Kingsman ZDV6000 Installation Instructions Manual

Zero clearance direct vent gas fireplace
Hide thumbs Also See for ZDV6000:
Table of Contents

Advertisement

Quick Links

Installation Instructions

Zero Clearance Direct Vent Gas Fireplace
This appliance may be installed in an aftermarket permanently located, manufactured home (USA only) or mobile
home, where not prohibited by local codes.
This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not convertible for
use with other gases, unless a certified kit is used.
Read this complete manual before beginning installation.
These instructions must be kept with the unit for future reference.
WARNING: If the information in these instructions is not followed exactly, a fire or explosion may
result causing property damage, personal injury or loss of life.
Warning: Improper installation, adjustment, alteration, service or maintenance can cause property
damage, personal injury or loss of life. Refer to this manual. Installation and service must be performed by
a qualified installer, service agency or the gas supplier.
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
For Propane Horizontal installations the venting must be a minimum of one foot vertical off the flue before
going horizontal.
A Division of R-Co. Inc.
2340 Logan Avenue
Winnipeg, Manitoba, Canada R2R 2V3
Ph: (204) 632-1962
Model Number ZDV6000, ZDV3320
MQRB3328
Stock #'s ZDV3320N, ZDV3320LP, ZDV3320NE, ZDV3320LPE, are
Certified to: ANSI Z21.50b-2009, CSA 2.22b-2009, CGA 2.17-M91
Stock #'s ZDV6000N, ZDV6000LP, MQRQB3328N, MQRB3328LP
ZDV6000NE, ZDV6000LPE, MQRQB3328NE, MQRB3328LPE are
Certified to: ANSI Z21.88-2009, CSA 2.33-2009, CGA 2.17-M91
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
FOR YOUR SAFETY
What To Do If You Smell Gas
Do not try to light any appliance.
Extinguish any open flame.
Do not touch any electrical switch.
Do not use any phone in your building.
Immediately call your gas supplier from a neighbour's phone.
If you can not reach your gas supplier, call the fire department.
Printed in Canada
May 8, 2012
Part # 33DV-MAN-II

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZDV6000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kingsman ZDV6000

Summary of Contents for Kingsman ZDV6000

  • Page 1: Installation Instructions

    Installation Instructions Model Number ZDV6000, ZDV3320 MQRB3328 Zero Clearance Direct Vent Gas Fireplace Stock #’s ZDV3320N, ZDV3320LP, ZDV3320NE, ZDV3320LPE, are Certified to: ANSI Z21.50b-2009, CSA 2.22b-2009, CGA 2.17-M91 Stock #’s ZDV6000N, ZDV6000LP, MQRQB3328N, MQRB3328LP ZDV6000NE, ZDV6000LPE, MQRQB3328NE, MQRB3328LPE are Certified to: ANSI Z21.88-2009, CSA 2.33-2009, CGA 2.17-M91 INSTALLER: Leave this manual with the appliance.
