Mambo Hardware Description
Duplex spacing
Carrier spacing
Multiplex, Duplex
Time slots per TDMA frame
Frame duration
Time slot duration
Modulation
Receiver input sensitivity @ ARP
BER Class II < 2.4 %
Table 4:

3.4 Technical specifications of GPS receiver

GPS features:
Accuracy:
DGPS Accuracy:
Datum:
Sensitivity*:
*
The sensitivity value is specified at the correlator. On a JP13 Evaluation Receiver using GSW3
firmware with the supplied antenna, 17 dBHz is equivalent to -155 dBm
This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission.
GSM 1800
GSM 1900
E-GSM 900
GSM 850
GSM 1800
GSM 1900
E-GSM 900
GSM 850
GSM 1800
GSM 1900
Air Interface
OEM single board 20 channel GPS receiver, L1 1575.42
MHz, C/A code 1,023 MHz chip rate.
GPS receiver with SiRFstarIII chip set
Processor type ARM7/TDMI
Position 10 meters CEP without SA.
Velocity 0.1 meters/second, without SA
Time 1 microsecond synchronized to GPS time
Position 1 to 5 meters, typical.
Velocity 0.05 meters/second, typical
WGS-84.
Tracking 13 dBHz.
Hot Start 15 dBHz
Cold Start 30 dBHz
374
299
45
45
95
80
200
TDMA/FTDMA, FDD
8
4.615
577
GMSK
-102 -107
-102 -107
-102 -106
-102 -105.5
.
Version 1.01
dBm
MHz
MHz
MHz
MHz
kHz
ms
µs
dBm
dBm
dBm
dBm
Page 15
