Do not try to light any appliance.
Extinguish any open flame.
Do not touch any electrical switch.
Do not use any phone in your building.
Immediately call your gas supplier from a neighbour's phone.
Printed in Canada 22/12/04 Part # 3600-MAN
KINGSMAN INDUSTRIES
A Division of R-Co. Inc.
2340 Logan Avenue
Winnipeg, Manitoba, Canada R2R 2V3
Ph: (204) 632-1962
