These instructions must be kept with the unit for future reference.
WARNING: If the information in these instructions is not followed exactly, a fire or explosion may
result causing property damage, personal injury or loss of life.
Warning: Improper installation, adjustment, alteration, service or maintenance can cause property
damage, personal injury or loss of life. Refer to this manual. Installation and service must be performed by
a qualified installer, service agency or the gas supplier.
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
A Division of R-Co. Inc.
2340 Logan Avenue
Winnipeg, Manitoba, Canada R2R 2V3
Ph: (204) 632-1962
Printed in Canada
February 21, 2013
Installation Instructions
Installation Instructions
Model Numbers: ZV3600N, ZV3600NE, ZV3600LP, ZV3600LPE,
Model Numbers: ZV3600N, ZV3600NE, ZV3600LP, ZV3600LPE,
ZV4200N, ZV4200NE, ZV4200LP, ZV4200LPE are
ZV4200N, ZV4200NE, ZV4200LP, ZV4200LPE are
Certified to: ANSI Z21.50b-2009, CSA 2.22b-2009, CGA 2.17-M91
Certified to: ANSI Z21.50b-2009, CSA 2.22b-2009, CGA 2.17-M91
ZERO CLEARANCE VENTED GAS FIREPLACE
ZERO CLEARANCE VENTED GAS FIREPLACE
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Read this complete manual before beginning installation.
FOR YOUR SAFETY
What To Do If You Smell Gas
Do not try to light any appliance.
Extinguish any open flame.
Do not touch any electrical switch.
Do not use any phone in your building.
Immediately call your gas supplier from a neighbour's phone.
If you can not reach your gas supplier, call the fire department.
Part # 36ZV-MAN
