Mambo Hardware Description

3 TECHNICAL DATA

3.1 General specifications of MAMBO device

Power supply:
Internal battery:
Casing:
Bluetooth:
Detector:
Temperature range:
Physical characteristics:
Audio:

3.1.1 Power consumption

Supply voltage
Average supply current
GSM
GPRS
This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission.
Supply voltage 5 VDC, required to charge the internal
battery
Consists of a rechargeable Lithium-Ion battery with a
capacity of 850 mA/h built-in inside the unit.
Default operating time is approx. 4-5 hours powered
by 850 mA/h after full charged. See also chapter
Fully shield
Supports Bluetooth connectivity, Class 1.1 and 2.0
Bluetooth™ range:
3-D motion detector available
Normal operation: -0 °C to +55 °C.
Size: 86 mm x 60 mm x 28 mm
Weight: approx. 90 g
Audio interface including: internally 1 x Microphone, 1
x Speaker and externally an audio interface for
headset connection.
POWER CONSUMPTION (@ T
Typ Unit Description
4.1 V Powered by the internal battery (3.7 V / 850 mA/h)
9 mA SLEEP modes (Ign, Timer, Motion)
15 mA SLEEP mode (Ring), GSM engine on
150 GSM IDLE mode (all modules are powered on)
370 mA GSM TALK mode (all modules are powered on), Internal audio in use
260 GSM TALK mode (all modules are powered on), Headset in use
230 mA DATA mode GPRS (all modules are powered on)
10 m
= 25 °C)
AMB
Version 1.01
3.1.1.
Page 11
