Technical data
Dimensions
Weight
Table 2: General specifications
GPS
GSM
Table 3: Power supply
Operation
Transportation
Storage
Table 4: Temperature limits
Interface A
Interface B
Interface C
Interface D
Table 5: Interface specifications
A2D–JP
General specifications
95 mm x 50 mm x 15 mm (B x W x H)
60 g
Power supply
VC3 3.3 V DC ±5 %
Max. 190 mA Operate
VBAT 3 V DC ±0,25 V
Max. 40 µA for „Keep Alive"
Preamp. Power 3,3 V DC – 6 V DC ±5 %
Max. 50 mA
VC5 5,0 V DC ± 5 %
Average current (in mA at 5V nominal):
0,015
in OFF mode 2 (EN pulled to LOW, the internal regulator is switched
off)
17*
in OFF mode 1 (AT+CPOF was issued and SOFT_ON was set to
LOW, the internal regulator is still working)
30*
in idle mode (base station sends at -85 dBm)
260*
in transmit mode at power level 7
350*
in transmit mode at power level 5 (Maximum)
* Serial interface is applied and working.
Temperature limits
-20 °C to +55 °C
-40 °C to +70 °C
-25 °C to +70 °C
Interface specifications
60pin connector AMP 177984-2
GPS 50 Ω MCX female, for active 3 V GPS antenna
GSM 50 Ω, SMB male
SIM card reader for small SIM cards (3V)
Version 1.03
Technical data
Side 11
