Mambo Hardware Description
FALCOM MAMBO is equipment that can be used in a variety of applications such as:
♦ Personal safety and security
♦ Fleet tracking and management
♦ Remote tracking (Locating people)
♦ Real-time Navigation and Positioning
♦ Finding streets and routes
♦ Travel planning and many others ...

0.2 Circuit concept

The MAMBO architecture includes the following major functional components:
ARCHITECTURE INTEGRATES:
high-performance Tri Band GSM/GPRS core (operating at 26MHz)
20 parallel channel low-power GPS core (operating at L1 1575.42
MHz and C/A code 1,023 MHz chip rate)
ARM7TDMI Processor (at speed 25MHz) that controls all functions of
the system
Bluetooth
3D detector system (MSENS module)
Power Control for Li-Ion Batteries
high capacity (3.7V/ 850 mA/h) Li-Ion battery
FLASH-Memory (2MB - 512KB).
Internal SIM card reader
Internal GSM/GPRS antenna
Internal GPS antenna
Internal Bluetooth antenna
Internal Speaker and Microphone
PHYSICAL INTERFACES:
Audio interface (for headset)

0.3 Related documents

[1] MAMBO_software_2.3.17_user_manual.pdf
[2] MAMBO_getting_started.pdf
[3] MAMBO_software_update.pdf
[4] MAMBO_configuration_software.pdf
