- Page 1 PU-515PL-KIT HDBaseT™ LITE Extender Kit with PoE & 2-way IR (up to 60m) OPERATION MANUAL...
- Page 3 DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. CYP (UK) Ltd assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. CYP (UK) Ltd assumes no responsibility for any inaccuracies that may be contained in this document.
-
Page 4: Safety Precautions
SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons. -
Page 5: Table Of Contents
CONTENTS 1. Introduction ...........6 2. Applications ...........6 3. Package Contents ........6 4. System Requirements ......6 5. Features ..........7 6. Operation Controls and Functions ..8 6.1 Transmitter Front and Rear Panels ..8 6.2 Receiver Front and Rear Panels .... 9 6.3 D-Sub 9-Pin Definitions ......10 6.4 IR Cable Pin Assignment .......10 7. -
Page 6: Introduction
1. INTRODUCTION The PU-515PL-KIT allows uncompressed HDMI signals to be transmitted over a Single CAT5e/6/7 cable. This solution has the added features of RS- 232 and 2-way IR control, and Power over Ethernet (PoE) functionality over the same CAT5e/6/7 cable. These combined HDMI and control signals can be transmitted up to lengths of 60 metres. -
Page 7: Features
5. FEATURES HDMI 1.4 with 3D, 4K×2K support, HDCP and DVI compliant Supports HDMI 1.4 (including HDCP) over a single CAT5e/6/7 up to 60m Complies with HDBaseT™- Lite specifications Full HD resolution support (1080p@60Hz/36-bit), 3D over 60m, 4Kx2K over 40m and PC resolution support (VGA to WUXGA) over CAT5e/6 cable HDMI input up to 15m with 8-bit deep colour, or 10m with 12-bit deep colour Supports HDMI output up to 15m with 8/12-bit deep colour Supports two-way IR, RS-232 Control, and Power Over Ethernet (PoE) -
Page 8: Operation Controls And Functions
6. OPERATION CONTROLS AND FUNCTIONS 6.1 Transmitter Front and Rear Panels IR2 Extender HDMI In Power Link RS-232 In IR1 Blaster CAT 5e /6/7 Out Transmitter RS232 In: Connect to a PC/laptop or RS-232 control device (with supplied 3.5 mm mini-jack to D-sub 9-pin adaptor) for the transmission of RS-232 commands. -
Page 9: Receiver Front And Rear Panels
6.2 Receiver Front and Rear Panels IR1 Extender HDMI Out Power Link RS-232 Out IR2 Blaster CAT 5e /6/7 In Receiver RS232 Out: Connect to the device that is to be controlled (with the supplied 3.5mm mini-jack to D-sub 9-pin adaptor) by RS-232 commands IR1 Extender: Connect an IR extender cable for IR signal reception. -
Page 10: D-Sub 9-Pin Definitions
6.3 D-Sub 9-Pin Definitions DEFINE TX/RX TxD/RxD RxD/TxD 6.4 IR Cable Pin Assignment IR Blaster Power 5 V IR Blaster Signal IR Extender IR Signal Power 5 V Ground... -
Page 11: Connection Diagram
7. CONNECTION DIAGRAM Example 1: Direct Connection DVD or Blu-ray Player RS-232 RS-232 HDMI Equipped PC or Adaptor 1.5m Input Notebook 60° IR Blaster 60° Power Supply IR Extender IR2 Extender HDMI In RS-232 In IR1 Blaster Transmitter Power Link CAT 5e /6/7 Out Single CAT5e/6/7... - Page 12 Example 2: Using a Repeater to Extend the Operating Distance RS-232 Equipped PC or Control Blu-ray Player System 1.5m HDMI Input 60° 60° RS-232 IR Blaster Adaptor IR Extender IR2 Extender HDMI In Power RS-232 In IR1 Blaster Transmitter Supply Power Link CAT 5e /6/7 Out...
-
Page 13: Specifications
8. SPECIFICATIONS Video Bandwidth 300 MHz/10.2 Gbps Transmitter Input Ports 1×HDMI, 1×IR Extender, 1×RS-232 Output Ports 1×CAT5e/6/7, 1×IR Blaster Receiver Input Ports 1×CAT5e/6/7, 1×IR Extender Output Ports 1×HDMI, 1×IR Blaster, 1×RS-232 CAT5e/6/7 Cable Up to 60 meters Distance HDMI Input Cable 15 meters/8-bit, 10 meters/12-bit Distance HDMI Output Cable... -
Page 14: Acronyms
CAT5e/6/7 Cable Specification: LENGTH BAND- DATA SUPPORTED VIDEO WIDTH RATE HD VIDEO UP TO UP TO UP TO 60 M 225 MHZ 5.3 GBPS UP TO 1080P@60 HZ/36-BIT, 3D (DATA RATE LOWER THAN 5.3 GBPS OR BANDWIDTH BELOW 225 MHZ). ULTRA HD VIDEO UP TO GREATER... - Page 16 CYP (UK) Ltd., Unit 7, Shepperton Business Park, Govett Avenue, Shepperton, Middlesex, TW17 8BA Tel: +44 (0) 20 3137 9180 | Fax: +44 (0) 20 3137 6279 Email: sales@cypeurope.com www.cypeurope.com v1.01...
