4 MAMBO INTERFACES

4.1.1 Buttons & LEDs
The MAMBO device operates with the push of buttons. The MAMBO device can be
turned on by pressing the B1 for longer than 5 seconds. After 4-5 seconds a beep
tone is generated and the
the unit is powered on.
user requirements.
depending on what configuration is most important for you. Depending on your
specific requirements all 3 integrated LED indicators can also be programmed.
References to customize the configuration of your MAMBO device are available in
the MAMBO software manual
Figure 1:
Items Buttons overview
1 BUTTON 0
2 BUTTON 1
3 BUTTON 2
Table 5:
Items LEDs overview
1 LED 0
2 LED 1
3 LED 2
Table 6:

4.1.2 Power jack

In order to recharge the internal battery the Ø 3,5 mm power jack allows you to
connect either a car adapter cable or a power charger to a DC electrical outlet.
Figure 2:
This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission.
status indicators
All other buttons are not configured, they are kept free for
Thus you have the possibility to configure all 3 available Buttons
"MAMBO_firmware_2.3.17_user_manual.pdf".
MAMBO with allocated Buttons and LEDs names
LEDs lighting colours
LEDs lighting colours
Power Jack interface to connect the charger
L1 and L3 light for a short time, notifying
Buttons marked
B1
B2
B3
LEDs marked Colours of light
L1 Red, Green or Blue
L2 Red, Green or Blue
L3 Red, Green or Blue
