- Page 1 NOVA-7830 SOCKET-370 CPU Embedded Board With 10/100 Mbps Ethernet, VGA, Audio User Manual Version 1.1 September 23, 2003 ©Copyright 2003 by ICP Electronics Inc. All Rights Reserved.
- Page 2 Trademarks NOVA-7830 is a registered trademark of ICP Electronics Inc., IBM PC is a registered trademark of International Business Machines Corporation. Intel is a registered trademark of Intel Corporation. Award is a registered trademark of Award Software International, Inc.
-
Page 3: Table Of Contents
Table of Contents Introduction ..............4 Specifications ..................4 Package Contents ................5 Installation..............6 NOVA-7830 Layout................6 Clear CMOS Setup................7 Compact Flash Setting................. 7 Audio Amplifier Select ................. 7 LCD Panel Shift Clock/Panel VCC Select ..........8 COM Port RI and Voltage Selection ............8 COM4 RS232/RS422 (485) Selection ............. -
Page 4: Introduction
NS16C550. The parallel port and FDD interface are compatible with IBM PC/AT architecture's. NOVA-7830 has one Fast Ethernet Multifunction PCI Controller as a LAN controller, which is fully integrated 10BASE-T/100BASE-TX LAN solution with high performance networking functions and low power consumption features. -
Page 5: Package Contents
256 SDRAM. • Operating Temperature: 0¢ J ~ 60¢ J (CPU needs cooler). Package Contents NOVA-7830 package includes the following items: • NOVA-7830 Mobile CPU based Single board computer. • FDD cable x 1 • HDD cable x 1 •... -
Page 6: Installation
Chapter 2 Installation This chapter describes how to install NOVA-7830. Read the unpacking information carefully. The jumpers and switches setting for NOVA-7830 configuration, such as CPU type selection, system clock setting, and watchdog timer, are also included. NOVA-7830 Layout... -
Page 7: Clear Cmos Setup
Clear CMOS Setup CMOS RAM holds the board’s configuration data, which has to be set by means of system BIOS. To clear CMOS RAM, close JP1 for about 3 seconds, and then open it again. It will then resume normal operation. •... -
Page 8: Lcd Panel Shift Clock/Panel Vcc Select
LCD Panel Shift Clock/Panel VCC Select This jumper is for the setting of LCD panel shift clock mode and panel power voltage. • JP7: LCD Panel Shift Clock Description Inverted Normal • JP7: Panel VCC Description +5 V +3.3 V COM Port RI and Voltage Selection JP8 is setting COM3, 4 RI and Voltage. -
Page 9: Com4 Rs232/Rs422 (485) Selection
COM4 RS232/RS422 (485) Selection • JP9: Selection COM4 is RS232/RS422 (485) Description RS232 RS422/485 • JP10: Selection COM4 is RS422/RS485 Description JP10 RS422 RS485... -
Page 10: Connection
Chapter 3 Connection This chapter describes how to connect peripherals, switches and indicators to the NOVA-7830 board. The following table lists the connectors on NOVA-7830. Label Description CDIN1 CD-IN Connector Parallel Port Connector IDE Connector SUS LED CN8, 11 Serial Port 1, 2... -
Page 11: Floppy Disk Drive Connector
GROUND TRACK 0# GROUND WRITE PROTECT# READ DATA# GROUND SIDE 1 SELECT# DISK CHANGE# Video IN Connector NOVA-7830 is equipped witch 4 channels of composite video connector (BT878A). • CN33: Capture IN Description Description AVIN0 GROUND AVIN1 GROUND AVIN2 GROUND... -
Page 12: Ultra Ata33/66/100 Ide Disk Drive Connector
Ultra ATA33/66/100 IDE Disk Drive Connector You can attach one IDE (Integrated Device Electronics) hard disk drives to the NOVA-7830 IDE controller. • CN2: Primary IDE Connector Description Description RESET# GROUND DATA 7 DATA 8 DATA 6 DATA 9 DATA 5... -
Page 13: Parallel Port
Parallel Port This port is usually connected to a printer. NOVA-7830 includes an on-board parallel port, and accessed through a 26-pin flat-cable connector CN1. Three modes— SPP, EPP and ECP, are supported. • CN1: Parallel Port Connector Description Description STROBE#... -
Page 14: Serial Ports
Serial Ports NOVA-7830 offers four high speed NS16C550 compatible UARTs with Read/Receive 16 byte FIFO in each serial port. • CN8: D_SUB 9-PIN Connector Description DATA CARRIER DETECT (DCD) RECEIVE DATA (RXD) TRANSMIT DATA (TXD) DATA TERMINAL READY (DTR) GROUND... -
Page 15: Power Connector
CLEAR TO SEND (CTS) RING INDICATOR (RI) TX+ (RS422/485) TX- (RS422/485) RX+ (RS422/485) RX- (RS422/485) Power Connector The NOVA-7830 has one power connector for power supply. • CN30: Power Supply Connector Description VCC12V GROUND GROUND VCC5V • CN26: ATX Power Connector... -
Page 16: Irda Infrared Interface Port
1.11 IrDA Infrared Interface Port NOVA-7830 has a built-in IrDA port which supports Serial Infrared (SIR) or Amplitude Shift Keyed IR (ASKIR) interface. When IrDA port is used, you have to set SIR or ASKIR model in COM 2 of Peripheral Setup in BIOS. Normal RS-232 COM 2 will then be disabled. -
Page 17: Audio Connectors
1.13 Audio Connectors NOVA-7830 has a built-in AUDIO chipset (CMEDIA CMI8738LX); and a connector directly connected to the pin-header (CN32). The Audio chipset can support 5.1 channel sounds that include LINEOUT, REAR, and CENTER/BASS. • CN32: Audio Connector (2x8_2.00mm) Description... -
Page 18: Lan Rj45 Connector
• CN37: Intel 82562ET LAN RJ45 Connector Description Description 1.16 Compact Flash Connector—TYPE II NOVA-7830 supports one Compact Flash socket provided from IDE2. You must set the jumper to avoid the conflict (like master or slave). • CN43: Compact Flash Socket Description... -
Page 19: External Switches And Indicators
RESET SW GND HDD LED+ HDD LED - 1.18 IEEE-1394 Connector NOVA-7830 is equipped witch IEEE1394 controller (TI TSB43AA22). You can connect it to your 1394 device through CN21, 36 connector. The pin assignments are as follows: • CN21: 1394 Connector... -
Page 20: Cardbus/Pcmcia Connector
1.19 CardBus/PCMCIA Connector NOVA-7830 has a built-in CardBus/PCMCIA interface connector. • CN44: CardBus/PCMCIA Connector Description Description GROUND CE1# READY GROUND GROUND CD1# CE2# VS1# IORD# IOWR# VS2# RESET WAIT# INPACK# REG# BVD2 BVD1 CD2# GROUND GROUND GROUND... -
Page 21: Digital I/O
This kind of response is highly necessary for harsh and critical industrial operating environment. That’s why we design 4-bit digital inputs and 4-bit digital outputs on NOVA-7830. Digital Input and Output are control signals in general. You can use these signals to control external devices that needs On/Off circuit or TTL devices. -
Page 22: Lcd Panel Connector
1.21 LCD Panel Connector NOVA-7830 provides a 2 x 25-pin connector for the LCD flat panel interface. NOVA-7830 comes to support TFT LCD panels at following display options: Video Display type Resolution Example TFT VGA 640x480, 18bits Toshiba LTM10C209H TFT SVGA... -
Page 23: Ami Bios Setup
Chapter 4 AMI BIOS Setup Introduction This chapter discusses the Setup program built into the BIOS which allows users to configure the system. This configuration is then stored in battery-backed CMOS RAM so that Setup information is retained whilst the power is off. Starting Setup The BIOS is immediately active when you turn on the computer. - Page 24 Write the current settings to CMOS and exit. Exit Without Saving Exit without saving the current settings. AMIBIOS HIFLEX SETUP UTILITY – VERSION 1.52 ©2001 American Megatrends, Inc. All Rights Reserved NOVA-7830 V1.0 (02/11/2003) Standard CMOS Setup Advanced CMOS Setup Advanced Chipset Setup Power Management Setup...
-
Page 25: Standard Cmos Setup Selections
Standard CMOS Setup Selections AMIBIOS SETUP – STANDARD CMOS SETUP ©2001 American Megatrends, Inc. All Rights Reserved Date (mm/dd/yyyy): Tue Mar 19, 2002 Base Memory: 639 KB Time (hh/mm/ss): 17:18:10 Extd Memory: 247 MB Floppy Drive A: Not Installed Floppy Drive B: Not Installed LBA Blk PIO 32Bit Type Size Cyln Head WPcom Sec Mode Mode Mode Mode... -
Page 26: Advanced Cmos Setup Selections
Primary/Secondary Master/Slave 32Bit Mode This option enables Primary Master IDE 32-bit data transfers on the IDE data port. If disabled, 16-bit data transfer is used by the BIOS.32-bit data transfers can only be enabled if IDE prefetch mode is also enabled. Boot Sector Virus Protection When this option is enabled, AMIBIOS issues a warning when any program or virus issues a Disk Format command or attempts to write to the boot sector of the... - Page 27 2nd Boot Device This option sets the type of device for the second boot drives that the AMIBIOS attempts to boot from after AMIBIOS POST completes. The settings are Disabled, IDE-0, IDE-1, IDE-2, IDE-3, Floppy, ARMD-FDD, ARMD-HDD, and CDROM. 3rd Boot Device This option sets the type of device for the third boot drives that the AMIBIOS attempts to boot from after AMIBIOS POST completes.
- Page 28 Boot To OS/2 Set this option to Enabled if running OS/2 operating system and using more than 64MB of system memory on the motherboard. The settings are Disabled or Enabled. Wait For 'F1' If Error If this option is enabled, AMIBIOS waits for the end user to press <F1> before continuing.
-
Page 29: Advanced Chipset Setup Selections
D000, 16k Shadow These options enable shadowing of the contents of the ROM area named in the option title. The settings are Enable Disable, Cached. The ROM area that is not used by ISA adapter cards will be allocated to PCI adapter cards. D400, 16k Shadow These options enable shadowing of the contents of the ROM area named in the option title. - Page 30 DRAM Cycle time (SCLKs) This feature controls the number of SDRAM clocks used for SDRAM parameters Tras and Trc. Tras specifies the minimum clocks required between active command and precharge command. Trc specifies the minimum clocks required between active command and re-active command. CAS# Latency (SCLs) This controls the latency between the SDRAM read command and the time that the data actually becomes available.
-
Page 31: Power Management Setup Selections
Power Management Setup Selections AMIBIOS SETUP – POWER MANAGEMENT SETUP ©2001 American Megatrends, Inc. All Rights Reserved ACPI Aware O/S Available Options: Sleep State S1/POS > No USB KB/MS wakeup From S3 Disable Power Management/APM Enabled Suspend Time Out Disabled Throttle Slow Clock Temperature 65¢... - Page 32 FDC/LPT/COM Ports Enabling the option allow the IRQ input to be monitored for both inactiving for entering Auot_mode/SMI_mode and activing for entering Normal_mode. SB & MSS Audio Ports Enabling the option allow the IRQ input to be monitored for both inactiving for entering Auot_mode/SMI_mode and activing for entering Normal_mode.
-
Page 33: Pci / Plug And Play Setup Selections
Alarm Second You can set time for second. Power Type Select Select you use power type. PCI / Plug and Play Setup Selections AMIBIOS SETUP – PCI / PLUG AND PLAY SETUP ©2001 American Megatrends, Inc. All Rights Reserved Plug and Play Aware O/S Available Options: Clear NVRAM on Every Boot >... - Page 34 PCI Latency Timer (PCI Clocks) This option specifies the latency timings (in PCI clocks) for PCI devices installed in the PCI expansion slots. The settings are 32, 64, 96, 128, 160, 192, 224, or 248. PCI VGA Palette Snoop If enable, PCI will allow VGA palette signals to go to the ISA bus. Allocate IRQ to PCI VGA Set this option to Yes to allocate an IRQ to the VGA device on the PCI bus.
-
Page 35: Peripheral Setup Selections
Peripheral Setup Selections AMIBIOS SETUP – PERIPHERAL SETUP ©2001 American Megatrends, Inc. All Rights Reserved OnBoard Serial PortC 3E8/COM3 Available Options: Serial Port C IRQ Disabled OnBoard Serial PortD 2E8/COM4 3F8/COM1 Serial Port D IRQ 2F8/COM2 OnBoard FDC Enabled > 3E8/COM3 OnBoard Serial PortA 3F8/COM1 2E8/COM4... -
Page 36: Hardware Monitor Setup Selections
F1: Help F2/F3: Color Figure 8: Hardware Monitor Setup This setup helps users monitor the NOVA-7830 board on board system voltage and fan speed. The function is implemented by on board W83627HF chip. The voltage monitoring will cover V core, Vtt, +3.3V, SB5V, +5V and +12V. And there... -
Page 37: Appendix A Watchdog Timer
Appendix A Watchdog Timer The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash. This condition may have occurred by external EMI or a software bug. When the CPU stops working correctly, hardware on the board will either perform a hardware reset (cold boot) to bring the system back to a known state. -
Page 38: Appendix B Digital I/O
This kind of response is highly needed for harsh and critical industrial operating environment. That is why we design 4-bit digital inputs and 4-bit digital outputs on NOVA-7830. Digital Input and Output are control signals in general. You can use these signals to control external devices that needs On/Off circuit or TTL devices. -
Page 39: Appendix C Address Mapping
Appendix C Address Mapping IO Address Map I/O address Range Description 000-01F DMA Controller #1 020-021 Interrupt Controller #1, Master 02E-02F Super I/O 040-05F 8254 timer 04E-04F Super I/O 060-06F 8042 (Keyboard Controller) 070-07F Real time Clock, NMI Mask 080-09F DMA Page Register 0A0-0BF Interrupt Controller #2... -
Page 40: St Mb Memory Address Map
1st MB Memory Address Map Memory address Description 00000-9FFFF System memory A0000-BFFFF VGA buffer C0000-C7FFF VGA BIOS F0000-FFFFF System BIOS 1000000- Extend BIOS IRQ Mapping Table IRQ0 System Timer IRQ8 RTC clock IRQ1 Keyboard IRQ9 Available IRQ2 Cascade to IRQ Controller IRQ10 COM4 IRQ3 COM2... -
Page 41: Appendix D How To Use Wake-Up Function
Appendix D How to Use Wake-up Function NOVA-7830 provides two kinds of wake-up function: modem wake-up and LAN wake-up function. Wake-up function is working while you use ATX power supply. Wake-up By Ring: You must set the option Power On By Ring of CMOS SETUP to be enabled. The ATX power supply will be switched on when there is a ring signal detected on pin “RI”... -
Page 42: Appendix E How To Use Video-In Function
Appendix E How to Use VIDEO-IN Function NOVA-7830 provides users to capture live video from video source such as the CCTV camera. NOVA-7830 has four video input channels for surveillance systems. Driver Installation: Taking the advantage of IEI driver installation program makes the driver installation an easy job. - Page 43 Pin Definition: Dupont Head 8-Pin Description Description AVIN0 GROUND AVIN1 GROUND AVIN2 GROUND AVIN3 GROUND D-SUB 9-Pin (for both cable 1 and cable 2) Description Description AVIN0 AVIN1 AVIN2 AVIN3 N.C. GROUND GROUND GROUND GROUND Cable 2: D-SUB 9-Pin, connected to cable 1. RCA connectors are used to connect with video-in source.
-
Page 44: Appendix F How To Use Lcd-Type Function
Appendix F How to Use LCD-TYPE Function NOVA-7830 provides four kinds of LCD-TYPE Function. This page describes how to use LCD-TYPE function. LCD-TYPE function Procedure: 1. Go to the DOS command prompt in MS-DOS or Windows 9x. 2. At the DOS command prompt, type "LCD_Prg".
